four wheel drive TOYOTA LAND CRUISER 2018 Owners Manual (in English)

1
INDEX
Engine maintenance 9
Fuel tank door release and cap
8
Hood release
8
Indicator symbols
4-5
Instrument cluster
4
Instrument panel
2-3
Instrument panel light control
9
Keyless entry1 6
Smart Key system1,2 7
1 Visit your Toyota dealer for information on customizing this feature.2 Programmable by customer. Refer to the Owner’s Manual for instructio\
ns and more information.3 HomeLink® is a registered trademark of Gentex Corporation.
OVERVIEW
FEATURES & OPERATIONS FEATURES & OPERATIONS (continued)
SAFETY & EMERGENCY FEATURES TOYOTA SAFETY SENSE™ P (TSS-P)
Automatic air
conditioning/heating
22-23
Audio
20-21
Auto lock/unlock1 10
Automatic transmission
10
Back door
16
Cool box
28
Crawl Control
24
Cup holders
28
Door locks
16
Four-wheel drive
11
Garage door opener (HomeLink®)3 27
Lights1 & turn signals 17
Moonroof
19
Multi-Information Display (MID)2 25
Multi-terrain Monitor
24
Parking brake
28
Power back door
16
Power outlets-12V DC
28
Power outlet-120V AC
29
Qi wireless charger
29
Rear seat entertainment system
27
Rear view mirror-Outside
19
Seat adjustments-Front
12
Seat adjustments-Rear
12
Seat ventilators/heaters
23
Seats-Head restraints
12
Seats-Tumbling 2nd row seats
13 Seats-Tumbling 3rd row seats
14
Steering lock release
15
Telephone controls (Bluetooth®) 26
Tilt & telescopic steering wheel
15
Windows-Power
18
Windshield wipers & washers
18
Floor mat installation
43
Rear door child safety locks
41
Seat belts
40
Seat belts-Shoulder belt anchor
40
Spare tire & tools
41
Star Safety System™ 42
Tire Pressure Monitoring
(warning) System (TPMS)
40
Automatic High Beams (AHB) 38-39
Dynamic Radar
Cruise Control (DRCC)
36-38
Lane Departure Alert (LDA)
33-35
Pre-Collision System with Pedestrian
Detection function (PCS w/PD)
31-33
Quick overview-
Toyota Safety Sense P
30
Sensors
30
BLUETOOTH® DEVICE
PAIRING SECTION 44-53
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES

OVERVIEW
FEATURES/OPERATIONS
TOYOTA SAFETY SENSE
SAFETY AND EMERGENCY FEATURES
3
“ENGINE START STOP” button (Smart Key)
Audio/Navigation
2 system
Emergency flasher button
Air conditioning and heating controls
Front seat heater/ventilator switches
Heated steering wheel switch
USB/AUX port
Four-wheel drive
control switch
Crawl control
switch
Multi-terrain Select mode selector/
Crawl Control speed mode dial
Center differential lock/unlock switch
VSC OFF switch
Second start mode switch
POWER mode switch Turn Assist switch
Audio system
Shift lever
Parking brake
1 If equipped2 For details, refer to the “Navigation System Owner’s Manual” an\
d “2018 Entune™ Audio
Quick Reference Guide.”

OVERVIEW
FEATURES/OPERATIONS
TOYOTA SAFETY SENSE
SAFETY AND EMERGENCY FEATURES
5
Low fuel level warning
Parking brake indicator
Shift position and range indicators
Low Tire Pressure Warning2
Malfunction/Check Engine indicator2
Master warning2
Power mode indicator
Slip indicator2
Low speed four-wheel drive indicatorMulti-terrain select indicator
ECO driving indicator2
Turn assist function indicator
TRAC OFF indicator2
Turn signal indicator
Fog light indicator
1 If equipped.2 If indicator does not turn off within a few seconds of starting engine, \
there may be a malfunction.
Have vehicle inspected by your Toyota dealer.
Driver seat belt reminder
(alarm will sound if speed is over 12 mph)Open door warning
Front passenger seat belt reminder
(alarm will sound if speed is over 12 mph)
Pre-Collision System warning2
Lane Departure Alert indicator
Dynamic Radar Cruise Control
indicator
Headlight low/high beam
indicator
Vehicle Stability Control OFF
indicator2
Rear Cross Traffic Alert indicator

OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
11
Four-wheel drive
High speed
Low speed
Shift to “N” position when stopped, then push and turn to “L4.”\
H4
L4
Lock the center differential when your vehicle’s wheels get stuck in \
a ditch or when
driving on a slippery or bumpy surface.
Push
Turn
FOUR-WHEEL DRIVE CONTROL SWITCH
CENTER DIFFERENTIAL LOCK/UNLOCK SWITCH

42
Star Safety System™
SAFETY AND EMERGENCY FEATURES
Your vehicle comes standard with the Star Safety SystemTM, which combines Anti-
lock Brake System (ABS), Brake Assist (BA), Electronic Brake-force D\
istribution
(EBD), Smart Stop Technology (SST), Traction Control (TRAC) and Ve\
hicle Stability
Control (VSC).
Refer to the Owner’s Manual for more details and important information on limitations
to these systems.
VSC helps prevent loss of traction during cornering by reducing engine p\
ower and
applying brake force to selected wheels.
Toyota’s VSC monitors steering angle and the direction your vehicle i\
s traveling.
When it senses that the front or rear wheels begin to lose traction, VSC\
reduces
engine power and applies braking to selected wheels. This helps restore \
traction
and vehicle control.
VEHICLE STABILITY CONTROL (VSC)
Helps to maintain drive power and prevent the 4 wheels from spinning whe\
n starting
the vehicle or accelerating on slippery roads.
ACTIVE TRACTION CONTROL (A-TRAC)
Toyota’s ABS sensors detect which wheels are locking up and limits wh\
eel lockup
by “pulsing” each wheel’s brakes independently. Pulsing release\
s brake pressure
repeatedly for fractions of a second. This helps the tires attain the tr\
action that
current road conditions will allow, helping you to stay in directional c\
ontrol.
MULTI-TERRAIN ANTI-LOCK BRAKE SYSTEM (ABS)
Toyota’s ABS technology has Electronic Brake-force Distribution (EBD\
) to help
maintain stability and balance when braking. Abrupt stops cause the vehi\
cle to tilt
forward, reducing the braking power of the rear wheels. EBD responds to \
sudden
stops by redistributing brake force to maximize the braking effectivenes\
s of all four
wheels.
ELECTRONIC BRAKE FORCE DISTRIBUTION (EBD)
Brake Assist is designed to detect sudden or “panic” braking, and \
then add braking
pressure to decrease the vehicle’s stopping distance. When there’s\
only a split
second to react, Brake Assist can add additional brake pressure more qui\
ckly than
just the driver alone can.
BRAKE ASSIST (BA)
Smart Stop Technology automatically reduces engine power when the accele\
rator
and brake pedals are pressed simultaneously under certain conditions.
SST engages when the accelerator is depressed first and the brakes are a\
pplied
firmly for longer than one-half second at speeds greater than five miles\
per hour.
SST doesn’t engage if the brake pedal is depressed before the acceler\
ator pedal,
allowing vehicles to start on a steep hill and safely accelerate without\
rolling
backward.
SMART STOP TECHNOLOGY (SST)
