lock TOYOTA LAND CRUISER 2017 J200 Quick Reference Guide

OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY &
EMERGENCY FEATURES
1
INDEX
Engine maintenance 9
Fuel tank door release and cap 8
Hood release 8
Indicator symbols 4-5
Instrument cluster 4
Instrument panel 2-3
Keyless entry
1 6
Light control-Instrument panel 9
Smart Key system
1,2 7
1 Visit your Toyota dealer for information on customizing this feature.2 Programmable by customer. Refer to the Owner’s Manual for instructio\
ns and more information.3 HomeLink® is a registered trademark of Gentex Corporation.
OVERVIEW
FEATURES & OPERATIONS FEATURES & OPERATIONS (continued)
SAFETY & EMERGENCY FEATURES TOYOTA SAFETY SENSE
Automatic air
conditioning/heating
22-23
Audio 20-21
Auto lock/unlock
1 10
Automatic transmission 10
Cooler box 28
Crawl Control 24
Cup holders 28
Door-Back 21
Door locks 26
Doors-Power sliding 16
Four-wheel drive 11
Garage door opener (HomeLink
®)3 27
Lights1 & turn signals 17
Moon roof 19
Multi-Information Display (MID)
2 25
Multi-terrain Monitor 24
Parking brake 28
Power outlets-12V DC 28
Power outlet-120V AC 29
Qi wireless charger 29
Rear seat entertainment system 27
Rear view mirror-Outside 19
Seat adjustments-Front 12
Seat adjustments-Rear 12
Seat ventilators/heaters 23
Seats-Head restraints 12
Seats-Stowing 3rd row seats 15 Seats-Tumbling 2nd row seats 13
Seats-Tumbling 3rd row seats 14
Steering lock release
11
Telephone controls (Bluetooth
®) 26
Tilt & telescopic steering wheel 25
Windows-Power 18
Windshield wipers & washers 18
Doors-Child safety locks 41
Floor mat installation 43
Seat belts 40
Seat belts-Shoulder belt anchor 40
Spare tire & tools 41
Star Safety System
™ 42
Tire Pressure Monitoring
(warning) System (TPMS) 40
Auto High Beams (AHB) 38-39
Dynamic Radar
Cruise Control (DRCC) 36-38
Lane Departure Alert (LDA) 33-35
Pedestrian Detection Function 33
Pre-Collision System (PCS) 31-32
Quick overview-
Toyota Safety Sense P 30
Sensors 30
BLUETOOTH® DEVICE
PAIRING SECTION 44-53

2
OVERVIEWInstrument panel
Steering wheel controls
Steering wheel
audio switches2
Multi-Information
Display (MID) switches1
Dynamic Radar Cruise Control
(DRCC)/Cruise control Dynamic Radar Cruise
Control (DRCC)
vehicle-to-vehicle
distance button
Lane Departure
Alert (LDA) switch
Tilt and telescopic steering control switch
Headlight, turn signal & front fog light controls
Meters
Multi-Information Display (MID) Windshield wiper and washer controls
Multi-terrain monitor switch (VIEW)
2
Pre-Collision System (PCS) switch
Tire Pressure Monitoring
(warning) System reset switch
Hood lock release lever
Fuel tank door release lever
Power outside rear view mirror switches
Roll Sensing of Curtain
shield Airbag OFF switch
Automatic High Beam (AHB) switch
Intuitive parking assist switch
Headlight cleaner switch Talk switch
2
Telephone switches2

OVERVIEW
FEATURES/OPERATIONS
TOYOTA SAFETY SENSE
SAFETY AND EMERGENCY FEATURES
3
“ENGINE START STOP” button (Smart Key)
Audio/Navigation
2 system
Emergency flasher button
Air conditioning and heating controls
Front seat heater/ventilator switches
Heated steering wheel switch
USB/AUX port
Four-wheel drive
control switch
Crawl control
switch
Multi-terrain Select mode selector/
Crawl Control speed mode dial
Center differential lock/unlock switch
VSC OFF switch
Second start mode switch
POWER mode switch Turn Assist switch
Audio system
Shift lever
Parking brake
1 If equipped2 For details, refer to the “Navigation System Owner’s Manual” an\
d “2017 Entune™ Audio
Quick Reference Guide.”

OVERVIEW
FEATURES/OPERATIONS
TOYOTA SAFETY SENSE
SAFETY AND EMERGENCY FEATURES
5
Arrow direction indicates fuel
tank door position
Low fuel level warning
Brake system warning2
Anti-lock Brake System warning2
Parking brake indicator
Shift position and range indicators
Roll Sensing of Curtain shield
Airbag OFF indicator2
Automatic Transmission
second start indicator
Power mode indicator
Vehicle Stability Control OFF indicator
Slip indicator
Low speed four-wheel drive indicator
Center differential lock indicator
Crawl Control indicatoraVehicle Stability Control OFF indicator
Multi-terrain select indicator
ECO driving indicator2
Turn assist function indicator
TRAC OFF indicator
Headlight low/high beam indicator
Turn signal indicator
Fog light indicator
Automatic headlight leveling
system warning
1 If equipped.2
If indicator does not turn off within a few seconds of starting engine, \
there may be a malfunction.
Have vehicle inspected by your Toyota dealer.
AIR BAG ON-OFF indicatorCruise control indicator/
Cruise control SET indicator
Auto High Beam indicator
Pre-Collision System warning2
Blind Spot Monitor indicator2
Rear Cross Traffic
Alert indicator
Blind Spot Monitor outside rear
view mirror indicators2
Land Departure Alert indicator
Dynamic Radar Cruise Control
indicator

6
Keyless entry
OVERVIEW
NOTE: If a door is not opened within 30 seconds of unlocking, all doors will relock for
safety.
Push
ONCE: Driver door TWICE: All doors
Carry remote
Smart key feature
Carry remote
Smart key feature
Front door lock
Touch Carry remote
Smart key feature
Grasp
Front door unlock*
Push
Push and hold
* Driver door unlocking function can be programmed to unlock driver door\
only, or all doors.
NOTE: Doors may also be locked/unlocked using remote.
LockUnlock
LOCKING OPERATION
UNLOCKING OPERATION
PANIC BUTTON (IF EQUIPPED)
BACK DOOR LOCK/UNLOCK

10
Auto lock/unlock
Automatic transmission
Automatic door locks can be programmed to operate in four different mode\
s, or
turned OFF.
-Doors lock when shifting from Park.
-Doors lock when the vehicle speed is approximately 12 mph or higher.
-Doors unlock when shifting into Park.
-Doors unlock when the driver’s door is opened within 45 seconds after\
turning the “ENGINE START STOP” switch OFF. (Vehicles with a Smart Key system\
)
-Doors unlock when the driver’s door is opened within 45 seconds afte\
r turning the ignition switch to the “ACC” or “LOCK” position. (Vehic\
les without a Smart Key
system)
Refer to the Owner’s Manual for more details.
* The “ENGINE START STOP” switch/ignition switch must be “ON”\
and the brake pedal depressed to shift from Park.
Shift the shift lever to “S” position from “D” position.
+ : Upshift (push and release)
- : Downshift (pull and release)
Downshifting increases power going uphill, or provides engine braking do\
wnhill. For
best fuel economy during normal driving conditions, always drive with th\
e shift lever
in the “D” position.
Park*
Reverse
Neutral
Drive
P
R
N
D
S“S” mode
For powerful acceleration and driving in
mountainous regions.For starting on slippery surfaces, such as snowy
roads. Press “2nd” to return to normal mode.
POWER MODE SECOND GEAR START MODE
FEATURES & OPERATIONS
“S” (SEQUENTIAL) MODE

OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
11
Four-wheel drive
Steering lock release
Turn
Push
High speed
Low speed
Shift to “N” position when stopped, then push and turn to “L4.”\
H4
L4
Lock the center differential when your vehicle’s wheels get stuck in \
a ditch or when
driving on a slippery or bumpy surface.
Push
Turn
FOUR-WHEEL DRIVE CONTROL SWITCH
CENTER DIFFERENTIAL LOCK/UNLOCK SWITCH

12
Seat adjustments-Front
Seat adjustments-Rear
Seats-Head restraints
FEATURES & OPERATIONS
Seat positionSeatback angleLumbar support
(driver’s side only)
Seat position, cushion
angle and height Seatback angle
Refer to the Owner’s Manual for more details.
Second row
Third row (fold down)
Front Second rowThird row
Lock release button
Height
AngleLock release button
Height
Fold down
Lock release lever
Seatback angle

14
Seats-Tumbling 3rd row seats
FEATURES & OPERATIONS
Stow the seat belt buckles.Stow the center head restraint.
Hook the seat belt to the seat belt
hangers. Fold down the outer head restraints.
Fold the seats. Lift the seats sideward.
Lock the seats. Install the seat hook covers on the
seat hooks.
Install the seat hook covers into
the back of the seat cushions. Lower the seats to their
original
position.
(1)
(5)
(3)
(2)
(4)
Push
(6)
Pull
(7)(8)
Seat hook cover
Pull
Pull
Returning seats
(1)(2)

16
FEATURES & OPERATIONSDoors-Power sliding
(if equipped)
ON/OFF SWITCH
OPENING/CLOSING
Power
• Sliding doors will not fully open if the sliding door window is open.
• Power sliding doors will open only when gear selector is in the “P”\
(Park) position,
and doors are unlocked. Refer to the Owner’s Manual for more details.
• An alarm will sound if a sliding door is open and the vehicle is shifted\
out of Park.
• Left sliding door will not open if gas door is open.
• If battery is disconnected, the power sliding doors need to be reinitial\
ized.
Refer to the Owner’s Manual for more details.
Manual
• Sliding doors will not lock into the open position if the sliding door w\
indow is open.
Front overhead console Instrument panel
Push
Center pillar
On Off
Open: Push
Close: Push againOpen: Push
Close: Push again
