330 4-3. Do-it-yourself maintenance
13 HTR-IG 10 AAir conditioning system, rear win-
dow defogger
14 WIPER 25 A Windshield wipers
15 RR WIPER 15 A Rear window wiper
16 WASHER 15 A Windshield washer
17 ECU-IG NO. 1 10 AMain body ECU, electric power
steering, electric cooling fan(s),
shift lock control system, anti-lock
brake system, multiport fuel injec-
tion system/sequential multiport
fuel injection system, tire pressure
warning system, vehicle stability
control system
18 ECU-IG NO. 2 10 ABack-up lights, charging system,
rear window defogger
19 OBD 7.5 A On-board diagnosis system
20 STOP 10 AStop lights, high mounted stop-
light, anti-lock brake system, vehi-
cle stability control system,
multiport fuel injection system/
sequential multiport fuel injection
system, shift lock control system
21 DOOR 25 A Power door lock system
22 ACC-B 25 A CIG, ACC
23 4WD 7.5 A All wheel drive system
24 FR FOG 15 A Front fog lights
25 AM1 7.5 AStarting system, shift lock control
system, ACC, CIG
26 DEF 30 ARear window defogger, MIR HTR,
multiport fuel injection system/
sequential multiport fuel injection
system
27 POWER 30 A Power windows
FuseAmpereCircuit
