Page 11 of 500
11
: If equipped
*1: For vehicles with a Display Audio system, refer to “Display Audio System Owner’s Manual”.
B
Window lock switch
P. 59
Power window switches P. 59
Door lock switch P. 31
Inside door lock button P. 32
Page 12 of 500
12
C
AUX port
AUX port/USB port
P. 246
P. 225, 234, 246
Cup holders P. 285
Pictorial indexInterior
Power outlet P. 295
Parking brake lever P. 130Power outlet
Cigarette lighter
P. 295
P. 294
Page 13 of 500
13
Gauges and meters P. 132
Tilt and telescopic steering control lever P. 54
Pictorial index
Headlight switch
Turn signal lever
Fog light switch
P. 138
P. 129
P. 141
Instrument panel
Audio system P. 194
Windshield wiper and washer
switch
Rear window wiper and
washer switch
P. 143
P. 146
Security indicator
P. 68
Tire pressure warning reset switch P. 349
Fuel filler door opener
P. 64
: If equipped
Emergency
flasher switch
P. 388
Horn
P. 131
Outside rear view
mirror switches
P. 57
Page 14 of 500
14
A
Rear window and outside rear view mirror defogger
switch
/rear window defogger switch P. 193
Air conditioning system P. 186
Pictorial indexInstrument panel
Page 15 of 500
15
B
Cruise control switch P. 148
Engine (ignition) switch P. 118
Audio remote control
switches
P. 248
: If equipped
Page 16 of 500
16
C
Clock P. 292
Shift lever P. 122, 127Shift lock override
button
P. 423
Instrument panelPictorial index
Page 17 of 500
17
D
VSC off switch P. 152
Auxiliary box P. 288
Hood lock release
lever
P. 330
: If equipped
Page 18 of 500
18
For your information
Main Owner’s Manual
Please note that this manual covers all models and all equipment, including
options. Therefore, you may find some explanations for equipment not
installed on your vehicle.
All specifications provided in this manual are current at the time of printing.
However, because of the Toyota policy of continual product improvement, we
reserve the right to make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustrations may differ
from your vehicle in terms of equipment.
Noise from under vehicle after turning off the engine
Approximately five hours after the engine is turned off, you may hear sound
coming from under the vehicle for several minutes. This is the sound of a fuel
evaporation leakage check and, it does not indicate a malfunction.
Accessories, spare parts and modification of your Toyota
A wide variety of non-genuine spare parts and accessories for Toyota
vehicles are currently available on the market. You should know that these
parts are not covered by Toyota warranty and that Toyota is not responsible
for their performance, repair, or replacement, or for any damage they may
cause to, or adverse effect they may have on, your Toyota vehicle.
This vehicle should not be modified with non-genuine Toyota products.
Modification with non-genuine Toyota products could affect its performance,
safety or durability, and may even violate governmental regulations. In
addition, damage or performance problems resulting from the modification
may not be covered under warranty.
Page 19 of 500
19
Installation of a mobile two-way radio system
As the installation of a mobile two-way radio system in your vehicle may
affect electronic systems such as the multi-port fuel injection system/sequen-
tial multi-port fuel injection system, cruise control system, anti-lock brake
system, SRS airbag system or seat belt pretensioner system, be sure to
check with your Toyota dealer for precautionary measures or special instruc-
tions regarding installation.
Vehicle data recordings
Your Toyota is equipped with several sophisticated computers that will record
certain data, such as:
• Engine speed
• Accelerator status
• Brake status
• Vehicle speed
• Shift position (vehicles with an automatic transmission)
The recorded data varies according to the vehicle grade level and options
with which it is equipped. Furthermore, these computers do not record con-
versations, sounds or pictures.
●Data usage
Toyota may use the data recorded in these computers to diagnose malfunc-
tions, conduct research and development, and improve quality.
Toyota will not disclose the recorded data to a third party except:
• With the consent of the vehicle owner or with the consent of the lessee if
the vehicle is leased
• In response to an official request by the police, a court of law or a govern-
ment agency
• For use by Toyota in a lawsuit
• For research purposes where the data is not tied to a specific vehicle or
vehicle owner
Page 20 of 500
20
Event data recorder
This vehicle is equipped with an event data recorder (EDR). The main pur-
pose of an EDR is to record, in certain crash or near crash-like situations,
such as an air bag deployment or hitting a road obstacle, data that will assist
in understanding how a vehicle’s systems performed. The EDR is designed
to record data related to vehicle dynamics and safety systems for a short
period of time, typically 30 seconds or less.
The EDR in this vehicle is designed to record such data as:
• How various systems in your vehicle were operating;
• Whether or not the driver and passenger safety belts were buckled/fas-
tened;
• How far (if at all) the driver was depressing the accelerator and/or brake
pedal; and,
• How fast the vehicle was traveling.
These data can help provide a better understanding of the circumstances in
which crashes and injuries occur.
NOTE: EDR data are recorded by your vehicle only if a non-trivial crash situ-
ation occurs; no data are recorded by the EDR under normal driving condi-
tions and no personal data (e.g., name, gender, age, and crash location) are
recorded. However, other parties, such as law enforcement, could combine
the EDR data with the type of personally identifying data routinely acquired
during a crash investigation.
To read data recorded by an EDR, special equipment is required, and access
to the vehicle or the EDR is needed. In addition to the vehicle manufacturer,
other parties, such as law enforcement, that have the special equipment, can
read the information if they have access to the vehicle or the EDR.
