ECO mode TOYOTA LAND CRUISER 2017 J200 Quick Reference Guide

OVERVIEW
FEATURES/OPERATIONS
TOYOTA SAFETY SENSE
SAFETY AND EMERGENCY FEATURES
3
“ENGINE START STOP” button (Smart Key)
Audio/Navigation
2 system
Emergency flasher button
Air conditioning and heating controls
Front seat heater/ventilator switches
Heated steering wheel switch
USB/AUX port
Four-wheel drive
control switch
Crawl control
switch
Multi-terrain Select mode selector/
Crawl Control speed mode dial
Center differential lock/unlock switch
VSC OFF switch
Second start mode switch
POWER mode switch Turn Assist switch
Audio system
Shift lever
Parking brake
1 If equipped2 For details, refer to the “Navigation System Owner’s Manual” an\
d “2017 Entune™ Audio
Quick Reference Guide.”

OVERVIEW
FEATURES/OPERATIONS
TOYOTA SAFETY SENSE
SAFETY AND EMERGENCY FEATURES
5
Arrow direction indicates fuel
tank door position
Low fuel level warning
Brake system warning2
Anti-lock Brake System warning2
Parking brake indicator
Shift position and range indicators
Roll Sensing of Curtain shield
Airbag OFF indicator2
Automatic Transmission
second start indicator
Power mode indicator
Vehicle Stability Control OFF indicator
Slip indicator
Low speed four-wheel drive indicator
Center differential lock indicator
Crawl Control indicatoraVehicle Stability Control OFF indicator
Multi-terrain select indicator
ECO driving indicator2
Turn assist function indicator
TRAC OFF indicator
Headlight low/high beam indicator
Turn signal indicator
Fog light indicator
Automatic headlight leveling
system warning
1 If equipped.2
If indicator does not turn off within a few seconds of starting engine, \
there may be a malfunction.
Have vehicle inspected by your Toyota dealer.
AIR BAG ON-OFF indicatorCruise control indicator/
Cruise control SET indicator
Auto High Beam indicator
Pre-Collision System warning2
Blind Spot Monitor indicator2
Rear Cross Traffic
Alert indicator
Blind Spot Monitor outside rear
view mirror indicators2
Land Departure Alert indicator
Dynamic Radar Cruise Control
indicator

10
Auto lock/unlock
Automatic transmission
Automatic door locks can be programmed to operate in four different mode\
s, or
turned OFF.
-Doors lock when shifting from Park.
-Doors lock when the vehicle speed is approximately 12 mph or higher.
-Doors unlock when shifting into Park.
-Doors unlock when the driver’s door is opened within 45 seconds after\
turning the “ENGINE START STOP” switch OFF. (Vehicles with a Smart Key system\
)
-Doors unlock when the driver’s door is opened within 45 seconds afte\
r turning the ignition switch to the “ACC” or “LOCK” position. (Vehic\
les without a Smart Key
system)
Refer to the Owner’s Manual for more details.
* The “ENGINE START STOP” switch/ignition switch must be “ON”\
and the brake pedal depressed to shift from Park.
Shift the shift lever to “S” position from “D” position.
+ : Upshift (push and release)
- : Downshift (pull and release)
Downshifting increases power going uphill, or provides engine braking do\
wnhill. For
best fuel economy during normal driving conditions, always drive with th\
e shift lever
in the “D” position.
Park*
Reverse
Neutral
Drive
P
R
N
D
S“S” mode
For powerful acceleration and driving in
mountainous regions.For starting on slippery surfaces, such as snowy
roads. Press “2nd” to return to normal mode.
POWER MODE SECOND GEAR START MODE
FEATURES & OPERATIONS
“S” (SEQUENTIAL) MODE

OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
19
Moon roof
OpenTilt
CloseClose
Recommended open position to minimize
wind noise.
Push once to open partway;
again to open completely.
Rear view mirror-Outside
Linked mirror function when reversing
The outside rearview mirrors automatically
angle downwards when vehicle is in reverse. Will only operate when switc\
h is in “L”
or “R” position. Use switch to adjust mirror
angle while in ACCESSORY or
IGNITION ON mode.
SLIDIING OPERATION
TILTING OPERATION
Rear view mirror-Outside

32
TOYOTA SAFETY SENSE
CHANGING THE PRE-COLLISION WARNING TIMING
DISABLING THE PRE-COLLISION SYSTEM (PCS)
Each time the Pre-Collision System switch is pressed, the response to th\
e warning
distance changes.
To disable the system
Press the PCS switch for 3 seconds or more.
The PCS warning light will turn on and a message will be displayed on th\
e Multi-
Information Display (MID).
To enable the system
Press the PCS switch again.
The system is enabled each time the engine switch is turned to IGNITION \
ON mode.
Far
Middle
Near

36
1 The set speed may also be cancelled by depressing the brake pedal.2 The set speed may be resumed once vehicle speed exceeds 25 mph.
DRCC helps maintain a pre-set distance to a preceding vehicle when the
preceding vehicle is traveling at a lower speed. This mode is always sel\
ected first
when the cruise control button is depressed. Constant speed cruise contr\
ol mode
is also available.
Vehicle will cruise at a set speed, decelerate to maintain selected dist\
ance from a
slower vehicle traveling in front and accelerate back up to the selected\
speed if the
vehicle in front changes lanes or speeds up.

(1) Push the ON-OFF button. The “RADAR READY” or “
” indicator will come on.
(2) Push the lever down to SET speed, push it up to Resume and pull it\
or depress brake to Cancel.
(3) Push up to increase the set speed, push down to decrease (1mph in\
crements).
(1) Note: If DRCC is turned off and
you hold the ON-OFF button for
at least 1.5 seconds, the system
switches to constant speed
control mode. Vehicle-to-vehicle distance button
Cruise control switch
Display
Set speed
Increase
speed
Decrease
speed
(3)
SetCancel1
Resume2(2)
Dynamic Radar Cruise Control (DRCC)
TOYOTA SAFETY SENSE
TURNING SYSTEM ON/OFF
ADJUSTING SET SPEED

38
Auto High Beams (AHB)
TOYOTA SAFETY SENSE
SWITCHING TO CONSTANT SPEED CONTROL MODE
The AHB uses an in-vehicle camera sensor to assess the brightness of str\
eetlights,
the lights of oncoming and preceding vehicles, etc., and automatically t\
urns high
beam on or off as necessary.
(3) Acceleration when there are no longer any preceding vehicles drivi\
ng
slower than the set speedThe system accelerates until the set speed is reached. The system then
returns to constant speed cruising.
Note: When your vehicle is too close to a vehicle ahead, and sufficient
automatic deceleration via the cruise control is not possible, the display will
flash and the buzzer will sound to alert the driver. An example of this would be
if another driver cuts in front of you while you are following a vehicle. Depress
the brake pedal to ensure an appropriate vehicle-to-vehicle distance.
Note: When the engine is turned off, it will automatically default to DR\
CC.
If you are already using DRCC “
”, push ON-OFF button to turn the system off
first, then push and hold ON-OFF button for at least 1.5 seconds to swit\
ch.
(1) (2)

39
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
ACTIVATING THE AHB SYSTEM
CONDITIONS WHERE AHB WILL TURN ON/OFF AUTOMATICALLY
When all of these conditions are met, high beams will be automatically t\
urned on
(after approximately 1 second):
• Vehicle speed is above approximately 25 mph (40 km/h).
• The area ahead of the vehicle is dark.
• There are no oncoming or preceding vehicles with headlights or tail\
lights
turned on.
If any of these conditions occur, the system is designed to automaticall\
y turn off
highbeams. • Vehicle speed drops below approximately 19 mph (30 km/h).
• The area ahead of the vehicle is not dark.
• Oncoming or preceding vehicles have headlights or tail lights
turned on.
• There are many streetlights on the road ahead.
(1) With the engine switch in IGNITION ON mode and headlight switch tu\
rned to
“AUTO” position, push lever away from you.
(2) Depress the Automatic High Beam “AUTO” switch. The AHB indicator will come on when the headlights are turned on automat\
ically
to indicate that the system is active.
Note: Pull the lever back toward you to turn the AHB system off.
The AHB indicator will turn off and the high beam indicator turns on.
