450 6-1. Specifications
Electrical system
Manual transaxle
Battery
Open voltage at
68F (20C):12.6  12.8 V Fully charged
12.2  12.4 V Half charged
11 . 8  12.0 V Discharged
(Voltage checked 20 minutes after the
engine and all the lights turned off)
Charging rates 5 A max.
Gear oil capacity (Reference)1.8 L 4-cylinder (2ZR-FE) engine
2.0 qt. (1.9 L, 1.7 Imp. qt.)
2.4 L 4-cylinder (2AZ-FE) engine
2.6 qt. (2.5 L, 2.2 Imp. qt.)
Gear oil typeTOYOTA Genuine Manual Transmission
Gear Oil LV or equivalent
Recommended API grade GL-4
Recommended gear oil
viscositySAE 75W
NOTICE
■Manual transaxle gear oil
Using manual transmission gear oil other than “TOYOTA Genuine Manual
Transmission Gear Oil LV” may cause occurrence of idle rattling noise and
bad fuel consumption.

467 6-1. Specifications
6
Vehicle specifications
Tire related termMeaning
Normal occupant
weight150 lb. (68 kg) times the number of occupants
specified in the second column of Table 1
* that
follows
Occupant distributionDistribution of occupants in a vehicle as speci-
fied in the third column of Table 1
* below
Production options
weightThe combined weight of installed regular pro-
duction options weighing over 5 lb. (2.3 kg) in
excess of the standard items which they
replace, not previously considered in curb
weight or accessory weight, including heavy
duty brakes, ride levelers, roof rack, heavy duty
battery, and special trim
RimA metal support for a tire or a tire and tube
assembly upon which the tire beads are seated
Rim diameter
(Wheel diameter)Nominal diameter of the bead seat
Rim size designation Rim diameter and width
Rim type designationThe industry manufacturer's designation for a
rim by style or code
Rim width Nominal distance between rim flanges
Vehicle capacity
weight (Total load
capacity)The rated cargo and luggage load plus 150 lb.
(68 kg) times the vehicle's designated seating
capacity
Vehicle maximum load
on the tireThe load on an individual tire that is determined
by distributing to each axle its share of the
maximum loaded vehicle weight, and dividing
by two
Vehicle normal load
on the tireThe load on an individual tire that is determined
by distributing to each axle its share of curb
weight, accessory weight, and normal occu-
pant weight (distributed in accordance with
Ta b l e 1
* below), and dividing by two

490 Alphabetical index
Back door
Back door ................................34
Wireless remote control ..........26
Back-up lights
Wattage ................................. 456
Battery
Checking ............................... 347
If the vehicle has a
discharged battery .............. 428
Preparing and checking
before winter ....................... 154
Bluetooth
® audio ..................... 230
Bluetooth® phone .................... 247
Bottle holder ............................. 290
Brake
Fluid ...................................... 345
Parking brake ........................ 127
Brake assist .............................. 145
Break-in tips ............................. 106
Care
Exterior .................................. 316
Interior ................................... 319
Seat belts .............................. 320
Cargo capacity ......................... 150
Cargo hooks ............................. 304
CD changer ............................... 190
CD player .................................. 190
Chains ....................................... 154Child restraint system
Booster seats, definition.......... 88
Booster seats, installation ....... 92
Convertible seats,
definition ............................... 88
Convertible seats,
installation............................. 92
Front passenger occupant
classification system ............. 83
Infant seats, definition ............. 88
Infant seats, installation .......... 92
Installing CRS with LATCH
anchors ................................. 93
Installing CRS with
seat belts .............................. 95
Installing CRS with top tether
straps .................................... 99
Child safety
Airbag precautions .................. 78
Battery precautions ....... 348, 431
Child restraint system ............. 88
Child-protectors....................... 30
How your child should wear
the seat belt .......................... 48
Installing child restraints.......... 92
Moon roof precautions ............ 61
Power window lock switch ...... 57
Power window precautions ..... 58
Removed key battery
precautions ......................... 369
Seat belt extender
precautions ........................... 50
Seat belt precautions .............. 49
B
C

495 Alphabetical index
Radiator.................................... 344
Radio ........................................ 183
Rear seats
Folding down .......................... 42
Rear side marker lights
Replacing light bulb .............. 380
Switch ................................... 135
Wattage ................................ 456
Rear turn signal lights
Replacing light bulbs ............ 380
Switch ................................... 126
Wattage ................................ 456
Rear view mirror
Compass .............................. 311
Rear window defogger............ 179
Rear window wiper.................. 140
Replacing
Fuses.................................... 371
Key battery ........................... 368
Light bulbs ............................ 380
Tires ..................................... 411
Reporting safety defects for
U.S.A. owners........................ 476
Seat belts
Adjusting the seat belt ............ 46
Automatic Locking
Retractor .............................. 47
Child restraint system
installation ............................ 92
Cleaning and maintaining
the seat belts...................... 320Emergency Locking
Retractor ...............................47
How to wear your seat belt......46
How your child should wear
the seat belt ..........................48
Pregnant women, proper seat
belt use .................................48
Reminder light .......................404
Seat belt extenders .................48
Seat belt pretensioners ...........47
Seatback table ..........................302
Seating capacity.......................153
Seats
Adjustment ..............................38
Adjustment precautions...........40
Child seats/child restraint
system installation ................92
Cleaning ................................319
Head restraint..........................44
Properly sitting in the seat .......69
Rear seat folding down ...........42
Seatback table ......................302
Service reminder
indicators ..............................132
Shift lever
Automatic transmission .........119
If the shift lever cannot
be shifted from P................. 426
Manual transmission .............124
Shift lock system .....................426
Side airbags................................71R
S

497 Alphabetical index
TRAC ........................................ 146
Traction control ....................... 146
Trip meter................................. 129
Turn signal lights
Replacing light bulbs ............ 380
Switch ................................... 126
Wattage ................................ 456
Vanity mirrors .......................... 294
Vehicle identification
number................................... 443
Vehicle stability control .......... 146
VSC ........................................... 146
Warning buzzers
Brake system........................ 401
Downshifting ......................... 123
Seat belt reminder ................ 404
Warning lights
Active Torque Control 4WD
system warning light .......... 402
Anti-lock brake system ......... 402
Brake assist system ............. 402
Brake system........................ 401
Charging system .................. 402
Electric power steering
warning light ....................... 402
Engine oil maintenance ........ 404
Engine oil pressure............... 402
Low fuel level........................ 404Low tire pressure warning
light .....................................404
Malfunction indicator lamp ....402
Open door .............................404
Pretensioners ........................402
Seat belt reminder light .........404
SRS airbags ..........................402
Washer fluid ..........................404
Washer
Checking ...............................349
Preparing and checking
before winter .......................154
Switch....................................138
Washing and waxing ...............316
Weight
Cargo capacity ......................150
Load limits .............................153
Weight ...................................442
Wheels ......................................364
Window glasses ........................57
Window lock switch ...................57
Windows
Power windows .......................57
Rear window defogger ..........179
Washer ..................................138
Windshield wipers ...................138
Wireless remote control key
Replacing the battery ............368
Wireless remote control ..........26
WMA disc ..................................197
V
W
