clock setting TOYOTA MIRAI 2021 Accessories, Audio & Navigation (in English)

151-1. Basic function
1
Quick guide
Press the “MENU” button to display the “Menu” screen.Displays the clock. Select to display the clock settings screen .
( P. 6 3 )
Select to display the destination screen.
*1 (  P. 8 7 )
Select to display the audio control screen. ( P.124)
Select to display the hands-free operation screen. ( P.276)
When an Apple CarPlay connection is established, select to dis-
play the phone application screen. ( P.55)
Select to display the Toyota apps screen.
*2, 3 (  P.318)
When an Apple CarPlay/Android Auto connection is established
and this button displays “Apple CarPlay”/“Android Auto”, select to
display the home screen of Apple CarPlay/Android Auto. ( P.55)
Select to display the information screen. ( P.19)
Select to display the “Setup” screen. ( P.18)
Select to adjust the contrast, brightness, etc. of the display.
( P. 3 6 )
*1: 12.3-inch display model
*2: This function is not made available in some countries or areas .
*3: When an Apple CarPlay/Android Auto connection is established, this
function will be unavailable.
“Menu” screen
“Menu” screen operation
A
B
C
D
E
F
G
H
I

622-4. Other settings
2-4.Other settings
1Press the “MENU” button.
8-inch display model
12.3-inch display model
2 Select “Setup”.
 If the general settings screen
is not displayed, select “Gen-
eral”. 3
Select the desired items to
be set.
 “Clock”
Select to change the time zone and
select “On” or “Off” or “Auto”
*1 for
daylight saving time, automatic
adjustment of the clock, etc.
(  P. 6 3 )
 “Language”
Select to change the language. The
language setting of Apple Car-
Play/Android Auto can only be
changed on the connected device.
“Customize Home Screen”
Select to change the display infor-
mation/area on the home screen
and the home screen layout.
( P. 3 1 )
 “Projection Settings”
Select to set automatic Apple Car-
Play/Android Auto connection
establishment on/off. ( P.64)
 “Beep”
Select to turn the beep sound
on/off.
“Theme Setting”
Select to change the screen theme
setting.
General settings
Settings are available for
clock, operation sounds,
etc.
Displaying the general
settings screen
General settings screen

632-4. Other settings
2
Basic function
“Unit of Temperature”*1
Select to change the unit of tem-
perature.
“Units of Measurement”*1
Select to change the unit of mea-
sure for distance /fuel consumption.
“Auto Change to Screen”*1
Select to set aut omatic screen
changes from the audio control
screen to the home screen to
on/off. When set to on, the screen
will automatically return to the
home screen from the audio control
screen after 20 seconds.
 “Keyboard Layout”
Select to change the keyboard lay-
out.
“Delete Keyboard History”
Select to delete the keyboard his-
tory.
“Memorize Keyboard History”
Select to set the memorize key-
board history on/off.
“Animation”
Select to turn the a nimations on/off.
“Driver Setting”
Select to change the driver set-
tings. ( P. 6 5 )
 “Delete Personal Data”
Select to delete personal data.
(  P.65)
 “Software Update”
Select to update software versions.
For details, contact your Toyota
dealer.
“Software Update Setting”*2
Select to set soft ware update set-
ting. ( P. 6 6 )
 “Gracenote Database
Update”
Select to upda te Gracenote® data-
base versions. For details, contact
your Toyota dealer.
 “Software Information”
Select to display th e software infor-
mation. Notices related to third
party software used in this product
are enlisted. (This includes instruc-
tions for obtaining such software,
where applicable.)
 “SW Sensitivity Level”
Select to change the capacitive
touch screen button sensitivity to 1
(low), 2 (medium), or 3 (high).
*1: 12.3-inch display model
*2: This function is not made avail- able in some countries or areas.
1 Display the general settings
screen. ( P. 6 2 )
2 Select “Clock”.
3 Select the desired items to
be set.
Select to change the time
zone. ( P.64)
Clock settings
A

642-4. Other settings
Select to set daylight saving
time on/off/auto
*.
Select to set automatic
adjustment of the clock by
GPS on/off.
When set to off, the clock can
be manually adjusted.
( P. 6 4 )
Select to set the 24 hour time
format on/off.
When set to off, the clock is
displayed in 12 hour time for-
mat.
*: 12.3-inch display model
1 Select “Time Zone”.
2 Select the desired time zone.
 12.3-inch display model:
If “Auto” is selected, the time
zone is selected automatically
by current vehicle position.
When “Auto Adjust by GPS” is
turned off, the clock can be
manually adjusted.
1 Select “Auto Adjust by GPS”
to set to off. 2
Adjust the clock manually.
Select “+” to set the time for-
ward one hour and “-” to set
the time back one hour.
Select “+” to set the time for-
ward one minute and “-” to
set the time back one minute.
Select to round to the nearest
hour.
e.g.
1:00 to 1:29  1:00
1:30 to 1:59  2:00
1 Display the general settings
screen. ( P. 6 2 )
2 Select “Projection Settings”.
3 Select the desired items to
be set.
Select to turn Apple CarPlay
connection establishment
Setting the time zone
Manual clock setting
B
C
D
3URMHFWLRQVHWWLQJV
A
B
C
A

Alphabetical Index327
B
Basic function .......................... 12
Basic information before opera-tion........................................... 26
Basic operation ................ 74, 124
Bluetooth
® audio .................... 146
Overview .............................. 146
Registering/Conn ecting a Blue-
tooth
® device...................... 149
“Bluetooth” button (“Setup” screen) .............................. 18, 43
Bluetooth
® phone message func-
tion......................................... 288 Calling the message sender. 291
Checking received messages ........................................... 289
Displaying the message screen ........................................... 288
Receiving a message ........... 288
Replying to a me ssage (dicta-
tion reply) ........................... 290
Replying to a message (quick
reply) .................................. 290
Buttons overview ..................... 12 Operations of each part.......... 12
C
Clock settings .....................15, 63
Command list ..........................170
Command list overview ........170
Connected Service s ...............308
Connected Services operation ...............................................318
Connectivity settings ...............38
D
“Data Services” button (“Setup”
screen) .............................18, 178
Data services settings............178 Setting download methods ...178
Destination Assist ..................321
“Destination” button (“Menu” screen) ...............................15, 87
Destination search ...................87
Destination search operation ..87 Destination screen..................87
One-touch setting home/favorite as a destination ....................93
Searching by address.............90
Searching by contact ..............90
Searching by Destination Assist .............................................89
Searching by emergency........89
Searching by favorites list ......89
Searching by keyword ............88
Searching by point of interest .91
Searching by recent destinations .............................................89
Selecting search area .............88
Setting home as destination ...88
