navigation system TOYOTA LAND CRUISER 2010 J200 Navigation Manual

NAVIGATION SYSTEM: MEMORY POINTS
104
(a) Registering preset destinations
1. Push the “SETUP” button.
2. Touch “Navi.” on the “Setup”
screen.
3. Touch “Preset Destinations” on the
“Navigation Settings” screen.
4. Touch “Set”.
5. Enter the location in the same way
as for a destination search. (See “Des-
tination search” on page 50.)
6. Select a position for this preset des-
tination. When registration of preset destination is
completed, the “Edit Preset Destination”
screen will be displayed.
7. Touch “OK”.
To edit registered information, see “(b)
Editing preset destinations” on page 105.

NAVIGATION SYSTEM: MEMORY POINTS
105
(b) Editing preset destinations
1. Push the “SETUP” button.
2. Touch “Navi.” on the “Setup”
screen.
3. Touch “Preset Destinations” on the
“Navigation Settings” screen.
4. Touch “Edit”.
5. Touch the button of the desired pre-
set destination.
6. Touch “Edit” for the item you want
to change.
“Name”: To edit preset destination names.
The names can be displayed on the map.
(See page 110.)
“Location”: To edit location information.
(See page 111.)
“Phone #”: To edit telephone numbers.
(See page 111.)
“Icon”: To select icons to be displayed on
the map. (See page 109.)
7. Touch “OK”.

NAVIGATION SYSTEM: MEMORY POINTS
106
(c) Deleting preset destinations
1. Push the “SETUP” button.
2. Touch “Navi.” on the “Setup”
screen.
3. Touch “Preset Destinations” on the
“Navigation Settings” screen.
4. Touch “Delete”.
5. Touch the preset destination for
deletion.
“Select All”: To select all preset destina-
tions on the list.
“Unselect All”: To unselect all of the se-
lected preset destinations.
6. Touch “Delete”.
7. To delete preset destination, touch
“Yes”. To cancel the deletion, touch
“No”.Points or areas on the map can be regis-
tered.
1. Push the “SETUP” button.
2. Touch “Navi.” on the “Setup”
screen.
3. Touch “Address Book”.
Registering address book entries
(See page 107.)
Editing address book entries (See
page 108.)
Deleting address book entries (See
page 112.)
— Setting up the “Address
Book”

NAVIGATION SYSTEM: MEMORY POINTS
107
(a) Registering address book entries
1. Push the “SETUP” button.
2. Touch “Navi.” on the “Setup”
screen.
3. Touch “Address Book” on the “Nav-
igation Settings” screen.
4. Touch “New”.
5. Enter the location in the same way
as for a destination search. (See “Des-
tination search” on page 50.)
After the address book entry has been reg-
istered, the “Edit Address Book Entry”
screen will be displayed.
6. Touch “OK”.
To edit registered information, see “(b)
Editing address book entries” on page 108.
INFORMATION
Up to 100 address book entries can
be registered.

NAVIGATION SYSTEM: MEMORY POINTS
108
(b) Editing address book entries
The icon, name, location and/or telephone
number of a registered address book entry
can be edited.
1. Push the “SETUP” button.
2. Touch “Navi.” on the “Setup”
screen.
3. Touch “Address Book” on the “Nav-
igation Settings” screen.
4. Touch “Edit”.
5. Touch the button of the desired ad-
dress book entry.
6. Touch “Edit” for the item you want
to change.
“Name”: To edit address book entry
names. The names can be displayed on
the map. (See page 110.)
“Location”: To edit location information.
(See page 111.)
“Phone #”: To edit telephone numbers.
(See page 111.)
“Icon”: To select icons to be displayed on
the map. (See page 109.)
7. Touch “OK”.

NAVIGATION SYSTEM: MEMORY POINTS
109

To change “Icon”
1. Touch “Edit” of “Icon”.
2. Touch the desired icon.
Change pages by touching
“Page 1”,
“Page 2” or “With Sound” tab. SOUND ICONS
You can set a sound for some address
book entries. When the vehicle ap-
proaches
the location of the address book
entry, the selected sound will be heard.
1. Touch “With Sound” on the “Ad-
dress Book Entry Icon” screen.
2. Touch the desired sound icon.
The next screen appears when “Bell (with
Direction)” is touched.
Touch either or to adjust the
direction. Touch “OK”.
The bell sounds only when the vehicle ap-
proaches this point in the direction that has
been set.

NAVIGATION SYSTEM: MEMORY POINTS
11 0

To change “Name”
1. Touch “Edit” of “Name”.
2. Enter the name using the alphanu-
meric keys.
Up to 32 characters can be entered.
3. Touch “OK”.
The previous screen will be displayed.
DISPLAYING MEMORY POINT NAMES
The name of an address
book entry can be
set to display on the map.
To show the name, touch “On” on the
“Edit Address Book Entry” screen. To
not show it, touch “Off”.

NAVIGATION SYSTEM: MEMORY POINTS
111

To change “Location”
1. Touch “Edit” of “Location”.
2. Touch
one of the 8 directional touch
screen buttons to move the cursor
to the desired point on the map.
3. Touch “OK”.
The previous screen will be displayed.
To change “Phone #”
(telephone number)
1. Touch “Edit” of “Phone #”.
2. Enter the number using number
keys.
3. Touch “OK”.
The previous screen will be displayed.

NAVIGATION SYSTEM: MEMORY POINTS
11 2
(c) Deleting address book entries
1. Push the “SETUP” button.
2. Touch “Navi.” on the “Setup”
screen.
3. Touch “Address Book” on the “Nav-
igation Settings” screen.
4. Touch “Delete”.
5. Touch the button to be deleted.
“Select All”: To select all addresses in the
address book.
“Unselect All”: To unselect all of the se-
lected addresses.
6. Touch “Delete”.
7. To delete the address book entry,
touch “Yes”. To cancel the deletion,
touch “No”. Areas you
want to avoid because of traffic
jams, construction work or other reasons
can be registered as areas to avoid.
1. Push the “SETUP” button.
2. Touch “Navi.” on the “Setup”
screen.
3. Touch “Areas to Avoid”.
Registering areas to avoid (See
page 113.)
Editing areas to avoid (See page
114.)
Deleting areas to avoid (See page
117.)
— Setting up the “Areas to
Avoid”

NAVIGATION SYSTEM: MEMORY POINTS
11 3
(a) Registering areas to avoid
1. Push the “SETUP” button.
2. Touch “Navi.” on the “Setup”
screen.
3. Touch “Areas to A void” on the “Nav-
igation Settings” screen.
4. Touch “New”.
5. Enter the location in the same way
as for a destination search, or display
the map of the area to be avoided. (See
“Destination search” on page 50.)
6. Scroll the map to the desired point.
“Adjust Location” : To adjust the position
in smaller increments.
7. Touch “Enter”.
8. Touch either or to
change the size of the area to be
avoided.
9. Touch “OK”.
INFORMATION
 If a destination is input in the area
to avoid or the route calculation
cannot be made without running
through the area to avoid, a route
passing through the area to be
avoided may be shown.
 Up to 10 locations can be regis-
tered as points/areas to avoid.
