221. Basic information before operation
1When the engine switch is in ACCES-
SORY or IGNITION ON mode, the ini-
tial screen will be displayed and the
system will begin operating.
After a few seconds displays the initial
screen, the “CAUTION” screen will be dis-
played.
 After about 5 seconds, the “CAUTION”
screen automatically switches to the home
screen. (Select “Continue” or press the
“HOME” button to display the home
screen.)
1Press and hold the “PWR•VOL” knob
for 3 seconds or more.
Initial screen
 Images shown on the initial screen can
be changed to suit individual prefer-
ences. ( P.46)
WA R N I N G
● When the vehicle is stopped with the
engine running, always apply the park-
ing brake for safety.
Maintenance information
This system reminds users when to re-
place certain parts or components and
shows dealer information (if regis-
tered) on the screen.
When the vehicle reaches a previously
set driving distance or date specified
for a scheduled maintenance check,
the “Maintenance Reminder” screen
will be displayed when the navigation
system is turned on.
 This screen goes off if the screen is not
operated for several seconds.
 To prevent this screen from being dis-
played again, select “Do Not Display
This Message Again” .
 To register maintenance information:
P. 5 0
 If is selected, the registered
phone number can be called.
Restarting the system
When system response is extremely
slow, the system can be restarted.

LC200_Navi_OM60R69U_(U)
19.05.29 15:08
1624. Rear seat entertainment system operation
1Press the “OPTION” button if no icons
are shown while watching a DVD video
and this screen appears.
 When there are two pages, select “ ” or
“” to change the page.
■Searching by title
1Select “Search” .
2Enter the title number and select
“OK”.
The player starts playing video for that title
number.
Option screen
No.FunctionPage
Select to display the ini-
tial setup screen.163
Select to turn off the
icons from the screen.
Select to display the
menu screen for DVD
video. (For the opera-
tion, see the manual that
comes with the DVD vid-
eo disc provided sepa-
rately.)

Press and hold to rewind
during playback.
Select to stop the video.
Select to play/pause the
video screen.
Press and hold to fast
forward during playback
and play in slow motion
when the player is
paused.

Select to display the title
search screen.162
Select to display the pre-
determined scene on the
screen and start playing.

Select to display the au-
dio selection screen.163
Select to display the sub-
title selection screen.163
Select to display the an-
gle selection screen.163
INFORMATION
●If appears on the screen when a
control is selected, the operation
relevant to the control is not permitted.
No.FunctionPage
