TOYOTA MATRIX 2011 E140 / 2.G Owners Manual

251 3-4. Using the hands-free phone system (for cellular phone)
3
Interior features
NOTICE
■To prevent damage to a cellular phone
Do not leave a cellular phone in the vehicle. The temperature inside may
become high resulting in damage to the phone.

252
3-4. Using the hands-free phone system (for cellular phone)
Using the hands-free phone system (for cellular phone)
■Audio unit
Display
A message, name, phone
number, etc. is displayed.
Lower-case characters and
special characters, such as
an umlaut, cannot be dis-
played.
Selects speed dials
Selects items such as menu
or number
Turn: Selects an item
Press: Inputs the selected
item
Bluetooth
® connection con-
dition and reception level
If “BT” is not displayed, the
hands-free phone system
cannot be used.
: If equipped

253 3-4. Using the hands-free phone system (for cellular phone)
3
Interior features
■Steering wheel telephone switches
Vo l u m e
The voice guidance volume
cannot be adjusted using this
button.
Off-hook switch
Turns the hands-free sys-
tem on/starts a call
On-hook switch
Turns the hands-free sys-
tem off/ends a call/refuses a
call
Talk switch
Turns the voice command
system on (press)/turns the
voice command system off
(press and hold)

254 3-4. Using the hands-free phone system (for cellular phone)
■Microphone
Vehicles with moon roof
Vehicles without moon roof

255 3-4. Using the hands-free phone system (for cellular phone)
3
Interior features
Operating the system using a voice command
By following voice guidance instructions output from the speaker,
voice commands enable the operation of the hands-free phone sys-
tem without the need to check the display or operate .
■Operation procedure when using a voice command
Press the talk switch and follow voice guidance instructions.
■Auxiliary commands when using a voice command
The following auxiliary commands can be used when operating the
system using a voice command:
“Cancel”: Exits the hands-free phone system
“Repeat”: Repeats the previous voice guidance instruction
“Go back”: Returns to the previous procedure
“Help”: Reads aloud the function summary if a help comment is
registered for the selected function

256 3-4. Using the hands-free phone system (for cellular phone)
Using the hands-free phone system for the first time
Before using the hands-free phone system, it is necessary to register
a cellular phone in the system. The phone registration mode will be
entered automatically when starting the system with no cellular
phone registered. Follow the procedure below to register a cellular
phone:
Press the off-hook switch or the talk switch.
The introductory guidance and phone name registration instructions
are heard.
Select “Pair Phone” using a voice command or .
Register a phone name by either of the following methods.
a. Select “Record Name” using , and say a name to be
registered.
b. Press the talk switch and say a name to be registered.
Voice guidance instruction to confirm the input is heard.
Select “Confirm” using a voice command or .
STEP1
STEP2
STEP3
STEP4

257 3-4. Using the hands-free phone system (for cellular phone)
3
Interior features
Registration to the hands-free phone system only
Select “Phone Only” using a voice command or .
Registration to the hands-free phone system and Bluetooth
® audio
system at the same time
Select “Int. Audio (Internal audio)” using a voice command or
.
Select “Confirm” using a voice command or .
A passkey is displayed and heard, and a voice guidance instruction
for inputting the passkey into the cellular phone is heard.
Input the passkey into the cellular phone.
Refer to the manual that comes with the cellular phone for the oper-
ation of the phone.
Guidance for registration completion is heard.
STEP5
STEP5
STEP6
STEP7

258 3-4. Using the hands-free phone system (for cellular phone)
Menu list of the hands-free phone system
■Normal operation
First menuSecond
menuThird menuOperation detail
CallBack
(Call
back)--Dialing a number stored in
the incoming call history
memory
Redial - -Dialing a number stored in
the outgoing call history
memory
Dial by
number- - Dialing by inputting a number
Dial by
Name
(Dial by
name)--Dialing by inputting a name
registered in the phone book
Phonebook
Add Entry - Adding a new number
Change
Name-Changing a name in the
phone book
Delete
Entry-Deleting the phone book
data
Delete
Speed
Dial-Deleting a registered speed
dial
List
Names- Listing the phone book data
Speed
Dial
(Set
speed
dial)- Registering a speed dial

259 3-4. Using the hands-free phone system (for cellular phone)
3
Interior features
Setup
(Setup)SecuritySet PIN Setting a PIN code
Phonebook Lock
(Phone book
lock)Locking the phone book
Phonebook
Unlock (Phone
book unlock)Unlocking the phone book
Phone
SetupPair PhoneRegistering the cellular
phone to be used
Change Phone
Name (Change
name)Changing a registered name
of a cellular phone
Delete PhoneDeleting a registered cellular
phone
List phonesListing the registered cellular
phones
Select phoneSelecting a cellular phone to
be used
Set Passkey Changing the passkey
Handsfree
PowerTurning the Hands-free
power on/off
System
SetupGuidance Vol-
umeSetting voice guidance vol-
ume
Device NameDisplaying a device’s infor-
mation
Reset Setting Initialization
First menuSecond
menuThird menuOperation detail

260 3-4. Using the hands-free phone system (for cellular phone)
■Using a short cut key
First menuSecond menuOperation detail
Dial “XXX (name)” -Dialing a number registered
in the phone book
Dial “XXX (number)” - Dialing the input numbers
Phone book add
entry- Adding a new number
Phone book change
name-Changing the name of a
phone number in the phone
book
Phone book delete
entry- Deleting phone book data
Phone book set
speed dial- Registering a speed dial
Phone book delete
speed dial- Deleting a speed dial
Phone book List
names- Listing the phone book data
