engine TOYOTA MATRIX 2011 E140 / 2.G Owners Manual

457
6-1. Specifications
6
Vehicle specifications
Fuel infor mation
■Fuel tank opening for unleaded gasoline
To help prevent incorrect fueling, your Toyota has a fuel tank opening that
only accommodates the special nozzle on unleaded fuel pumps.
■If your engine knocks
●Consult your Toyota dealer.
●You may occasionally notice light knocking for a short time while acceler-
ating or driving uphill. This is normal and there is no need for concern.
■Gasoline quality
In very few cases, driveability problems may be caused by the brand of gas-
oline you are using. If driveability problems persist, try changing the brand of
gasoline. If this does not correct the problem, consult your Toyota dealer.
■Gasoline quality standards
●Automotive manufacturers in the U.S., the Europe and Japan have
developed a specification for fuel quality called World-Wide Fuel Charter
(WWFC) that is expected to be applied worldwide.
●The WWFC consists of four categories that are based on required emis-
sion levels. In the U.S., category 4 has been adopted.
●The WWFC improves air quality by lowering emissions in vehicle fleets,
and improves customer satisfaction through better performance.
Your vehicle must use only unleaded gasoline.
Select octane rating 87 (Research Octane Number 91) or higher. Use
of unleaded gasoline with an octane rating lower than 87 may result
in engine knocking. Persistent knocking can lead to engine damage.
At minimum, the gasoline you use should meet the specifications
of ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada.

458 6-1. Specifications
■Toyota recommends the use of gasoline containing detergent additives
●Toyota recommends the use of gasoline that contains detergent additives
to avoid build-up of engine deposits.
●All gasoline sold in the U.S. contains detergent additives to clean and/or
keep clean intake systems.
■Toyota recommends the use of cleaner burning gasoline
Cleaner burning gasoline, including reformulated gasoline that contains oxy-
genates such as ethanol or MTBE (Methyl Tertiary Butyl Ether) is available in
many areas.
Toyota recommends the use of cleaner burning gasoline and appropriately
blended reformulated gasoline. These types of gasoline provide excellent
vehicle performance, reduce vehicle emissions and improve air quality.
■Toyota does not recommend blended gasoline
●Toyota allows the use of oxygenate blended gasoline where the oxygen-
ate content is up to 10% ethanol or 15% MTBE.
●If you use gasohol in your Toyota, be sure that it has an octane rating no
lower than 87.
●Toyota does not recommend the use of gasoline containing methanol.
■Toyota does not recommend gasoline containing MMT
Some gasoline contains octane enhancing additive called MMT (Methylcy-
clopentadienyl Manganese Tricarbonyl).
Toyota does not recommend the use of gasoline that contains MMT. If fuel
containing MMT is used, your emission control system may be adversely
affected.
The malfunction indicator lamp on the instrument cluster may come on. If
this happens, contact your Toyota dealer for service.

459 6-1. Specifications
6
Vehicle specifications
NOTICE
■Notice on fuel quality
●Do not use improper fuels. If improper fuels are used the engine will be
damaged.
●Do not use leaded gasoline.
Leaded gasoline can cause damage to your vehicle’s catalytic converters
causing the emission control system to malfunction.
●Do not use gasohol other than that stated here.
Other gasohol may cause fuel system damage or vehicle performance
problems.
●Using unleaded gasoline with an octane number or rating lower than that
stated here will cause persistent heavy knocking.
At worst, this will lead to engine damage.
■Fuel-related poor driveability
If after using a different type of fuel, poor driveability is encountered (poor
hot starting, vaporization, engine knocking, etc.), discontinue the use of that
type of fuel.
■When refueling with gasohol
Take care not to spill gasohol. It can damage your vehicle's paint.

466 6-1. Specifications
Warning: The temperature grades for this tire are established for a
tire that is properly inflated and not overloaded.
Excessive speed, underinflation, or excessive loading, either sepa-
rately or in combination, can cause heat buildup and possible tire fail-
ure.
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sureTire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressureThe maximum cold inflated pressure to which a
tire may be inflated, shown on the sidewall of
the tire
Recommended infla-
tion pressureCold tire inflation pressure recommended by a
manufacturer
Accessory weightThe combined weight (in excess of those stan-
dard items which may be replaced) of auto-
matic transmission, power steering, power
brakes, power windows, power seats, radio
and heater, to the extent that these items are
available as factory-installed equipment
(whether installed or not)
Curb weightThe weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded vehi-
cle weightThe sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight

473 6-2. Customization
6
Vehicle specifications
Door lock
(vehicles
with power
door lock
system)
(
P. 2 9 )Unlocking using a keyDriver's door
unlocked in one
step, all doors
unlocked in two
stepsAll doors
unlocked in one
step
Opening driver's door
unlocks all doorsOff On
Shifting gears to P
unlocks all doors. (vehi-
cles with an automatic
transmission)On Off
Shifting gears to posi-
tion other than P locks
all doors. (vehicles with
an automatic transmis-
sion)On Off
Illumination
(
P. 282)Time elapsed before
lights turn off15 seconds7.5 seconds
30 seconds
Operation when the
doors are unlocked
(vehicles with power
door lock system)On Off
Operation after the
engine switch is turned
to the “LOCK” positionOn Off
Seat belt
reminder
(
P. 404)Vehicle speed linked
seat belt reminder
buzzerOn Off
ItemFunctionDefault settingCustomized
setting

491 Alphabetical index
Child-protectors ........................ 30
Cleaning
Exterior ................................. 316
Interior .................................. 319
Seat belts ............................. 320
Clock ........................................ 295
Compass .................................. 311
Condenser ............................... 344
Console box............................. 287
Cooling system
Engine overheating .............. 433
Cruise control .......................... 141
Cup holder ............................... 288
Curtain shield airbags .............. 71
Customizable features ............ 472
Daytime running light
system ................................... 136
Defogger
Rear window......................... 179
Side mirror ............................ 179
Dimension ................................ 442
Dinghy towing .................. 167,168
Display
Trip meter ............................. 129
Do-it-yourself maintenance .... 328
Doors
Door lock .......................... 26, 29
Door windows ......................... 57
Side mirrors ............................ 55
Driver's seat belt reminder
light ........................................ 404Driving
Break-in tips ..........................106
Correct posture .......................69
Procedures ............................104
Winter driving tips..................154
Electric power steering ...........145
Emergency flashers
Switch....................................390
Emergency, in case of
If a warning light turns on ......401
If the engine will not start ......425
If the shift lever cannot be
shifted from P......................426
If the vehicle has a
discharged battery ..............428
If the warning buzzer
sounds ................................401
If you have a flat tire .............411
If you lose your keys .............427
If you think something is
wrong ..................................397
If your vehicle becomes
stuck ...................................436
If your vehicle has to be
stopped in an emergency ...438
If your vehicle needs to be
towed ..................................391
If your vehicle overheats .......433
D
E

492 Alphabetical index
Engine
Compartment ........................ 337
Engine switch ........................ 115
Hood...................................... 332
How to start the
engine ................................. 115
Identification number ............. 443
If the engine will not start ...... 425
Ignition switch........................ 115
Overheating........................... 433
Engine coolant
Capacity ................................ 449
Checking ............................... 343
Preparing and checking
before winter ....................... 154
Engine coolant temperature
gauge ...................................... 129
Engine immobilizer system.......66
Engine oil
Capacity ................................ 447
Checking ............................... 339
Preparing and checking
before winter ....................... 154
Engine oil maintenance
data ......................................... 341
EPS ............................................ 145
Event data recorder ................. 399Floor mat .................................. 303
Fluid
Brake..................................... 345
Washer.................................. 349
Fog lights
Replacing light bulbs ............. 380
Switch ................................... 137
Wattage................................. 456
Front passenger occupant
classification system .............. 83
Front passenger's seat belt
reminder light ........................ 404
Front seats
Adjustment .............................. 38
Front side marker lights
Replacing light bulbs ............. 380
Switch ................................... 135
Wattage................................. 456
Front turn signal lights
Replacing light bulbs ............. 380
Switch ................................... 126
Wattage................................. 456
Fuel
Capacity ................................ 446
Fuel gauge ............................ 129
Fuel pump shut off system .... 398
Gas station information ......... 500
Information ............................ 457
Refueling ................................. 62
Type ...................................... 446F

493 Alphabetical index
Fuel door .................................... 62
Fuel filler door ........................... 62
Fuel pump shut off system .... 398
Fuses ........................................ 371
Gas station information .......... 500
Gauges ..................................... 129
Glove box ................................. 287
Grocery bag hooks ................. 300
Hands-free phone system
(for cellular phone) ............... 247
Hazard lights
Switch ................................... 390
Head restraints
Adjusting ................................ 44
Headlights
Replacing light bulbs ............ 380
Switch ................................... 135
Wattage ................................ 456
Heaters
Side mirror ............................ 179
Hood ......................................... 332
Hooks
Cargo hooks ......................... 304
Grocery bag hooks ............... 300
Horn .......................................... 128I/M test.......................................327
Identification number
Engine ...................................443
Vehicle ..................................443
Ignition switch ..........................115
Illuminated entry system .........283
Indicator lights .........................132
Initialization
Items to initialize....................474
Inside rear view mirror ..............53
Interior lights
Interior lights..........................282
Switch....................................283
Wattage .................................456
Jack
Positioning a floor jack ..........334
Vehicle-equipped jack ...........411
Jack handle ..............................411
Keyless entry..............................26
Keys
Engine switch ........................115
If you lose your keys .............427
Ignition switch........................115
Key number .............................24
Keyless entry...........................26
Keys ........................................24
Wireless remote control key ....26
G
H
I
J
K

494 Alphabetical index
License plate lights
Replacing light bulbs ............. 380
Switch.................................... 135
Wattage ................................. 456
Light bulbs
Replacing .............................. 380
Wattage ................................. 456
Lights
Emergency flasher switch ..... 390
Fog light switch ..................... 137
Hazard light switch ................390
Headlights switch .................. 135
Interior light switch ................283
Personal light switch ..... 284, 285
Replacing light bulbs ............. 380
Turn signal lever.................... 126
Wattage ................................. 456
Load capacity ........................... 153
Lock steering column .............. 117
Maintenance
Do-it-yourself
maintenance ....................... 328
General maintenance ............ 324
Maintenance data.................. 442
Maintenance requirements.... 322
Manual transmission
Manual transmission ............. 124
Meter
Instrument panel light
control ................................. 131
Meters ................................... 129Mirrors
Inside rear view mirror ............ 53
Side mirror heater ................. 179
Side mirrors............................. 55
Vanity mirrors ........................ 294
Moon roof ................................... 59
MP3 disc ................................... 197
Noise from under vehicle .......... 18
Odometer .................................. 129
Oil
Engine oil .............................. 339
Opener
Fuel filler door ......................... 62
Hood ..................................... 332
Outside rear view mirrors
Adjusting and folding............... 55
Outside temperature
display .................................... 129
Overheating, Engine ................ 433
Parking brake ........................... 127
Parking lights
Replacing light bulb............... 380
Switch ................................... 135
Wattage................................. 456
Personal lights
Switch ........................... 284, 285
Wattage................................. 456
Power outlet ............................. 298
Power windows .......................... 57L
M
N
O
P

496 Alphabetical index
Side marker lights
Replacing light bulbs ............. 380
Switch.................................... 135
Wattage ................................. 456
Side mirror
Adjusting .................................55
Spare tire
Inflation pressure................... 360
Storage location .................... 411
Spark plug ................................ 449
Specifications........................... 442
Speedometer ............................ 129
Steering
Column lock release.............. 117
Steering wheel
Adjustment ..............................52
Audio switches ...................... 227
Stop lights
Replacing light bulbs ............. 380
Wattage ................................. 456
Storage feature......................... 286
Storage precautions ................150
Stuck
If your vehicle becomes
stuck ................................... 436
Sun visors................................. 293
Sunshade
Roof.........................................60
Switch
Emergency flasher switch ..... 390
Engine switch ........................ 115
Fog light switch ..................... 137
Hazard light switch ................390
Ignition switch........................ 115
Light switches........................ 135
Power door lock switch ...........29
Power window switch ..............57
Window lock switch .................57
Wiper and washer switch ...... 138Tachometer .............................. 129
Tail lights
Replacing light bulbs ............. 380
Switch ................................... 135
Wattage................................. 456
Talk switch ............................... 253
Telephone switch..................... 253
Theft deterrent system
Engine immobilizer system ..... 66
Theft prevention labels ............. 68
Tie-down belts.......................... 304
Tire inflation pressure ............. 360
Tire information
Glossary ................................ 466
Size ....................................... 463
Tire identification number...... 462
Uniform tire quality
grading................................ 464
Tires
Chains ................................... 154
Checking ............................... 351
If you have a flat tire.............. 411
Inflation pressure .................. 360
Inflation pressure sensor....... 352
Replacing .............................. 411
Rotating tires ......................... 351
Size ....................................... 454
Snow tires ............................. 154
Spare tire .............................. 411
Tonneau cover ......................... 306
Tools ......................................... 411
Total load capacity .................. 153
Towing
Dinghy towing ............... 167, 168
Trailer towing ................ 158, 159T
