TOYOTA LAND CRUISER 2011 J200 Owners Manual

581
6-1. Specifications
6
Vehicle specifications
L/C200_U (OM60F74U)
Tire related termMeaning
Snow tire A tire that attains a traction index equal to or
greater than 110, compared to the ASTM E-
1136 Standard Reference Test Tire, when
using the snow traction test as described in
ASTM F-1805-00, Standard Test Method for
Single Wheel Driving Traction in a Straight Line
on Snow-and Ice-Covered Surfaces, and which
is marked with an Alpine Symbol ( ) on at
least one sidewall
Te s t r i m The rim on which a tire is fitted for testing, and
may be any rim listed as appropriate for use
with that tire
Tread That portion of a tire that comes into contact
with the road
Tread rib A tread section running circumferentially
around a tire
Tread separation Pulling away of the tread from the tire carcass
Treadwear indicators
(TWI) The projections within the principal grooves
designed to give a visual indication of the
degrees of wear of the tread
Wheel-holding fixture The fixture used to hold the wheel and tire
assembly securely
during testing

582 6-1. Specifications
L/C200_U (OM60F74U)
*:Table 1  Occupant loading and distribution for vehicle normal load
for various designated seating capacities
Designated seating
capacity, Number of occupantsVehicle normal load,
Number of occupantsOccupant distribution in a normally loaded vehicle
2 through 4 2 2 in front
5 through 10 3 2 in front, 1 in second
seat
11 through 15 5 2 in front, 1 in second
seat, 1 in third seat, 1
in fourth seat
16 through 20 7 2 in front, 2 in second
seat, 2 in third seat, 1
in fourth seat

583
6
Vehicle specifications
L/C200_U (OM60F74U)
6-2. Customization
Customizable features
Customizing vehicle features using the touch screen (vehicles
with navigation system)Press “SETUP”.
Touch “Vehicle” on the “Setup” screen.
Touch “Vehicle Customization”. Touch the setting to be changed.
Change each setting and touch
“Save”.
If “Save” is not touched before
switching to another screen, any
changes will be lost.
A message indicating that the settings are being saved will
appear.
Do not perform any other operations while this message is
displayed.
Your vehicle includes a variety of electronic features that can be per-
sonalized to your preferences.
Programming of these preferences can be performed by your Toyota
dealer.
For vehicles with the navigation syst em, it is also possible to cus-
tomize certain vehicle features yourself using the touch screen.
Some function settings are changed simultaneously with other functions
being customized. Contact your Toyota dealer for further details.
STEP1
STEP2
STEP3
STEP4
STEP5

584 6-2. Customization
L/C200_U (OM60F74U)
Customizable featuresVehicle customization settings can be changed at your Toyota dealer.
For vehicles with the navigation system, some settings can be
changed using the touch screen.
Settings that can be changed using the touch screen
Settings that can be chan ged using the vehicle switches
Settings that can be chan ged by your Toyota dealer
Definition of symbols: O= Available, — = Not available
ItemFunctionDefault
settingCustomized setting
Smart key
system
(P. 26) Smart key sys-
tem
ON OFF O — O
Smart door
unlocking Driver’s door All the doors O O O
Operation signal
(Buzzer) ON OFF — — O

585
6-2. Customization
6
Vehicle specifications
L/C200_U (OM60F74U)
Wireless
remote
control
(
P. 39) Wireless remote
control
ON OFF — — O
Open door warn-
ing function
(when locking the
vehicle) ON OFF — — O
Unlocking opera-
tion Driver’s door
unlocked in
one step, all doors
unlocked in two steps All doors
unlocked in one step O—O
Smart key
system
( P. 26)
and
wireless
remote
control
( P. 39) Operation signal
(Emergency
flashers)
ON OFF O — O
Time elapsed
before automatic
door lock function
is activated if
door is not
opened after
being unlocked 60 seconds
OFF
O—O
30 seconds
120 seconds
ItemFunctionDefault settingCustomized setting

586 6-2. Customization
L/C200_U (OM60F74U)
Door lock
(P. 41) Unlocking using a
key
Driver’s door
unlocked in
one step, all doors
unlocked in two steps All doors
unlocked in one step O—O
Speed-detecting
automatic door
lock function OFF ON O O O
Shifting the shift
lever to position
other than “P”
locks all doors ON OFF O O O
Shifting the shift
lever to “P”
unlocks all doors ON OFF O O O
Opening driver’s
door unlocks all
doors OFF ON O O O
Power
windows
( P. 86) Mechanical key
linked operation
(close)
OFF ON — — O
Mechanical key
linked operation
(open) OFF ON — — O
Wireless remote
control linked
operation (open) OFF ON — — O
Linked entry
function OFF ON — — O
ItemFunctionDefault
settingCustomized setting

587
6-2. Customization
6
Vehicle specifications
L/C200_U (OM60F74U)
*1: The settings can be changed when the mechanical key linked operation of
the power window is set to ON.
*2: The settings can be changed when the wireless remote control linked oper-ation of the power window is set to ON.
*3: The settings can be changed when the entry function linked operation of thepower window is set to ON.
Moon roof
(
P. 90) Mechanical key
linked operation
(open)
*1OFF
ON — — O
Mechanical key
linked operation
(close)
*1OFF ON — — O
Linked operation
of components
when door key is
use Slide only Tilt only — — O
Wireless remote
control linked
operation
(open)
*2
OFF ON — — O
Linked operation
of components
when wireless
remote control
used Slide only Tilt only — — O
Linked entry
function
*3OFF ON — — O
ItemFunctionDefault
settingCustomized setting

588 6-2. Customization
L/C200_U (OM60F74U)
ItemFunctionDefault settingCustomized setting
Illumination
(P. 379) Time period
before the interior
lights turn off
15 secondsOFF
O—O
7.5 seconds
30 seconds
Time period
before the exte-
rior lights turn off 15 secondsOFF
O—O
7.5 seconds
30 seconds
Operation after
the “ENGINE
START STOP”
switch is turned
off ON OFF — — O
Operation when
the doors are
unlocked ON OFF — — O
Operation when
you approach the
vehicle with the
electronic key on
your person
(When the inte-
rior light switch is
door position) ON OFF — — O
Foot lights ON OFF — — O
Sensitivity of the
ambient light sen-
sor used for dim-
ming the meter
lights etc. Standard -2 to 2 O — O
Sensitivity of the
ambient light sen-
sor used for
brightening the
meter lights etc. Standard -2 to 2 O — O

589
6-2. Customization
6
Vehicle specifications
L/C200_U (OM60F74U)
Automatic
light control
system
(
P. 176) Light sensor sen-
sitivity
Standard -2 to 2 O — O
Daytime running
light system ON OFF O — O
Time elapsed
before head-
lights automati-
cally turn off after
doors are closed 30 seconds
OFF
O—O
60 seconds
90 seconds
Automatic
air
conditioning
system
( P. 256) Switching
between outside
air and recircu-
lated air mode
linked to “AUTO”
switch operation
Auto Manual O — O
A/C Auto switch
operation Auto Manual O — O
ItemFunctionDefault
settingCustomized setting

590 6-2. Customization
L/C200_U (OM60F74U)
■Vehicle customization
● If the smart key system is turned “OFF”, unlock door cannot be selected.
● If the doors are not opened after locking and are then automatically re-
locked, a signal will be given if “Operation signal (Emergency flashers)”
or “Operation signal (Buzzer)” are set to ON.
■ When setting using the vehicle sw itches (vehicles with navigation sys-
tem)
When using the vehicle switches to set an item that can also be set using the
touch screen, the item displayed on the touch screen will not change imme-
diately.
If the “ENGINE START STOP” switch is first turned to OFF, the screen dis-
play will change once the “ENGINE START STOP” switch is turned to IGNI-
TION ON mode again.
■ When customizing using the touch screen (vehicles with navigation
system)
Stop the vehicle in a safe place, apply the parking brake, and shift the shift
lever to “P”. Also, to prevent battery discharge, leave the engine running
while customizing the features.
