TOYOTA LAND CRUISER 2016 J200 Owners Manual

LC200_OM_OM60M88U_(U)
4015-3. Using the storage features
5
Interior features
■Removing the cup holder insert (front cup holders)
Pull up the insert.
Cup holder insert may be removed for
cleaning.
WARNING
■ Items unsuitable for the cup holder
Do not place anything other than cups or beverage cans in the cup holders.
Even with the lid is closed, items must not be stored in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, cause injury. If possible, cover hot drinks to prevent burns.
■ When not in use
Keep the cup holders closed.
Injuries may result in the event of sudden braking, sudden swerving or an
accident.
NOTICE
■To prevent damage to the cup holders (vehicles with a rear cup holder)
Stow the cup holders before stowing the rear armrest.

402
LC200_OM_OM60M88U_(U)
5-3. Using the storage features
Bottle holders
Front seatsSecond seats
Third seats
NOTICE
■Items that should not be st owed in the bottle holders
Put the cap on before stowing a bottle. Do not place open bottles in the bot-
tle holders, or glasses and paper cups containing liquid. The contents may
spill and glasses may break.

LC200_OM_OM60M88U_(U)
4035-3. Using the storage features
5
Interior features
Your vehicle is equipped with either a front auxiliary box or wireless
charger.
For vehicles with wireless charger, refer to page 412.
Card holders
Sun visorInstrument panel
Auxiliary boxes
Front (if equipped)Rear (type A)
Press the lid to open.
Rear (type B)
Press the button to open.

404
LC200_OM_OM60M88U_(U)
5-3. Using the storage features
Luggage compartment features
Raise the hook to use.
The cargo hooks are provided for
securing loose items.
To hang the cargo net, use the
cargo net hooks and rear tie-down
hooks.
The cargo net itself is not included
as an original equipment.
Remove the cover. Hold the warn-
ing reflector with the bands.
The warning reflector itself is not
included as an original equipment.
Cargo hooks
Cargo net hooks
Warning reflector holder

LC200_OM_OM60M88U_(U)
4055-3. Using the storage features
5
Interior features
Remove the cover. Hold the first-
aid kit with a band.
The first-aid kit itself is not included
as an original equipment.
First-aid kit holder
WARNING
●To avoid injury, always return the cargo hooks to their positions when not
in use.
● Keep the auxiliary box closed. In the event of sudden braking or sudden
swerving, an accident may occur due to an occupant being struck by an
open auxiliary box or the items stored inside.
NOTICE
■To prevent damage to the cargo net hooks
Avoid hanging things other than a cargo net on it.

406
LC200_OM_OM60M88U_(U)
5-4. Using the other interior features
Other interior features
While the engine is running, the cool box, which is cooled by the air
conditioning, can be used.
Lift the lid while pulling up the
lower lever to release the lock.
Turns the cool box on/off
When on, the indicator light comes
on.
If the front air conditioning system
is not in use, the front air condition-
ing system is automatically turned
on when the cool box is turned on.
■While the cool box is on
The front air conditioning system cannot be turned off.
■ When the outside temperature is 0 C (32 F) or below
The cool box may not operate.
Cool box (if equipped)
1
2

LC200_OM_OM60M88U_(U)
4075-4. Using the other interior features
5
Interior features
WARNING
Keep the cool box closed while driving.
Injuries may result in the event of sudden braking, sudden swerving or an
accident.
NOTICE
To prevent battery discharge, do not leave the cool box on longer than nec-
essary when the engine is not running.

408
LC200_OM_OM60M88U_(U)
5-4. Using the other interior features
Main sun visor
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
To use the side extender, place
the visor in the side position,
then slide it backward.
Sub sun visor
Flip down with the main sun visor
in position or .
Slide the cover to open.
The light turns on when the cover
is opened.
If the vanity lights remain on when the engine switch is turned off, the lights
will go off automatically after 20 minutes.
Sun visors
1
2
3
23
Vanity mirror
NOTICE
To prevent battery discharge, do not leave the vanity lights on for extended
periods when the engine is not running.

LC200_OM_OM60M88U_(U)
4095-4. Using the other interior features
5
Interior features
Refer to “NAVIGATION SYSTEM
OWNER’S MANUAL” for adjust-
ment.
■The clock is displayed when
The engine switch is in ACCESSORY or IGNITION ON mode.
The displayed temperature
ranges from -22 F (-30C) up to
122 F (50 C).
■The outside temperature is displayed when
The engine switch is in IGNITION ON mode.
■ When --- is displayed
The system may be malfunctioning. Take your vehicle to your Toyota dealer.
■ Display
In the following situations, the correct outside temperature may not be dis-
played, or the display may take longer than normal to change.
●When stopped, or driving at low speeds (less than 12 mph [20 km/h])
● When the outside temperature has changed suddenly (at the entrance/exit
of a garage, tunnel, etc.)
Clock
Outside temperature display

410
LC200_OM_OM60M88U_(U)
5-4. Using the other interior features
The power outlet can be used for the following components:
12 V DC: Accessories that run on less than 10 A
120 V AC: Accessories that use less than 100 W
■Center of console
Front (12 V DC)
Press the lid to open.
Rear (12 V DC)
Power outlets
