start stop button TOYOTA LAND CRUISER 2017 J200 Quick Reference Guide

OVERVIEW
FEATURES/OPERATIONS
TOYOTA SAFETY SENSE
SAFETY AND EMERGENCY FEATURES
3
“ENGINE START STOP” button (Smart Key)
Audio/Navigation
2 system
Emergency flasher button
Air conditioning and heating controls
Front seat heater/ventilator switches
Heated steering wheel switch
USB/AUX port
Four-wheel drive
control switch
Crawl control
switch
Multi-terrain Select mode selector/
Crawl Control speed mode dial
Center differential lock/unlock switch
VSC OFF switch
Second start mode switch
POWER mode switch Turn Assist switch
Audio system
Shift lever
Parking brake
1 If equipped2 For details, refer to the “Navigation System Owner’s Manual” an\
d “2017 Entune™ Audio
Quick Reference Guide.”

28
Parking brake
Cup holders
Cooler box
Power outlets-12V DC
FEATURES & OPERATIONS
Push “PWR” button to turn cooler box ON; indicator will illuminate\
.
Indicator
The “ENGINE START STOP” switch must be in “ACCESSORY” or “\
IGNITION ON”
mode to be used.
FrontRear
(2) Push
SetRelease
(1) Pull slightly
(3) Lower
Pull
FrontRear

29
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
Power outlets-120V AC
Qi wireless charger
The “ENGINE START STOP” switch must be in “IGNITION ON” mode\
to be used.
A portable device can be charged by just placing Qi standard wireless ch\
arge
compatible portable devices according to the Wireless Power Consortium, \
such as
smart phones and mobile batteries, etc., on the charge area.
This function cannot be used with portable devices that are larger than \
the
charging area. Also, depending on the portable device, it may not operat\
e as
normal. Please read the Owner’s Manual for portable devices to be used.
The power switch must be in ACCESSORY or ON mode.
(1)
Push to open door.Push power supply charging button.
Note: While device is charging, the light is orange. The light turns green when
it is finished.
Place charging side of device on the
charge area.
(2)
(3)
