TOYOTA LAND CRUISER 2016 J200 Owners Manual

LC200_OM_OM60M88U_(U)
3915-1. Using the air conditioning system and defogger
5
Interior features
■Modes and indicators
The mode can be changed by pressing the switch.
*: When automatic mode is selected, the level automatically changes
depending on the air conditioning settings.
■ The seat heaters and ventila tors can be used when
The engine switch is in IGNITION ON mode.
■ Replacing the air filters
Filters are installed in the seat ventilators. For replacement of the filters, con-
tact your Toyota dealer.
■ Customization
The automatic mode settings for the seat heaters and ventilators can be
changed. ( P. 574)
Mode“AUTO” indicator lightLevel indicator lights
OffOffOff
Automatic*On3 to 1, or off
HiOff3
MidOff2
LoOff1

3925-1. Using the air conditioning system and defogger
LC200_OM_OM60M88U_(U)
For left-hand second seat
For right-hand second seat
High heating temperature
Low heating temperature
To turn on the seat heater, press
“HI” or “LO”.
Off
■The seat heaters can be used when
The engine switch is in IGNITION ON mode.
Second outboard seat heaters (if equipped)
1
2
3
4
45

393
LC200_OM_OM60M88U_(U)
5-2. Using the interior lights
5
Interior features
Interior lights list
Front interior lights ( P. 394)
Front personal lights ( P. 395)
Rear interior lights ( P. 394)
Rear personal lights ( P. 395)
Inside door handle lights Footwell lights
Scuff lights
Engine switch light
Door courtesy lights
Ambient lights1
2
3
4
5
6
7
8
9
10

394
LC200_OM_OM60M88U_(U)
5-2. Using the interior lights
Front
Door position on/off
Turns the light on/off
Rear
On/door position on
Interior lights
1
2

LC200_OM_OM60M88U_(U)
3955-2. Using the interior lights
5
Interior features
Front
Turns the light on/off
Rear
Turns the light on/off
■ Illuminated entry system
The lights automatically turn on/off according to engine switch mode, the
presence of the electronic key, whether the doors are locked/unlocked, and
whether the doors are open/closed.
■ To prevent battery discharge
If the interior lights remain on when the engine switch is turned off, the lights
will go off automatically after 20 minutes:
■ Customization
Settings (e.g. adjust the time elapsed before the interior lights automatically
turn off) can be changed. (Customizable features: P. 574)
Personal lights
NOTICE
To prevent battery discharge, do not leave the lights on longer than neces-
sary when the engine is not running.

396
LC200_OM_OM60M88U_(U)
5-3. Using the storage features
List of storage features
Card holders (P. 403)
Overhead console ( P. 399)
Glove box ( P. 397)
Bottle holders ( P. 402)
Door pockets
Auxiliary boxes ( P. 403) Console box (
P. 398)
Cool box (if equipped)
(  P. 406)
Cup holders ( P. 400)
Auxiliary box (if equipped)
(  P. 403)
Wireless charger (if equipped)
(  P. 412)
WARNING
■Items that should not be left in the storage spaces
Do not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:
●Glasses may be deformed by heat or cracked if they come into contact
with other stored items.
● Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may release gas,
causing a fire hazard.
1
2
3
4
5
6
7
8
9

LC200_OM_OM60M88U_(U)
3975-3. Using the storage features
5
Interior features
Open (push button)
Lock with the mechanical key
Unlock with the mechanical key
■Glove box light
The glove box light turns on when the tail lights are on.
■ Removing the separate tray
Glove box
1
2
3
Pull out the separate tray while releasing
the clips.
WARNING
Keep the glove box closed while driving.
Injuries may result in the event of sudden braking, sudden swerving or an
accident.

398
LC200_OM_OM60M88U_(U)
5-3. Using the storage features
Your vehicle is equipped with either a lower console box or cool box.
For vehicles with the cool box, refer to page 406.
Upper console box
Press the tab to open.
Lower console box (if equipped)
Lift the lever to open.
Remove the tray.
Console box
1
2
WARNING
Keep the console box closed while driving.
Injuries may result in the event of sudden braking, sudden swerving or an
accident.

LC200_OM_OM60M88U_(U)
3995-3. Using the storage features
5
Interior features
Press the button.
Overhead console
WARNING
■Items unsuitable for storing
Do not store items heavier than 0.4 lb. (0.2 kg).
Doing so may cause the overhead console to open and the items inside
may fall out, resulting in an accident.
■ While driving
Do not leave the overhead console open.
Items may fall out and cause injury.

400
LC200_OM_OM60M88U_(U)
5-3. Using the storage features
Front
Press down and release the lid.
You can adjust or remove the sep-
arator inside.
Rear
Pull the armrest down. ( P. 420)
Press the button.
Cup holders
1
2
