TOYOTA PRIUS 2015 4.G Owners Manual

601
6-1. Specifications
6
Vehicle specifications
PRIUS_OM_OM47A17U_DVD_(U)
*: Table 1
 Occupant loading and distri bution for vehicle normal load
for various designated seating capacities
Tire related termMeaning
Tread separation Pulling away of the tread from the tire carcass
Treadwear indicators
(TWI) The projections within the principal grooves
designed to give a visual indication of the
degrees of wear of the tread
Wheel-holding fixture The fixture used to hold the wheel and tire
assembly securely
during testing
Designated seating
capacity, Number of occupantsVehicle normal load,
Number of occupantsOccupant distribution in a normally loaded vehi- cle
2 through 4 2 2 in front
5 through 10 3 2 in front, 1 in second
seat
11 through 15 5 2 in front, 1 in second
seat, 1 in third seat, 1
in fourth seat
16 through 20 7 2 in front, 2 in second
seat, 2 in third seat, 1
in fourth seat

602
PRIUS_OM_OM47A17U_DVD_(U)
6-2. Customization
Customizable features
Customizable featuresVehicles with a Display Audio system: Settings that can be
changed using the Display Audio system
(For further information on custom izing settings using the Display
Audio system, refer to the “D ISPLAY AUDIO SYSTEM OWNER’S
MANUAL”.)
Vehicles with a navigation syst em: Settings that can be changed
using the navi gation system
(For further information on cust omizing settings using the naviga-
tion system, refer to the “NAVIGATION SYSTEM OWNER’S
MANUAL”.)
Settings that can be chan ged by your Toyota dealer
Definition of symbols: O = Available, — = Not available
Your vehicle includes a variety of electronic features that can be per-
sonalized to suit your prefer ences. Programming these preferences
requires specialized equipment and may be performed by your
Toyota dealer.
Some function settings are changed simultaneously with other functions
being customized. Contact your Toyota dealer for further details.

603
6-2. Customization
6
Vehicle specifications
PRIUS_OM_OM47A17U_DVD_(U)
ItemFunctionDefault
settingCustom- ized
setting
Smart key
system
( P. 63) Smart key
system
ON OFF OOO
Select doors to
unlock Driver’s
door All doors O O O
Wireless
remote
control
( P. 86) Wireless remote
control
ON OFF – – O
Unlocking
operation Driver’s
door
unlocked in 1-step, all doors
unlocked in 2-step All doors
unlocked in 1-step OOO
Panic function ON OFF – – O
Buzzer sounds
when pushing with any
door not closed ON OFF – – O

604 6-2. Customization
PRIUS_OM_OM47A17U_DVD_(U)
ItemFunctionDefault settingCustom- ized
setting
Smart key
system
( P. 63) and
wireless
remote
control
( P. 86) Operation
signals
(Emergency
flashers)
ON OFF – O O
Operation
signals
(Buzzers) Level 7
Level 1 to 6
OOO
OFF
Time elapsed
before
automatic door
lock function is
activated if door
is not opened
after being
unlocked 60 seconds
OFF
–OO
30
seconds
120
seconds

605
6-2. Customization
6
Vehicle specifications
PRIUS_OM_OM47A17U_DVD_(U)
*: This function cannot be customized for vehicles sold in Canada.
ItemFunctionDefault
settingCustom- ized
setting
Door lock
( P. 88,
553) Unlocking using
a key
Driver’s
door
unlocked in 1-step, all doors
unlocked in 2-step All doors
unlocked in 1-step –OO
Speed-detecting
automatic door
lock function OFF ON OOO
Shifting the shift
position to any
position other
than P locks all
doors ON OFF OOO
Shifting the shift
position to P
unlocks all doors ON OFF OOO
Opening driver’s
door unlocks all
doors OFF ON – O O
Automatic
light control
system
( P. 253) Light sensor
sensitivity
Level 3Levels
1 to 5 OOO
Time elapsed
before head-
lights automati-
cally turn off after
doors are closed 30 seconds
0 seconds
OOO
60 seconds
90 seconds
Daytime running
lights
*ON OFF OOO

606 6-2. Customization
PRIUS_OM_OM47A17U_DVD_(U)
ItemFunctionDefault settingCustom- ized
setting
Power
windows
( P. 125) The one-touch
closing operation
except for
driver’s seat
ON OFF – – O
Illumination
( P. 359) Time elapsed
before lights turn
off
15 secondsOFF
–OO
7.5
seconds
30 seconds
Operation when
the doors are
unlocked ON OFF – – O
Operation after
the “POWER”
switch turned
OFF ON OFF – – O
Operation when
you approach
the vehicle with
the electric key
on your person
(When the per-
sonal/interior
light main switch
is door position) ON OFF – – O
Foot lights ON OFF – – O
Foot lights oper-
ation when the
vehicle is run-
ning ON OFF – – O

607
6-2. Customization
6
Vehicle specifications
PRIUS_OM_OM47A17U_DVD_(U)
ItemFunctionDefault
settingCustom- ized
setting
Meter and
instrument
panel
( P. 217) Sensor sensitiv-
ity for darkening
the brightness of
the meter, navi-
gation system
and instrument
panel depend-
ing on the out-
side brightness
0 -2 to +2 – – O
Sensor sensitiv-
ity for returning
the brightness of
the meter, navi-
gation system
and instrument
panel to the orig-
inal level
depending on
the outside
brightness 0 -2 to +2 – – O
Automatic
air
conditioning
system
( P. 332) Enable/disable
automatic
operation of the
air conditioning
compressor
when the
“AUTO” switch
ON
ON OFF – O O
Heating/cooling
operation mini-
mized in Eco
drive mode ON OFF – – O

608 6-2. Customization
PRIUS_OM_OM47A17U_DVD_(U)
Multi-information display (P. 226)
ItemFunctionDefault
settingCustom- ized
setting
Remote Air
Condition-
ing System
( P. 348) Operation using
the
“A/C” button on
the wireless
remote control
Push and
hold for 0.8 seconds Push once
––O
Push twice
Push and
hold for 2.4 seconds
OFF
Stopping the
operation using
the “A/C” button
on the wireless
remote control Push twicePush once
––O
Push and
hold for 0.8 seconds
Push and
hold for 2.4 seconds
OFF
Reverse
warning
buzzer
( P. 210) Operation sig-
nals (Buzzer)
when shifting
into R
Beeps
repeatedly Beeps
once ––O
Seat belt
reminder
( P. 513) Vehicle speed
linked seat belt
reminder buzzer
ON OFF – – O
Available languagesEnglish, French and Spanish

609
6
Vehicle specifications
PRIUS_OM_OM47A17U_DVD_(U)
6-3. Initialization
Items to initialize
ItemWhen to initializeReference
Message indicating
maintenance is
required After the maintenance is performed P. 412
Tire pressure warning
system • When rotating the tires on vehicles
with differing front and rear tire infla-
tion pressures
• When changing the tire size P. 448
The following items must be init
ialized for normal system operation
after such cases as the 12-volt batt ery being reconnected, or mainte-
nance being performed on the vehicle.

610 6-3. Initialization
PRIUS_OM_OM47A17U_DVD_(U)
