TOYOTA MIRAI 2019 Owners Manual (in English)

1213. Instrument cluster
3
Instrument cluster
MIRAI_OM_USA_OM62054U(18MY)_O
M62048U(19MY)■
Fuel consumption record
To toggle through the items, press on the meter control switch es
(  P. 118) to select the tab and then press either or .
1-minute fuel consumption
Average fuel consumption in the
past 15 minutes, displayed in
1-minute intervals
5-minute fuel consumption
Average fuel consumption in the
past 30 minutes, displayed in
5-minute intervals
Monthly fuel consumption
Average fuel consumption over
the past 6 months
The scale of the vertical axis can
be changed by pressing or
of the meter control switches.
Press on the meter control
switches ( P. 118) to return.

1223. Instrument cluster
MIRAI_OM_USA_OM62054U(18MY)_O
M62048U(19MY)■
Drive monitor
Driving time
Displays the amount of time
since starting
*1 the fuel cell
system or resetting
*2.
Average vehicle speed
Displays the average vehicle
speed since starting
*1 the
fuel cell system or reset-
ting
*2.
Average fuel consumption
Displays the average fuel consumption since starting
*1 the fuel
cell system or resetting
*2.
*1: When the odometer, traveled distance since starting, or blank is dis-
played in the odometer and trip meter of the main display
*2: When trip meter A or trip meter B is displayed in the odometer and
trip meter of the main display

1233. Instrument cluster
3
Instrument cluster
MIRAI_OM_USA_OM62054U(18MY)_O
M62048U(19MY)■
ECO diary
To toggle through the items, press on the meter control switch es
(  P. 118) to select the tab and then press either or .
Daily history
Press either or of the
meter control switches to scroll
through the da ys displayed.
Monthly history
Press either or of the
meter control switches to scroll
through the months displayed.
Press on the meter control switches ( P. 118) to return.
■Power meter
Displays the output power and
regeneration level of the fuel cell
system.

1243. Instrument cluster
MIRAI_OM_USA_OM62054U(18MY)_O
M62048U(19MY)
The settings of the following items can be changed, refer to P. 484.
For functions that can be enabled or disabled, the function swi tches
between on and off each time is pressed.
● Clock ( P. 328)
• Rounds to the nearest hour
• Time adjustment
● LDA (Lane Departure Alert with steering control) (P. 2 3 8 )
Select to set up the following items.
• Steering assist function
• Alert sensitivity
• Vehicle sway warning function
• Sway sensitivity
● PCS (Pre-Collis ion System) (P. 226)
Select to set up the following items.
• PCS on/off
• PCS sensitivity
●
BSM (Blind Spot Monitor) ( P. 286)
Select to set up the BSM and RCTA function on/off.
● RSA (Road Sign Assist) (if equipped) ( P. 248)
Select to set up RSA (Ro ad Sign Assist) on/off.
●
Parking Support Brake function (for static objects) (if
equipped) ( P. 274)
Select to set up the Parking Supp ort Brake function (for static
objects) on/off.
● Intuitive parking assist ( P. 265)
Select to set up the following items.
• Intuitive parkin g assist on/off
• Intuitive parking assist buzzer volume
Setting display

1253. Instrument cluster
3
Instrument cluster
MIRAI_OM_USA_OM62054U(18MY)_O
M62048U(19MY)
● Units
Select to change the unit.
●
Meter settings
Select the menu to set up the following items ( P. 490)
• RSA notification method (if equipped)
Select to change the RSA notification method.
• RSA notification level (if equipped)
Select to change the RSA notification level.
• Time for exchanging the ion filter
Select to initialize the time for exchanging the ion filter.
• Language
Select to change the language on the display.
• Interruption display
Select to set the Interruption displays (navigation system rout e guid-
ance, Instrument panel brightness adjustment), which may appear in
some situations, on/off.
• Return to initial settings
Registered or changed meter settings will be deleted or returne d to
their default setting.
• Main display split screen (if equipped)
Select to change the main display to split screen.
• Monthly history of fuel economy history
Select to clear the history.
• Daily history of ECO log
Select to clear the log.
• Monthly history of ECO log
Select to clear the log.
• Calendar date
Select to set the date.
• Erase screen
Select to display a blank screen.

1263. Instrument cluster
MIRAI_OM_USA_OM62054U(18MY)_O
M62048U(19MY)
■Setting items
● [Meter settings] items are not selectable while driving and cannot be
operated.
Also, the settings screen is temporarily canceled in the follow ing situations.
• A warning message is displayed.
• The vehicle starts off.
● Settings for functions not equipped to the vehicle are not disp layed.
● When a function is turned off, the related settings for that fu nction are not
selectable.
■ When the 12-volt battery terminal is disconnected and reconnect ed
The following data is reset when the 12-volt battery terminal i s disconnected
and reconnected.
● 1-minute fuel consumption
● 5-minute fuel consumption
● Driving time
● Average vehicle speed
● Average fuel consumption
■ Liquid crystal display
P. 115
NOTICE
■During setting up the display
To prevent 12-volt battery discharge, ensure that the fuel cell system is
operating while setting up the display features.

127
4
Operation of
each component
MIRAI_OM_USA_OM62054U(18MY)_O
M62048U(19MY) 4-1. Key information
Keys .................................. 128
4-2. Opening, closing and locking the doors
Doors ................................ 132
Trunk ................................. 138
Smart key system ............. 143
4-3. Adjusting the seats Front seats ........................ 151
Driving position memory ... 153
Head restraints.................. 158
4-4. Adjusting the steering wheel and mirrors
Steering wheel .................. 160
Inside rear view mirror ...... 162
Outside rear view mirrors ............................. 164
4-5. Opening and closing the windows
Power windows ................. 167

1284-1. Key information
MIRAI_OM_USA_OM62054U(18MY)_O
M62048U(19MY)
Keys
The following keys are provided with the vehicle.
Electronic keys
• Operating the smart key system (P. 143)
• Operating the wireless remote control function
Mechanical keys
Key number plate
Locks all the doors ( P. 1 3 2 )
Unlocks all the doors ( P. 1 3 2 )
Pressing the button unlocks the
driver’s door. Pressing the button
again within 5 seconds unlocks the
other doors.
Opens the windows ( P. 1 3 2 )*
Opens the trunk (P. 1 3 8 )
Sounds the alarm ( P. 129)
*: This setting must be customized at your Toyota dealer.
The keys
Wireless remote control

1294-1. Key information
4
Operation of each component
MIRAI_OM_USA_OM62054U(18MY)_O
M62048U(19MY)
To take out the mechanical key,
slide the release lever and take
the key out.
The mechanical key can only be
inserted in one direction, as the
key only has grooves on one side.
If the key cannot be inserted in a
lock cylinder, turn it over and re-
attempt to insert it.
After using the mechanical key, store it in the electronic key. Carry the
mechanical key together with the electronic key. If the electro nic key bat-
tery is depleted or the entry function does not operate properl y, you will
need the mechanical key. ( P. 449)
■Panic mode
■ When required to leave the vehicle’s key with a parking attendant
Set the luggage security system ( P. 139) on and lock the glove box ( P. 3 2 1 )
as circumstances demand.
Remove the mechanical key for your own use and provide the attendant with
the electronic key only.
■ If you lose your mechanical keys
New genuine mechanical keys can be made by your Toyota dealer u sing the
other mechanical key and the key number stamped on your key num ber
plate. Keep the plate in a safe place such as your wallet, not in the vehicle.
■ When riding in an aircraft
When bringing an electronic key onto an aircraft, make sure you do not press
any button on the electronic key while inside the aircraft cabi n. If you are car-
rying an electronic key in your bag, etc., ensure that the butt ons are not likely
to be pressed accidentally. Pressing a button may cause the electronic key to
emit radio waves that could interfere with the operation of the aircraft.
Using the mechanical key
When is pressed for longer than
about 1 second, an alarm will sound inter-
mittently and the vehicle lights will flash to
deter any person from trying to break into
or damage your vehicle.
To stop the alarm, press any button on the
electronic key.

1304-1. Key information
MIRAI_OM_USA_OM62054U(18MY)_O
M62048U(19MY)■
Electronic key battery depletion
●The standard battery life is 1 to 2 years.
● If the battery becomes low, an alarm will sound in the cabin wh en the fuel
cell system stops. ( P. 426)
● As the electronic key always receives radio waves, the battery will become
depleted even if the electronic key is not used. The following symptoms indi-
cate that the electronic key battery may be depleted. Replace the battery
when necessary. ( P. 400)
• The smart key system or the wireless remote control does not o perate.
• The detection area becomes smaller.
• The LED indicator on the key surface does not turn on.
● To avoid serious deterioration, do not leave the electronic key within 3 ft.
(1 m) of the following electrical appliances that produce a magnetic field:
•TVs
• Personal computers
• Cellular phones, cordless phones and battery chargers
• Recharging cellular phones or cordless phones
• Table lamps
• Induction cookers
■ Replacing the battery
P. 400
■ Confirmation of the registered key number
The number of keys already registered to the vehicle can be confirmed. Ask
your Toyota dealer for details.
■ If a wrong key is used
The key cylinder rotates freely to isolate inside mechanism.
