TOYOTA LAND CRUISER 2021 Accessories, Audio & Navigation (in English)

LC200_Navi_OM60T11U_(U)
20.03.24 14:50
2211. Phone operation (Hands-free system for cellular phones)
Phone
7
1Press the switch on the steering
wheel to display the phone top screen.
2Press the switch on the steering
wheel to display the “Call History”
screen.
3Press the switch on the steering
wheel to call the latest history item.
4Check that the “Call” screen is dis-
played.
1Select or press the switch
on the steering wheel to talk on the
phone.
To refuse to receive the call : Select
or press the switch on the
steering wheel.
To adjust the volume of a received call :
Turn the “PWR·VOL” k n o b , o r u s e t h e v o l -
ume control switch on the steering wheel.
By off hook switch
Calls can be made using the latest call
history item.Receiving on the
Bluetooth® phone
Incoming calls
When a call is received, this screen is
displayed with a sound.
INFORMATION
● During international phone calls, the
other party’s name or number may not
be displayed correctly depending on the
type of cellular phone you have.
● The incoming call display mode can be
set. ( P.238)
● The ringtone that has been set in the
“Sound Settings” screen sounds when
there is an incoming call. Depending on
the type of Bluetooth
® phone, both the
navigation system and Bluetooth®
phone may sound simultaneously when
there is an incoming call. ( P.229)

LC200_Navi_OM60T11U_(U)
20.03.24 14:50
2221. Phone operation (Hands-free system for cellular phones)
■By dial pad
1Select “0-9”.
2Enter the desired number.
■By selecting “Release Tones”
1Select “Release Tones” .
Talking on the Bluetooth®
phone
While talking on the phone, this screen
is displayed. The operations outlined
below can be performed on this
screen.
No.FunctionPage
Select to display the dial
pad to send tones.222
Select to mute your voice
to the other party.
Select to change handset
modes between hands-
free and cellular phone.
Select to adjust your voice
volume that the other party
hears from their speaker.
223
Select to send tones. This
button only appears when
a number that contains a
(w) is dialed in hands-free
mode.
222
Select to hang up the
phone.
Select “+” or “-” to adjust
the volume of the other par-
ty’s voice.

Select to start talking with
the other party.223
INFORMATION
● Changing from hands-free call to cellular
phone call is not possible while driving.
● When cellular phone call is changed to
hands-free call, the hands-free screen
will be displayed and its functions can be
operated on the screen.
● Changing between cellular phone call
and hands-free call can be performed by
operating the cellular phone directly.
● Transferring methods and operations
will be different depending on the type of
cellular phone you have.
● For the operation of the cellular phone,
see the manual that comes with it.
Sending tones
This operation cannot be performed
while driving.
“Release Tones” appear when a con-
tinuous tone signal(s) containing a (w)
is registered in the contact list.
This operation can be performed while
driving.

LC200_Navi_OM60T11U_(U)
20.03.24 14:50
2231. Phone operation (Hands-free system for cellular phones)
Phone
7
1Select “Transmit Volume” .
2Select the desired level for the transmit
volume.
3Select “OK”.
1Select or press the switch
on the steering wheel to start talking
with the other party.
To refuse to receive the call : Select
or press the switch on the
steering wheel.
 Each time is selected or the
switch on the steering wheel is pressed
during an interrupted call, the party who is
on hold will be switched.
INFORMATION
● A continuous tone signal is a character
string that consists of numbers and the
characters p or w. (e.g.
056133w0123p#1 )
● When the “p” pause tone is used, the
tone data up until the next pause tone
will be automatically sent after 2 sec-
onds have elapsed. When the “w” pause
tone is used, the tone data up until the
next pause tone will be automatically
sent after a user operation is performed.
● Release tones can be used when auto-
mated operation of a phone based ser-
vice such as an answering machine or
bank phone service is desired. A phone
number with continuous tone signals
can be registered in the contact list.
● Tone data after a “w” pause tone can be
operated on voice command during a
call.
Transmit volume setting
INFORMATION
●The sound quality of the voice heard
from the other party’s speaker may be
negatively impacted.
● To reset the transmit volume, select
“Default” .
● “Transmit Volume” is dimmed when
mute is on.
Incoming call waiting
When a call is interrupted by a third
party while talking, this screen is dis-
played.
INFORMATION
● This function may not be available
depending on the type of cellular phone.

LC200_Navi_OM60T11U_(U)
20.03.24 14:50
2241. Phone operation (Hands-free system for cellular phones)
1Press the button.
2Select .
The phone top screen can be displayed by
pressing the
switch on the steering
wheel.
3Check that the message inbox screen
is displayed.
: Select to change to phone mode.Bluetooth® phone
message function
Received messages can be forwarded
from the connected Bluetooth
® phone,
enabling checking and replying using
the navigation system.
Depending on the type of Bluetooth
®
phone connected, received messages
may not be transferred to the message
inbox.
If the phone does not support the mes-
sage function, this function cannot be
used.
FunctionPage
Receiving a message224
Checking messages225
Replying to a message (quick re-
ply)226
Calling the message sender227
Message settings237
Receiving a message
When an e-mail/SMS/MMS is re-
ceived, the incoming message screen
pops up with sound and is ready to be
operated on the screen.
No.Function
Select to check the message.
Select to not open the message.
Select to call the message sender.

LC200_Navi_OM60T11U_(U)
20.03.24 14:50
2251. Phone operation (Hands-free system for cellular phones)
Phone
71Display the message inbox screen.
(P.224)
2Select the desired message from the
list.
3Check that the message is displayed.
INFORMATION
●Depending on the cellular phone used
for receiving messages, or its registra-
tion status with the navigation system,
some information may not be displayed.
● The pop up screen is separately avail-
able for incoming e-mail and SMS/MMS
messages under the following condi-
tions:
E-mail:
• “Incoming E-mail Display” is set to “Full
Screen”. ( P.237)
• “E-mail Notification Popup” is set to on. ( P.237)
SMS/MMS:
• “Incoming SMS/MMS Display” is set to
“Full screen”. ( P.237)
• “SMS/MMS Notification Popup” is set to on. ( P.237)
Checking messages
No.Function
Select “Mark Unread” or “Mark
Read” to mark mail unread or read
on the message inbox screen.
This function is available when “Up-
date Message Read Status on
Phone” is set to on. ( P.237)
Select to reply the message.
( P.226)
Select to display the previous or
next message.
Select to have messages read out.
To cancel this function, select
“Stop” .
When “Automatic Message Read-
out” is set to on, messages will be
automatically read out. ( P.237)
Select to make a call to the sender.
INFORMATION
● Reading a text message is not available
while driving.
● Depending on the type of Bluetooth
®
phone being connected, it may be
necessary to perform additional steps on
the phone.
● Messages are displayed in the
appropriate connected Bluetooth
®
phone’s registered mail address folder.
Select the tab of the desired folder to be
displayed.
● Only received messages on the
connected Bluetooth
® phone can be
displayed.
● The text of the message is not displayed
while driving.
● Turn the “PWR·VOL” knob, or use the
volume control switch on the steering
wheel to adjust the message read out
volume.

LC200_Navi_OM60T11U_(U)
20.03.24 14:50
2261. Phone operation (Hands-free system for cellular phones)
1Display the message inbox screen.
(P.224)
2Select the desired message from the
list.
3Select “Quick Msg” .
4Select the desired message.
5Select “Send” .
While the message is being sent, a send-
ing message screen is displayed.
 To cancel sending the message, select
“Cancel” .
6Check that a confirmation screen is
displayed when the operation is com-
plete.
If an error message is displayed, follow
the guidance on the screen to try again.
■Editing quick reply messages
1Select “Quick Msg” .
2Select corresponding to the de-
sired message to edit.
3Select “OK” when editing is complet-
ed.
Replying to a message (Quick
reply)
15 messages have already been
stored.
INFORMATION
● Depending on the type of Bluetooth®
phone, the reply function may not be
available.
This operation cannot be performed
while driving.

LC200_Navi_OM60T11U_(U)
20.03.24 14:50
2271. Phone operation (Hands-free system for cellular phones)
Phone
7
■Calling from e-mail/SMS/MMS mes-
sage display
1Display the message inbox screen.
(P.224)
2Select the desired message.
3Select .
If there are 2 or more phone numbers,
select the desired number.
4Check that the “Call” screen is dis-
played.
■Calling from a number within a
message
1Display the message inbox screen.
(P.224)
2Select the desired message.
3Select the text area.
4Select the desired number.
Identified phone numbers contained in the
message are displayed.
5Check that the “Call” screen is dis-
played.
■Calling from the incoming message
screen
P.224
INFORMATION
● To reset the edited quick reply
messages, select “Default”.
● “Quick Message 1” (“I am driving and
will arrive in approximately [ETA]
minutes.”) :
This message cannot be edited and will
automatically fill in [ETA] with the
navigation calculated estimated time of
arrival on the confirm message screen.
If there are waypoints set, [ETA] to the
next waypoint will be shown.
If there is no route currently set in the
navigation system, “Quick Message 1”
cannot be selected.
Calling the message sender
Calls can be made to an e-mail/SMS/
MMS message sender’s phone num-
ber.
This operation can be performed while
driving.
Calls can be made to a number identi-
fied in a message’s text area.
This operation cannot be performed
while driving.
INFORMATION
● A series of numbers may be recognized
as a phone number. Additionally, some
phone numbers may not be recognized,
such as those for other countries.

LC200_Navi_OM60T11U_(U)
20.03.24 14:50
2282. Setup
1Press the “SETUP” button.
2Select “Phone” .
3Select the item to be set.
1Display the phone top screen.
(P.217)
2Select “Settings” .
Phone/message settingsPhone/message settings screen
No.InformationPage
Registering/connecting a
phone 36
Sound settings229
Contact/call history set-
tings230
Messaging settings237
Phone display settings238
Displaying the phone/message
settings screen in a different
way

LC200_Navi_OM60T11U_(U)
20.03.24 14:50
2292. Setup
Phone
7
1Display the “Phone/Message Settings”
screen. (P.228)
2Select “Sound Settings” .
3Select the desired item to be set.
“Sound Settings” screen
The call and ringtone volume can be
adjusted. A ringtone can be selected.No.Function
Select to set the desired ringtone.
Select “-” or “+” to adjust the ring-
tone volume.
Select “-” or “+” to adjust the mes-
sage readout volume.
Select to set the desired incoming
SMS/MMS tone.
Select “-” or “+” to adjust the in-
coming SMS/MMS tone volume.
Select to set the desired incoming e-
mail tone.
Select “-” or “+” to adjust the in-
coming e-mail tone volume.
Select “-” or “+” to adjust the de-
fault volume of the other party’s
voice.
Select to reset all setup items.
INFORMATION
● Depending on the type of phone, certain
functions may not be available.

LC200_Navi_OM60T11U_(U)
20.03.24 14:50
2302. Setup
1Display the “Phone/Message Settings”
screen. (P.228)
2Select “Contact/Call History
Settings” .
3Select the desired item to be set.
*: For PBAP compatible Bluetooth
®
phones, this function is available when
“Automatic Contact/History Transfer” is
set to off. (P.230)
“Contact/Call History Settings”
screen
The contact can be transferred from a
Bluetooth
® phone to the system. The
contact also can be added, edited and
deleted.
The call history can be deleted and
contact and favorites can be changed.
No.FunctionPage
For PBAP compatible
Bluetooth® phones, select
to set automatic contact/
history transfer on/off.
When set to on, the
phone’s contact data and
history are automatically
transferred.

Select to update contacts
from the connected phone.231
Select to sort contacts by
the first name or last name
field.

Select to add contacts to
the favorites list. 235
Select to delete contacts
from the favorites list. 236
Select to set the trans-
ferred contact image dis-
play on/off.

*Select to clear contacts
from the call history.
*Select to add new contacts
to the contact list.232
*Select to edit contacts in
the contact list.233
*Select to delete contacts
from the contact list.234
Select to reset all setup
items.
INFORMATION
● Depending on the type of phone, certain
functions may not be available.
● Contact data is managed independently
for every registered phone. When one
phone is connected, another phone’s
registered data cannot be read.
