TOYOTA LAND CRUISER 2007 J200 Owners Manual
Manufacturer: TOYOTA, Model Year: 2007, Model line: LAND CRUISER, Model: TOYOTA LAND CRUISER 2007 J200Pages: 374, PDF Size: 6.3 MB
Page 1 of 374
Publication No. OM60C79U
Part No. 01999-60C79
Printed in Japan 01−0608 −00
(U)
Quick index
If a service reminder indicator or warning buzzer comes on 132 . . . .
If your vehicle will not start 280 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your engine stalls while driving 284 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle overheats 284 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
If you have a flat tire 285 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . .
If your vehicle needs to be towed 297 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tips for driving during break-in period 235 . . . . . . . . . . . . . . . . . . . . . . . . . .
How to start the engine 262 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
General maintenance 313 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Complete index NO TAG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Gas station information
Fuel type:
UNLEADED gasoline, Octane Rating 87 (Research Octane Number 91)
or higher. For improved vehicle performance, the use of premium unleaded
gasoline with an Octane Rating of 91 (Research Octane Number 96) or
higher is recommended.
See page 235 for detailed information.
Fuel tank capacity: 96 L (25.4 gal., 21.1 lmp.gal.)
Engine oil:
ILSAC multigrade engine oil is recommended.
See page 325 for detailed information.
Tire information: See pages 330 through 338.
Tire inflation pressure: See page 354.
U 8
I
Page 2 of 374
You should know as much about the quality and
importance of proper main tenance of your new
vehicle as the people who built it.
The Toyota authorized Repair Manual
tells you how to maint ain your vehicle and
enables you to correct ly perform your own
maintenance.
The best way to keep your new vehicle in top
running order is to maintain it properly from
the moment you drive it off the showroom
floor.
The Toyota authorized Repair Manual is
packed with literally everything you need to
know to perform your own maintenance in
virtually every area of your new vehicle.
Page 3 of 374
Where to obtain the Repair Manual
The repair manual for LAND CRUISER may be
purchased from any Toyota dealer or the Mate-
rial Distribution Center. To purchase the repair
manual, please contact your Toyota dealer or
call the Material Distribution Center toll free
at 1 800 622 2033.
Maintenance procedures for the engine,
chassis, body, electric al system, and more,
are clearly explained and illustrated.
Periodic maintenance and tune up
Periodic maintenance and tune up helps to pre-
vent small problems from growing into larger ones lat-
er on. The repair manual outlines exactly what main-
tenance is required and clearly explains how to do the
work yourself step by step.
Areas covered include such things as spark plug re-
placement, valve clearance adjustment and engine oil
and filter replacement.
Page 4 of 374
WE REALLY CARE ABOUT YOU PLEASE BUCKLE UP
Toyota has made a special effort to encourage use of seat belts.
Toyota belts are:
Comfortable
Easy to use
Convenient
We encourage you to use your belts every time you drive.
U
Page 5 of 374
i
Foreword
Welcome to the growing group of value−conscious people who drive Toyotas. We are proud of the advanced engineering and
quality construction of each vehicle we build.
This Owner ’s Manual explains the operation of your new Toyota. Please read it thoroughly and have all the occupants
follow the instructions carefully. Doing so will help you enjoy many years of safe and trouble free motoring. For
important information about this manual and your Toyota, read the following pages carefully.
When it comes to service, remember that your Toyota dealer knows your vehicle very well and is interested in your complete
satisfaction. Your Toyota dealer will provide quality maintenance and any other assistance you may require.
If there is not a Toyota dealer near you, please call the following number:
U.S. OWNERS
:When traveling in the U.S. mainland or Canada: Toyota Customer Experience Center Toll free:1 800 331 4331
Hawaii:
Servco Automotive Customer Services Toll free:1 888 272 5515
Please leave this Owner ’s Manual in this vehicle at the time of resale. The next owner will need this information also.
All information and specifications in this manual are current at the time of printing. However, because of Toyota’s policy of
continual product improvement, we reserve the right to make changes at any time without notice.
Please note that this manual applies to all models and explains all equipment, including options. Therefore, you may
find some explanations for equipment not installed on your vehicle.
Please access our websites for further information.
The U.S. mainland www.toyota.com
Hawaiiwww.toyotahawaii.com
©2006 TOYOTA MOTOR CORPORATION
All rights reserved. This material may not be reproduced or copied, in whole or in part, without the written permission of Toyo ta
Motor Corporation.
Page 6 of 374
ii
Important information about this manual
Safety and vehicle damage warnings
Throughout this manual, you will see safety and vehicle dam-
age warnings. You must follow these warnings carefully to
avoid possible injury or damage.
The types of warnings, what they look like, and how they are
used in this manual are explained as follows:
CAUTION
This is a warning against anything which may
cause injury to people if the warning is ignored.
You are informed about what you must or must not
do in order to reduce the risk of injury to yourself
and others.
NOTICE
This is a warning against anything which may
cause damage to the vehicle or its equipment if the
warning is ignored. You are informed about what
you must or must not do in order to avoid or re-
duce the risk of damage to your vehicle and its
equipment.
Safety symbol
When you see the safety symbol
shown above, it means: “Do not”; “Do
not do this”; or “Do not let this hap-
pen”.
Page 7 of 374
iii
Important information about your Toyota
Occupant restraint systems
Toyota encourages you and your family to take the time
to read Section 1−3 of this Owner’s Manual carefully. In
terms of helping you understand how you can receive
the maximum benefit of the occupant restraint systems
this vehicle provides, Section 1 −3 of this Owner’s Manu-
al is the most important section for you and your family
to read.
Section 1 −3 describes the function and operation con-
cerning seats, seat belts, SRS airbags and child re-
straint systems of this vehicle and some potential haz-
ards you should be aware of. These systems work to-
gether along with the overall structure of this vehicle in
order to provide occupant restraint in the event of a
crash. The effect of each system is enhanced when it is
used properly and together with other systems. No
single occupant restraint system can, by itself, provide
you or your family with the equal level of restraint
which these systems can provide when used together.
That is why it is important for you and your family to
understand the purpose and proper use of each of these
systems and how they relate to each other.
The purpose of all occupant restraint systems is to help
reduce the possib ility of death or serious injury in the
event of a collision. None of these systems, either indi-
vidually or together, can ensure that there is no injury
in the event of collision. However, the more you know
about these systems and how to use them properly, the
greater your chances become of surviving an accident
without death or serious injury.
Seat belts provide the primary restraint to all occupants
of the vehicle, and every occupant of the vehicle should
wear seat belts properly at all times. Children should
always be secured in child restraint systems that are
appropriate for their age and size. SRS (Supplemental
Restraint System) airbags are, as their names imply,
designed to work with, and be supplemental to, seat
belts and are not substitutes for them. SRS airbags can
be very effective in reducing the risk of head and chest
injuries by preventing contact of the head and chest
with interior portions of the vehicle.
Page 8 of 374
iv
In order to be effective, the SRS airbags must deploy
with tremendous speed. The rapid deployment of the
SRS airbags makes the SRS airbags themselves poten-
tial sources of serious injury if an occupant is too close
to an airbag, or if an object or some part of his or her
body has been placed between the occupant and the
airbag at the time of deployment. This is just one exam-
ple of how the instructions in Section 1−3 of this Own-
er ’s Manual will help ensure proper use of the occupant
restraint systems, and increase the safety they can pro-
vide to you and your family in the event of an accident.
Toyota recommends you to read the provisions in Sec-
tion 1 −3 carefully and refer to them as needed during
your time of ownership of this vehicle.Event data recorder
Your vehicle has computers that monitor and control
certain aspects of your vehicle. These computers assist
in driving and maintaining optimal vehicle performance.
Besides storing data useful for troubleshooting, there is
a system to record data in a crash or a near car crash
event. This is called an Event Data Recorder (EDR).
The SRS airbag sensor assembly contains the EDR. In
a crash or a near car crash event, this device may
record some or all of the following information:
Engine speed
Whether the brake pedal was applied or not
Vehicle speed
To what extent the accelerator pedal was depressed
Position of the transmission selector lever
Whether the driver and front passenger wore the
seat belts or not
Driver ’s seat position
Front passenger ’s occupant classification
Page 9 of 374
v
SRS airbag deployment data
SRS airbag system diagnostic data
If your vehicle is equipped with a vehicle stability con-
trol (VSC) system, its Electronic Control Unit (ECU) may
contain another EDR. There are a variety of driving
situations which include activating the VSC under which
the VSC EDR will record certain information. The VSC
EDR may record some or all of the following informa-
tion: Behavior of the vehicle
Steering wheel angle
Vehicle speed
To what extent the accelerator pedal was depressed
To what extent the brake pedal was applied
To what extent the ECU controlled the condition of
the 4 wheels
Vehicle stability control system diagnostic data
The information above is intended to be used for the
purpose of improving vehicle safety performance. Unlike
general data recorders, the EDR does not record sound
data such as conversation between passengers.Toyota will not disclose the data recorded in an EDR to
a third party except when: An agreement from the vehicle’s owner (or the leas-
ing company for a leased vehicle) is obtained
Officially requested by the police or other authorities
Used as a defence for Toyota in a law suit
Ordered by the court
However, if necessary Toyota will: Use the data for research on Toyota vehicle safety
performance
Disclose the data to a third party for research pur-
poses without disclosing details of the vehicle own-
er, and only when it is deemed necessary
Disclose summarized data cleared of vehicle identifi-
cation information to a non −Toyota organization for
research purposes
Page 10 of 374
vi
New vehicle warranty
Your new vehicle is covered by the following Toyota
limited warranties: New vehicle warranty
Emission control systems warranty
Others
For further information, please refer to the “Owner’s
Warranty Information Booklet” or “Owner ’s Manual Sup-
plement”.
Your responsibility for maintenance
It is the owner ’s responsib ility to make sure the speci-
fied maintenance is performed. Section 6 gives details
of these maintenance requirements. Also included in
Section 6 is general maintenance. For scheduled mainte-
nance information, please refer to the “Scheduled Main-
tenance Guide” or “Owner ’s Manual Supplement”.
Important health and safety
information about your Toyota
CAUTION
WARNING: Engine exhaust, some of its constitu-
ents, and a wide variety of automobile compo-
nents contain or emit chemicals known to the
State of California to cause cancer and birth de-
fects and other reproductive harm. In addition,
oils, fuels and fluids contained in vehicles as well
as waste produced by component wear contain or
emit chemicals known to the State of California
to cause cancer and birth defects or other repro-
ductive harm.
Battery posts, terminals and related accessories
contain lead and lead compounds. Wash your
hands after handling. Used engine oil contains
chemicals that have caused cancer in laboratory
animals. Always protect your skin by washing
thoroughly with soap and water.
