TOYOTA PRIUS 2010 3.G Navigation Manual

ADVANCED PARKING GUIDANCE SYSTEM
224
In the following circumstances, detec-
tion of the parking space lines on the
road surface may not be possible:
The lines are faded or dirty, making
them unclear.
The road surface is of a light color
which does not contrast well with the
white lines.
The parking space lines are a color oth-
er than white (yellow etc.).
The area is dark, for example at night
or in a covered parking lot.
During or after rain, when the road sur-
face is wet and reflects light, or puddles
have formed.
The sun is shining directly on the cam-
era, for example early morning or late
afternoon.
The parking space is covered with
snow or de −icing agent.
There are markings or maintenance
marks on the road surface.
The color or brightness of the road sur-
face is not uniform.
Hot or cold water has splashed on the
camera, and the lens is fogged.
There are dirt or water droplets on the
lens.
If the point at which you stop is correctly
identified, the green frame will display the
parking space accurately. If the white lines
of the parking space have not been cor-
rectly identified, the green frame will not
match the parking space even if you stop
in the correct location. In this case, adjust
the point at which you stop as needed. ALIGNING THE GREEN FRAME
There are two ways to align the green
frame with
the parking space, either using
the arrows on the screen, or by touching
the screen at points other than the arrows.
Using the arrows on the screen
By touching the arrows displayed on the
screen, you can move the green frame.

ADVANCED PARKING GUIDANCE SYSTEM
225
Directly touching the target point
By touching the point you wish to move the
frame to, you can move the green frame.
1. Touch the front edge of the place
you wish to move.
2. The frame will be moved as shown.
If you touch the following areas, the green
frame will not move:
The area surrounding the arrows.
The area near the lower touch−screen
button on the screen.
Areas too far away to park in the range
of 31.2 ft. (9.5 m) or more behind, and/
or either left or right from the current
position. IF THE PARKING SPACE AND THE
GREEN FRAME DO NOT MATCH
If the lines of the parking space are wider
than
the green frame, position the frame so
that the difference between the frame and
the parking space lines is equal on both
sides.

ADVANCED PARKING GUIDANCE SYSTEM
226
MessageCauseWhat to do
! Parking position cannot be
set.Not in an area where sys-
tem use is possible.Change the vehicle’s posi-
tion, referring to the help
function.
! Check APGS system.
Have your vehicle checked
by a dealer.There is a malfunction in
the system.Have your vehicle checked
by your Toyota dealer.
! Use on flat surface.The vehicle has rolled
forward on a sloped
road.
The vehicle does not
move even if you take
your foot off the brake
pedal.
Do not attempt to use the
system in those sorts of
conditions.
! System cannot guide un-
der current conditions.If the message is displayed
only when the system is op-
erating, it is likely that the
tires are worn, or tire infla-
tion pressure is low.Check tires for wear and
pressure.
If the message is displayed
constantly, there is most
likely a malfunction.Turn the “POWER” switch
to OFF, then to ON mode.
If the message is still
displayed, have the vehicle
checked by your Toyota
dealer.
The vehicle has skidded or
the tires have been locked.Do not attempt to use the
system on a slippery road
such as snowy road.
! APGS not available now.The system has temporari-
ly overheated.Turn the “POWER” switch
to OFF, then to ON mode.
Wait a few moments before
use.
There is a malfunction in
the voice guidance system.Have your vehicle checked
by your Toyota dealer.
The hybrid system has not
been started.Turn the “POWER” switch
to ON mode and start the
hybrid system. If the mes-
sage is still displayed, have
the vehicle checked by
your Toyota dealer.
! Release parking brake.The parking brake has
been applied.Release the parking brake.
! Too much force applied to
the steering wheel.You are exerting too much
pressure on the steering
wheel.Loosen your grip on the
steering wheel.
— What to do when this sort of message is displayed

ADVANCED PARKING GUIDANCE SYSTEM
227
MessageCauseWhat to do
Steering position is not
straight. Turn the steering
wheel to LEFT (or RIGHT).The steering wheel is not
straight.Straighten the steering
wheel.
Steer to left (or right) until
the frame becomes green.It is possible to begin to
park if you turn the steering
wheel in the direction indi-
cated.Turn the steering wheel in
the direction indicated until
the frame turns green (the
message “Too much force
applied to the steering
wheel” is displayed). Turn
the wheel slightly more
than necessary to over-
come tire resistance. Once
you have turned the steer-
ing wheel, you can no lon-
ger change the target park-
ing position. Be sure to
align the frame before turn-
ing the steering wheel.
! Parking position has not
been set.You have begun to back up
without touching “OK”.Stop the vehicle and touch
“OK”.
! Speed is too fast.The speed at which you are
backing up is too fast.Back up at a speed that
does not cause the warning
chime to sound, using the
brake pedal. The system
will be disabled if you back
up too quickly.
! Guidance canceled by
user operation.You have turned the steer-
ing wheel or depressed the
accelerator pedal during
the assist mode.The system has been dis-
abled, so restart from the
beginning.
! Accelerator pedal has
been depressed.You have depressed the
accelerator pedal when
setting the target parking
position.Do not depress the acceler-
ator pedal.
! Guidance unavailable.Some sort of malfunction
has occurred within the
system.Have the vehicle checked
by your Toyota dealer.
! System not ready.−Take your vehicle to your
Toyota dealer.
! Clean Park Sonar.In extreme cold weather or
foreign matter gets on the
sensors.Have the vehicle checked
by your Toyota dealer.

ADVANCED PARKING GUIDANCE SYSTEM
228
Message and voice guidance
In the parallel parking assist mode and parking assist mode, voice guida\
nce accompa-
nies the following messages displayed during parking position setting an\
d steering
wheel control. (Voice guidance may not be given depending on the reason the message
was displayed.)
Message
Voice Guidance (Warning tone)
During settingDuring steering wheelcontrol
! Check APGS system. Have your
vehicle checked by a dealer.(One chime)
(Two beeps) The guid-
ance has been can-
celed.
! System cannot guide under cur-
rent conditions.−
(Two beeps) The guid-
ance has been can-
celed.
! APGS not available now.(One chime)
(Two beeps) The guid-
ance has been can-
celed.
! Release parking brake.(One chime)
(Two beeps) The guid-
ance has been can-
celed.
! Parking position has not been set.(One chime)−
! Speed is too fast.−
(Several beeps and
then two beeps) The
guidance has been
canceled.
! Guidance canceled by user op-
eration.−
(Two beeps) The guid-
ance has been can-
celed.
For the adjustment of the volume, ask your Toyota dealer.

ADVANCED PARKING GUIDANCE SYSTEM
229

When a red frame is displayed in the
assist mode
If the frame turns red and the message
“Adjust the frame to the target.” is dis-
played while setting the target parking
position, you cannot use the assist mode.
In this situation, move the target parking
position, or move the position of the ve-
hicle.
The frame may be displayed in red, de-
pending on the location and angle of the
vehicle when “R” is selected.
Furthermore, even if the frame is displayed
in green, if you move the frame to a loca-
tion unsuitable for parking using the assist
mode, the frame will change to red.
When in the parking assist mode, if the
message “Steer to left (right) until the
frame becomes green.” is displayed, you
may use the assist mode by turning the
steering wheel. 1. Align
the frame with the target park-
ing position.
2. While stopped, turn the wheel to the
left (right) until the frame turns green
and “Too much force applied to the
steering wheel.” is displayed.
Turn the wheel slightly more than neces-
sary to overcome tire resistance.
If you turn the wheel too far, the direction
of turn displayed on the screen will re-
verse.
3. Touch “OK”.
Once you have turned the steering wheel,
you can no longer change the target park-
ing position. Be sure to align the frame be-
fore turning the steering wheel.

ADVANCED PARKING GUIDANCE SYSTEM
230
HELP FUNCTION
If you touch “OK”, the reason the frame is
displayed in red will be displayed. Move
the vehicle appropriately, referring to the
screen.
1. Touch “OK”.
2. Move the vehicle in accordance with
the message displayed.
See the following items for information on
the messages displayed.
If you move the frame to a position accept-
able to the assist mode, a chime will
sound.
3. If you have moved the vehicle for-
wards, shift to “R”.
4. Check that the frame is green, and if
that position is acceptable, touch
“OK”. DISPLAYED MESSAGE AND VEHICLE
POSITION FOR PARKING ASSIST
MODE
1Too far
If the vehicle is too far from the parking
space, the message “Start from a position
nearer to the target parking area.” is dis-
played.

ADVANCED PARKING GUIDANCE SYSTEM
231
1Angle too small
If the orientation of the vehicle is incorrect,
the message “Start with larger vehicle
heading angle.” is displayed.
1Near the front of the parking
space
2Too close
If the vehicle is near the front of the parking
space, or too close, the message “Start
from a position farther from the target park-
ing area.” is displayed.

ADVANCED PARKING GUIDANCE SYSTEM
232
DISPLAYED MESSAGE AND VEHICLE
POSITION FOR PARALLEL PARKING
ASSIST MODE
1Too far
If the vehicle is too far from other parked
vehicles, the message “Start from a posi-
tion nearer to adjacent vehicle.” is dis-
played.
1Too close
If the vehicle is too close to other parked
vehicles, the message “Start from a posi-
tion farther from adjacent vehicle.” is dis-
played.

ADVANCED PARKING GUIDANCE SYSTEM
233
1Too far forward
If the vehicle is too far forward, the mes-
sage “Start after moving slightly back-
ward.” is displayed.1Too far back
If the vehicle is too far back, the message
“Start after moving slightly forward.” is dis-
played.
