Screen TOYOTA LAND CRUISER 2014 J200 Navigation Manual

257
1. AUDIO/VIDEO SYSTEM OPERATION
5
AUDIO/VIDEO SYSTEM
L/C200_Navi_OM60L27U_(U)
13.06.03 19:41
■REPEATING AN ALBUM
1Touch “RPT” repeatedly until
“ALB.RPT” appears on the screen.
When the album is finished, the player will
automatically go back to the beginning of
the album and play it again. To cancel this
function, touch “RPT” again.
■PLAYING THE TRACKS ON THE
ALBUM IN RANDOM ORDER
1Touch “RAND” while the track is play-
ing.
Each time “RAND” is touched, the mode
changes as follows:
• Album Random  All Track Random 
Off
Once “RAND” appears on the screen, the
system selects a track randomly from the
album currently being listened to. To can-
cel this function, touch “RAND” repeat-
edly until the random mode turns off.
■PLAYING TRACKS FROM ALL THE
ALBUMS IN RANDOM ORDER
1Touch “RAND” repeatedly until
“ALB.RAND” appears on the screen.
Once “ALB.RAND” appears on the
screen, the system selects a track
randomly from all of the existing albums
on the Bluetooth
® device. To cancel this
function, touch “RAND” again.
RANDOM ORDER
Tracks or albums can be automatically
and randomly selected.
INFORMATION
●Depending on the portable player that is
connected to the system, certain func-
tions may not be available.

259
1. AUDIO/VIDEO SYSTEM OPERATION
5
AUDIO/VIDEO SYSTEM
L/C200_Navi_OM60L27U_(U)
13.06.03 19:41
1Press the “AUDIO” button.
2Touch the “A/V” tab or press the
“AUDIO” button repeatedly until the
“A/V” tab is selected.
Touch “Options” on the screen, then
touch
“Wide” on the “A/V Options”
screen. The screen mode can be
changed.
If “Full Screen” is touched when the vehi-
cle is completely stopped and the parking
brake is applied, the VTR video screen will
be displayed.
If any part of the VTR screen is touched,
the system will return to the VTR top
screen.
1Press the “AUDIO” button.
2Touch the “A/V” tab or press the
“AUDIO” button repeatedly until the
“A/V” tab is selected.
3Touch “Options”.
4This screen is displayed.
PLAYING VTRVTR OPTIONS
No.FunctionPage
Touch to display the
screen mode screen. 198
Touch to display the im-
age quality adjustment
screen.
226

263
1. AUDIO/VIDEO SYSTEM OPERATION
5
AUDIO/VIDEO SYSTEM
L/C200_Navi_OM60L27U_(U)
13.06.03 19:41
1To open the display, press the
“OPEN”, “SOURCE” or “DISC” but-
ton. To close the display, press the
“OPEN” or button.
If the display is closed with an image
shown, the image will automatically turn
off. (When you press the “OPEN” button,
the sound will not be turned off.)
1Press the “SETTING” button on the
controller.
2Select “TILT” tab.
3Select or .
This screen appears for a few seconds
when the rear display is opened. During
this time, only “OPEN/CLOSE” can be
operated.
OPENING AND CLOSING THE
DISPLAY
Opening and closing operations can be
performed from the front audio system.
(See page 266.)
JAM PROTECTION
The display will stop closing and return
to its previous position if something
gets in the way of it closing.
TILTING THE DISPLAY
INFORMATION
●The display angle is memorized and will
be recalled when the “ENGINE START
STOP” switch is turned to ACCESSORY
or IGNITION ON mode again.
CAUTION SCREEN

264
1. AUDIO/VIDEO SYSTEM OPERATION
L/C200_Navi_OM60L27U_(U)
13.06.03 19:41
1Press the “SOURCE” button to display
the audio source selection screen.
2Select an audio source.
1To play the rear audio over the speak-
ers in the vehicle, turn “Speaker Out-
put” on.
CHANGING THE SOURCE
No.Function
Turning on the audio source selec-
tion screen
Selecting an icon
Inputting the selected icon
CHANGING THE SPEAKER
OUTPUT

265
1. AUDIO/VIDEO SYSTEM OPERATION
5
AUDIO/VIDEO SYSTEM
L/C200_Navi_OM60L27U_(U)
13.06.03 19:41
CAUTION
●When the rear seat entertainment sys-
tem is not used
• Keep the display closed. In the event
of an accident, sudden braking or
sudden swerving, the opened display
may hit an occupant’s body, resulting
in injury.
●While driving
• Do not use headphones. Doing so
may cause an accident, resulting in
death or serious injury.
●To prevent accidents and electric shock
• Do not disassemble or modify the
remote control.
●When the remote control is not used
• Stow the remote control. Injuries may
result in the event of sudden braking,
sudden swerving or an accident.
●When you close the display
• Never use any part of your body to
intentionally activate the jam protec-
tion function.
●Conversational speech on some DVDs
is recorded at a low volume to empha-
size the impact of sound effects. If you
adjust the volume assuming that the
conversations represent the maximum
volume level that the DVD will play, you
may be startled by louder sound effects
or startled when you change to a differ-
ent audio source. The louder sounds
may have a significant impact on the
human body or pose a driving hazard.
Keep this in mind when you adjust the
volume.
●Removed battery and other parts:
• Keep away from children. These
parts are small and if swallowed by a
child they can cause choking. Failure
to do so could result in death or seri-
ous injury.
NOTICE
●Cleaning the display
• Wipe the display with a dry soft cloth.
• If the screen is wiped with a rough
cloth, the surface of the screen may
be scratched.
●To prevent damage to the remote control
• Keep the remote control away from
direct sunlight, temperature heat and
high humidity.
• Do not drop or knock the remote con-
trol against hard objects.
• Do not sit on or place heavy objects
on the remote control.
●Closing the display
• Do not close the display using your
hand. Doing so may result in a mal-
function.
●For normal operation after replacing the
battery, observe the following precau-
tions to prevent accidents:
• Always work with dry hands. Moisture
may cause the battery to rust.
• Do not touch or move any other com-
ponents inside the remote control.
• Do not bend either of the battery ter-
minals.

266
1. AUDIO/VIDEO SYSTEM OPERATION
L/C200_Navi_OM60L27U_(U)
13.06.03 19:41
1Press the “AUDIO” button.
2Touch the “Rear” tab or press the
“AUDIO” button repeatedly until the
“Rear” tab is selected.
3Touch the desired button. The selected
button indicator is highlighted.
1Select radio mode on the source
screen to display the control screen.
1Press the “” or “” button of
“FOL/CH” until the desired station/
channel band appears on the
screen.
OPERATION FROM THE
FRONT SEATS
The rear seat display can be operated
from the front seats.
No.Function
Turns the rear display open or close.
Locks the system so passengers in
the rear seats cannot operate the
rear entertainment system.
Enables the front speakers to output
the front audio system’s audio
source.
USING THE RADIO
When a different audio source is se-
lected at the front seats, radio mode
cannot be selected at the rear seats.
SELECTING A PRESET
STATION/CHANNEL

267
1. AUDIO/VIDEO SYSTEM OPERATION
5
AUDIO/VIDEO SYSTEM
L/C200_Navi_OM60L27U_(U)
13.06.03 19:41
Using the “TUNE” button
1Press the “” or “” button of
“TUNE” until the desired station/chan-
nel appears on the screen.
Press and hold the “” or “” button of
“TUNE” and the stations/channels will be
searched automatically one after another.
Using the / button
1Press the or button until the
desired station/channel appears on the
screen.
Press and hold the or button
until a beep is heard. The radio will begin
seeking up or down for a station/channel
of the nearest frequency.
Continue to press and hold the or
button after a beep is heard and sta-
tions/channels will be sought for automati-
cally. When the or button is
released the radio will seek up or down for
a station/channel of the nearest frequency.
1Select Apps mode on the source
screen to display the control screen.
TUNING THE STATION/
CHANNELUSING THE RADIO (INTERNET
RADIO BROADCAST)
One of Entune’s features is the ability
to listen to internet radio. In order to
use this service, an Entune compatible
phone and the navigation system
needs to be set. For details, refer to the
“ENTUNE SERVICE” section. (See
page 348.)

268
1. AUDIO/VIDEO SYSTEM OPERATION
L/C200_Navi_OM60L27U_(U)
13.06.03 19:41
1Connect iPod. (See “CONNECTING
iPod” on page 241.)
2Select iPod mode on the source
screen to display the control screen.
1Press the button.
1Press the or button repeated-
ly until the desired track number ap-
pears on the screen.
1Press the or button, or press
and hold the or button.
Press the “SOURCE” button and the sys-
tem will return to the iPod control screen.
PLAYING iPod
When a different audio source is se-
lected at the front seats, iPod mode
cannot be selected at the rear seats.
PLAYING AND PAUSING iPod
SELECTING A DESIRED
TRACK
FAST FORWARDING OR
REWINDING
DISPLAYING iPod VIDEO
If iPod mode is selected again at the
rear seats when iPod video is being
displayed in the front monitor, iPod vid-
eo can be displayed.
INFORMATION
●Depending on the iPod that is connected
to the system, certain functions may not
be available.

269
1. AUDIO/VIDEO SYSTEM OPERATION
5
AUDIO/VIDEO SYSTEM
L/C200_Navi_OM60L27U_(U)
13.06.03 19:41
1Connect a USB memory. (See “CON-
NECTING A USB MEMORY” on page
236.)
2Select USB mode on the source
screen to display the control screen.
1Press the button.
1Press the “” or “” button of “FOL/
CH” until the desired folder/album
number appears on the screen.
1Press the or button repeated-
ly until the desired file/track number
appears on the screen.
1Press the or button, or press
and hold the or button.
1Select BT-A mode on the source
screen to display the control screen.
PLAYING A USB MEMORY
When a different audio source is se-
lected at the front seats, USB mode
cannot be selected at the rear seats.
PLAYING AND PAUSING A USB
MEMORY
SELECTING A DESIRED
FOLDER OR ALBUM
SELECTING A DESIRED FILE
OR TRACK
FAST FORWARDING OR
REWINDING
INFORMATION
●Depending on the USB memory that is
connected to the system, certain
functions may not be available.
PLAYING Bluetooth® AUDIO
When a different audio source is se-
lected at the front seats, BT-A mode
cannot be selected at the rear seats.

270
1. AUDIO/VIDEO SYSTEM OPERATION
L/C200_Navi_OM60L27U_(U)
13.06.03 19:41
1Press the button.
1Press the “” or “” button of “FOL/
CH” until the desired album number
appears on the screen.
1Press the or button repeated-
ly until the desired track number ap-
pears on the screen.
1Press the or button, or press
and hold the or button.
1Select disc mode on the source screen
to display the control screen.
2Press the or button until the
desired track number appears on the
screen.
1Press the or button, or press
and hold the or button.
1Press the button.
PLAYING AND PAUSING
Bluetooth® AUDIO
SELECTING A DESIRED
ALBUM
SELECTING A DESIRED
TRACK
FAST FORWARDING OR
REWINDING
INFORMATION
●Depending on the portable player that is
connected to the system, certain
functions may not be available.
PLAYING AN AUDIO CD/CD
TEXT
SELECTING A TRACK
FAST FORWARDING OR
REWINDING A TRACK
PLAYING OR PAUSING A
TRACK
