TOYOTA PRIUS C 2017 NHP10 / 1.G Owners Manual

391
6
Interior features
PRIUS c_U (OM52J11U)
6-4. Other interior features
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
Slide the cover to open.
The temperature display shows temperatures within the range of
-40°F (-40°C) and 122°F (50°C).
The outside temperature display
of the “Drive Information” screen
can be displayed by pressing the
“DISP” switch. ( →P. 100)
Other interior features
Sun visors
1
2
Vanity mirrors
Outside temperature display

3926-4. Other interior features
PRIUS c_U (OM52J11U)
■The outside temperatur e is displayed when
Vehicles without a smart key system
The engine switch is in the “ON” position.
Vehicles with a smart key system
The “POWER” switch is in ON mode.
■ Outside temperature display
■ Display
In the following situations, the correct outside temperature may not be \
dis-
played, or the display may take longer than normal to change:
●When the vehicle is stopped, or moving at low speeds (less than 16 mph [25
km/h])
● When the outside temperature has changed suddenly (at the entrance/exit
of a garage, tunnel, etc.)
■ When “ − −” or “E” is displayed
The system may be malfunctioning. Take your vehicle to your Toyota dealer. The outside temperature is shown on the
multi-information display when the steer-
ing wheel climate remote control
switches are used to adjust the air condi-
tioning system’s temperature or change
between outside and recirculated air
modes. ( →P. 378)

3936-4. Other interior features
6
Interior features
PRIUS c_U (OM52J11U)
Please use as a power supply for electronic goods that use less than
12 VDC/10 A (power consumption of 120 W).
Open the lid.
■ The power outlet can be used when
Vehicles without a smart key system
The engine switch is in the “ACC” or “ON” position.
Vehicles with a smart key system
The “POWER” switch is in ACCESSORY or ON mode.
Power outlet
NOTICE
● To avoid damaging the power outlet, close the power outlet lid when the
power outlet is not in use. Foreign objects or liquids that enter the power
outlet may cause a short circuit.
● To prevent battery discharge, do not use the power outlet longer than nec-
essary when the hybrid system is off.

3946-4. Other interior features
PRIUS c_U (OM52J11U)
Coat hooks (if equipped)
WARNING
Do not hang coat hangers or other hard or sharp objects on the hook. If the
SRS curtain shield airbags deploy, these items may become projectiles,
causing death or serious injury.

3956-4. Other interior features
6
Interior features
PRIUS c_U (OM52J11U)
An assist grip installed on the ceil-
ing can be used to support your
body while sitting on the seat.
Assist grips
WARNING
Do not use the assist grip when getting in or out of the vehicle or rising from
your seat.
NOTICE
Do not hang any heavy object or put a heavy load on the assist grip.

3966-4. Other interior features
PRIUS c_U (OM52J11U)■
Removing the luggage cover
Unhook the cords.
Pull the luggage cover back-
ward to disengage the
anchors.
Remove the luggage cover.
Luggage cover (if equipped)
1
2
3

3976-4. Other interior features
6
Interior features
PRIUS c_U (OM52J11U)■
Installing the luggage cover
Place the luggage cover on
the anchors.
Push the luggage cover until
a click sound is heard.
Hook the cords.
1
2
3

3986-4. Other interior features
PRIUS c_U (OM52J11U)

399
7Maintenance and care
PRIUS c_U (OM52J11U)7-1. Maintenance and care
Cleaning and protecting the vehicle exterior .......... 400
Cleaning and protecting the vehicle interior ........... 403
7-2. Maintenance Maintenance requirements ................... 406
General maintenance........ 409
Emission inspection and maintenance
(I/M) programs ................ 412
7-3. Do-it-yourself maintenance
Do-it-yourself service precautions ..................... 413
Hood ................................. 416
Positioning a floor jack ...... 418
Engine compartment ......... 419
12-volt battery ................... 428
Tires .................................. 432
Tire inflation pressure ....... 441
Wheels .............................. 444
Air conditioning filter.......... 446
Wireless remote control/ electronic key battery ...... 448
Checking and replacing fuses ............................... 451
Light bulbs......................... 455

400
PRIUS c_U (OM52J11U)
7-1. Maintenance and care
●Working from top to bottom, liber ally apply water to the vehicle
body, wheel wells and underside of the vehicle to remove any dirt
and dust.
● Wash the vehicle body using a sponge or soft cloth, such as a
chamois.
● For hard-to-remove marks, use car wash soap and rinse thoroughly
with water.
● Wipe away any water.
● Wax the vehicle when the wate rproof coating deteriorates.
If water does not bead on a clean surface, apply wax when the vehicle
body is cool.
■Automatic car washes
●Fold the mirrors before washing the vehicle. Start washing from the fron\
t of
the vehicle. Make sure to extend the mirrors before driving.
● Brushes used in automatic car washes may scratch the vehicle surface and
harm your vehicle's paint.
● In certain automatic car washes, the rear spoiler may interfere with machine
operation. This may prevent the vehicle from being cleaned properly or
result in damage to the rear spoiler.
■ High pressure car washes
●Do not allow the nozzles of the car wash to come within close proximity of
the windows.
● Before using the car wash, check that the fuel filler door on your vehicle is
closed properly.
■ When using a car wash (vehicles with a smart key system)
If the door handle becomes wet while the electronic key is within the ef\
fective
range, the door may lock and unlock repeatedly. In that case, follow the fol-
lowing correction procedures to wash the vehicle:
●Place the electronic key in a location 6 ft. (2 m) or more away from the vehi-
cle. (Take care to ensure that the key is not stolen.)
● Set the electronic key to battery-saving mode to disable the smart key sys-
tem. ( →P. 141)
Cleaning and protecting the vehicle exterior
Perform the following to protect the vehicle and maintain it in
prime condition:
