233 3-3. Using the hands-free phone system (for cellular phone)
3
Interior features
Inputting a phone number by using
STEP2-1 Select “Manual Input” by using .
STEP2-2 Input a phone number by using , and press
once again.
Input the phone number 1 digit at a time.
Selecting a phone number from outgoing or incoming call history
STEP2-1 Select “Call History” by using a voice command or
.
STEP2-2 Select “Outgoing” or “Incoming” by using a voice
command or .
STEP2-3 Select the data to be registered by either of the fol-
lowing methods:
a. Say “Previous” or “Go back” until the desired data
is displayed, and select “Confirm” by using a
voice command.
b. Select the desired data by using .

252
3-6. Other interior features
Clock
■The clock is displayed when
The engine switch is in the “ACC” or “ON” position.
Adjusts the hour.
Adjusts the minutes.
Rounds to the nearest
hour.*
*: e.g. 1:00 to 1:29  1:00
1:30 to 1:59  2:00

268
3-6. Other interior features
Compass
The compass on the inside rear view mirror indicates the direction in
which the vehicle is heading.
■Operation
To turn the compass on or off,
press and hold “AUTO” for 3
seconds.
■Displays and directions
DisplayDirection
NNorth
NE Northeast
EEast
SE Southeast
S South
SW Southwest
WWest
NW Northwest

: If equipped

269 3-6. Other interior features
3
Interior features
Calibrating the compass
The direction display deviates from the true direction determined by
the earth’s magnetic field. The amount of deviation varies according
to the geographic position of the vehicle.
If you cross over a map boundary shown in the illustration, the compass
will deviate.
To obtain higher precision or perfect calibration, refer to the following.
■Deviation calibration
Stop the vehicle in a place where it is safe to drive in a circle.
Press and hold “AUTO” for 6
seconds.
A number (1 to 15) appears on
the compass display.
Press “AUTO” and, referring to the map above, select the
number of the zone where you are.
If the direction is displayed several seconds after adjustment, the
calibration is complete.
STEP1
STEP2
STEP3

270 3-6. Other interior features
■Circling calibration
Stop the vehicle in a place where it is safe to drive in a circle.
Press and hold “AUTO” for 9
seconds.
C appears on the compass dis-
play.
Drive the vehicle at 5 mph (8
km/h) or less in a circle until a
direction is displayed.
If there is not enough space to
drive in a circle, drive around the
block until the direction is dis-
played.
STEP1
STEP2
STEP3
■Conditions unfavorable for correct operation
The compass may not show the correct direction in the following situations:
●The vehicle is stopped immediately after turning.
●The vehicle is on an inclined surface.
●The vehicle is in a place where the earth's magnetic field is subject to
interference by artificial magnetic fields (underground car park/parking
lot, under a steel tower, between buildings, roof car park/parking lot, near
an intersection, near a large vehicle, etc.).
●The vehicle has become magnetized.
(There is a magnet or metal object near the anti-glare inside rear view
mirror.)
●The battery has been disconnected.
●A door is open.

271 3-6. Other interior features
3
Interior features
CAUTION
■While driving the vehicle
Do not adjust the display. Be sure to adjust the display only when the vehicle
is stopped.
■When doing the circling calibration
Be sure to secure a wide space, and watch out for people and vehicles in the
neighborhood. Do not violate any local traffic rules while performing circling
calibration.
NOTICE
■To avoid compass malfunctions
Do not place magnets or any metal objects near the anti-glare inside rear
view mirror.
Doing this may cause a malfunction of the compass sensor.
■To ensure normal operation of the compass
●Do not perform circling calibration of the compass in a place where the
earth's magnetic field is subject to interference by artificial magnetic fields.
●During calibration, do not operate electric systems (moon roof, power win-
dows, etc.) as they may interfere with the calibration.

298 4-3. Do-it-yourself maintenance
■Engine oil consumption
●The amount of engine oil consumed depends on the oil viscosity, the
quality of the oil and the way the vehicle is driven.
●More oil is consumed under driving conditions such as high speeds and
frequent acceleration and deceleration.
●A new engine consumes more oil.
●When judging the amount of oil consumption, keep in mind that the oil
may have become diluted, making it difficult to judge the true level accu-
rately.
●Oil consumption: Max. 1.1 qt./600 miles, 0.9 Imp. qt./600 miles (1.0 L per
1000 km)
●If you consume more than 1.1 qt. (1.0 L, 0.9 Imp. qt.) every 600 miles
(1000 km), contact your Toyota dealer.
■After changing the engine oil (U.S.A. only)
The oil change system should be reset. Perform the following procedures:
Turn the engine switch OFF with the trip meter A reading shown.
While pressing the trip meter reset button (P. 126), turn the
engine switch to the “ON” position.
Continue to press and hold the button until the trip meter displays
000000.
CAUTION
■Used engine oil
●Used engine oil contains potentially harmful contaminants which may
cause skin disorders such as inflammation or skin cancer, so care should
be taken to avoid prolonged and repeated contact. To remove used engine
oil from your skin, wash thoroughly with soap and water.
●Dispose of used oil and filters only in a safe and acceptable manner. Do
not dispose of used oil and filters in household trash, in sewers or onto the
ground. Call your Toyota dealer, service station or auto parts store for
information concerning recycling or disposal.
●Do not leave used engine oil within the reach of children.
STEP1
STEP2
STEP3

439 Alphabetical index
Daytime running light
system ................................... 133
Defogger
Rear window......................... 174
Side mirror ............................ 174
Dimension ................................ 396
Dinghy towing .................. 163,164
Display
Trip meter ............................. 126
Do-it-yourself maintenance .... 285
Doors
Door glasses .......................... 56
Door lock .......................... 26, 29
Side mirrors ............................ 54
Driver's seat belt reminder
light ........................................ 362
Driving
Break-in tips ......................... 104
Correct posture....................... 68
Procedures ........................... 102
Winter driving tips ................. 151
Electric power steering........... 142
Emergency flashers
Switch ................................... 348
Emergency, in case of
If a warning light turns on ..... 359
If the engine will not start...... 383
If the shift lever cannot be
shifted from P ..................... 384
If the vehicle has a
discharged battery ............. 386
If the warning buzzer
sounds ............................... 359If you have a flat tire .............369
If you lose your keys .............385
If you think something is
wrong ..................................355
If your vehicle becomes
stuck ...................................394
If your vehicle needs to be
towed ..................................349
If your vehicle overheats .......391
Engine
Compartment ........................294
Engine switch ........................112
Hood......................................289
How to start the
engine .................................112
Identification number .............397
If the engine will not start ......383
Ignition switch........................112
Overheating...........................391
Engine coolant
Capacity ................................403
Checking ...............................300
Preparing and checking before
winter ..................................151
Engine coolant temperature
gauge ......................................126
Engine immobilizer system.......65
Engine oil
Capacity ................................401
Checking ...............................296
Preparing and checking before
winter ..................................151
Engine oil maintenance
data .........................................298
EPS ............................................142
Event data recorder .................357D
E

442 Alphabetical index
Noise from under vehicle ..........18
Odometer .................................. 126
Oil
Engine oil .............................. 296
Opener
Fuel filler door .........................61
Hood...................................... 289
Outside rear view mirrors
Adjusting and folding ...............54
Outside temperature
display .................................... 126
Overheating, Engine ................391
Parking brake ........................... 124
Parking lights
Replacing light bulb ............... 337
Switch.................................... 132
Wattage ................................. 411
Personal lights
Switch............................ 240, 241
Wattage ................................. 411
Power outlet ............................. 255
Power windows ..........................56Radiator .................................... 301
Radio ......................................... 178
Rear seats
Folding down........................... 41
Rear side marker lights
Replacing light bulb............... 337
Switch ................................... 132
Wattage................................. 411
Rear turn signal lights
Replacing light bulbs ............. 337
Switch ................................... 123
Wattage................................. 411
Rear view mirror
Compass ............................... 268
Rear window defogger ............ 174
Rear window wiper .................. 138
Replacing
Fuses .................................... 328
Key battery ............................ 325
Light bulbs............................. 337
Tires ...................................... 369
Reporting safety defects for
U.S.A. owners ........................ 432N
