TOYOTA PRIUS C 2018 Owners Manual (in English)

401
7Maintenance and care
PRIUS c_U (OM52G95U)7-1. Maintenance and care
Cleaning and protecting the vehicle exterior .......... 402
Cleaning and protecting the vehicle interior ........... 405
7-2. Maintenance Maintenance requirements ................... 411
General maintenance........ 414
Emission inspection and maintenance (I/M)
programs......................... 417
7-3. Do-it-yourself maintenance
Do-it-yourself service precautions ..................... 418
Hood ................................. 421
Positioning a floor jack ...... 423
Engine compartment ......... 424
12-volt battery ................... 433
Tires .................................. 437
Tire inflation pressure ....... 446
Wheels .............................. 449
Air conditioning filter.......... 451
Wireless remote control/ electronic key battery ...... 453
Checking and replacing fuses ............................... 456
Light bulbs......................... 460

402
PRIUS c_U (OM52G95U)
7-1. Maintenance and care
●Working from top to bottom, liber ally apply water to the vehicle
body, wheel wells and underside of the vehicle to remove any dirt
and dust.
● Wash the vehicle body using a sponge or soft cloth, such as a
chamois.
● For hard-to-remove marks, use car wash soap and rinse thoroughly
with water.
● Wipe away any water.
● Wax the vehicle when the wate rproof coating deteriorates.
If water does not bead on a clean surface, apply wax when the vehicle
body is cool.
■Automatic car washes
●Fold the mirrors before washing the vehicle. Start washing from the fron\
t of
the vehicle. Make sure to extend the mirrors before driving.
● Brushes used in automatic car washes may scratch the vehicle surface and
harm your vehicle's paint.
● In certain automatic car washes, the rear spoiler may interfere with machine
operation. This may prevent the vehicle from being cleaned properly or
result in damage to the rear spoiler.
■ High pressure car washes
●Do not allow the nozzles of the car wash to come within close proximity of
the windows.
● Before using the car wash, check that the fuel filler door on your vehicle is
closed properly.
■ When using a car wash (vehicles with a smart key system)
If the door handle becomes wet while the electronic key is within the ef\
fective
range, the door may lock and unlock repeatedly. In that case, follow the fol-
lowing correction procedures to wash the vehicle:
●Place the electronic key in a location 6 ft. (2 m) or more away from the vehi-
cle. (Take care to ensure that the key is not stolen.)
● Set the electronic key to battery-saving mode to disable the smart key sys-
tem. ( →P. 140)
Cleaning and protecting the vehicle exterior
Perform the following to protect the vehicle and maintain it in
prime condition:

4037-1. Maintenance and care
7
Maintenance and care
PRIUS c_U (OM52G95U)■
Aluminum wheels (if equipped)
●Remove any dirt immediately by using a neutral detergent.
● Wash detergent off with water immediately after use.
● To protect the paint from damage, make sure to observe the following pre-
cautions.
• Do not use acidic, alkaline or abrasive detergent
• Do not use hard brushes
• Do not use detergent on the wheels when they are hot, such as after driv-
ing or parking in hot weather
■ Bumpers
Do not scrub with abrasive cleaners.
WARNING
■When washing the vehicle
Do not apply water to the inside of the engine compartment. Doing so may
cause the electrical components etc. to catch fire.
■ When cleaning the windshield
Installation area of front sensor on windshield: →P. 228
■ Precautions regarding the exhaust pipe
Exhaust gasses cause the exhaust pipe to become quite hot.
When washing the vehicle, be careful not to touch the pipe until it has
cooled sufficiently, as touching a hot exhaust pipe can cause burns.
NOTICE
■To prevent paint deterioration and corrosion on the body and compo-
nents (aluminum wheels etc.)
● Wash the vehicle immediately in the following cases:
• After driving near the sea coast
• After driving on salted roads
• If coal tar or tree sap is present on the paint surface
• If dead insects, insect droppings or bird droppings are present on the
paint surface
• After driving in an area contaminated with soot, oily smoke, mine dust, iron powder or chemical substances
• If the vehicle becomes heavily soiled with dust or mud
• If liquids such as benzene and gasoline are spilled on the paint surface
● If the paint is chipped or scratched, have it repaired immediately.
● To prevent the wheels from corroding, remove any dirt and store in a place
with low humidity when storing the wheels.

4047-1. Maintenance and care
PRIUS c_U (OM52G95U)
NOTICE
■Cleaning the exterior lights
● Wash carefully. Do not use organic substances or scrub with a hard brush.
This may damage the surfaces of the lights.
● Do not apply wax to the surfaces of the lights.
Wax may cause damage to the lenses.
■ When using a high pressure car wash
● When washing the vehicle, do not spray the camera or its surrounding
area directly with a high pressure washer. Shock applied from high pres-
sure water may cause the device to not operate normally.
● Do not bring the nozzle tip close to boots (rubber or resin manufactured
cover), connectors or the following parts. The parts may be damaged if
they come into contact with high-pressure water.
Do not pull, push, or hold onto either roof molding or attach anything to
them, as the roof molding may be partially removed and water may leak
into the vehicle.
■ Roof molding (if equipped)
Do not hold or pull a roof molding when climbing onto the vehicle or shaking
the vehicle as the roof molding may become disengaged and water may
leak into the vehicle.
• Traction related parts
• Steering parts • Suspension parts
• Brake parts

4057-1. Maintenance and care
7
Maintenance and care
PRIUS c_U (OM52G95U)
●Remove dirt and dust using a va cuum cleaner. Wipe dirty surfaces
with a cloth dampened with lukewarm water.
● If dirt cannot be removed, wipe it off with a soft cloth dampened with
neutral detergent diluted to approximately 1%.
Wring out any excess water from the cloth and thoroughly wipe off
remaining traces of detergent and water.
● Remove dirt and dust using a vacuum cleaner.
● Wipe it off with a soft cloth dam pened with neutral detergent diluted
to approximately 1%.
● Wring out any excess water from the cloth and thoroughly wipe off
remaining traces of detergent and water.
Cleaning and prot ecting the vehicle
interior
The following procedures will help protect your vehicle's interior
and keep it in top condition:
Protecting the vehicle interior
Cleaning the synthetic leather areas

4067-1. Maintenance and care
PRIUS c_U (OM52G95U)
To prevent the hybrid battery (traction battery) air intake vent from
becoming clogged, clean it periodically.
■Cleaning the air intake vent
Remove any dust and clogs
from the air intake vent with a
vacuum cleaner, etc.
The air intake vent has a filter
behind the air intake vent cover.
If “MAINTENANCE REQUIRED FOR TRACTION BATTERY
COOLING PARTS SEE OWNER’S MANUAL” is displayed on the
multi-information display, the filt er may be clogged. Remove the air
intake vent cover and clean the filter.
■Cleaning the air intake vent filter
The air intake vent filter is
located below the rear seat
cushion on the left side.
Remove the 2 clipsPush in the center part of
the clips
Remove the clips
Cleaning the hybrid battery (traction battery) air intake vent
1
1
2

4077-1. Maintenance and care
7
Maintenance and care
PRIUS c_U (OM52G95U)
Disengage the 3 clips and 3
guides on the back of the
cover and remove the air
intake vent cover.Guides
Clips
Remove any dust and clogs
from the filter using a vac-
uum cleaner, etc.
Make sure to also remove dust
and clogs from the inner side of
the air intake vent cover.
If the filter is damaged, have it
replaced by your Toyota dealer.
Install the air intake vent
cover. Guides
Clips
Check if the clips and guides
on the back of the cover are
engaging properly if the cover
cannot be installed.
Install the 2 clips.Push out the center part of
the clips
Insert the clips
Push in the center part of
the clips
2
1
2
3
4
1
2
5
1
2
3

4087-1. Maintenance and care
PRIUS c_U (OM52G95U)
Start the hybrid system and check that “MAINTENANCE
REQUIRED FOR TRACTION BATTERY COOLING PARTS SEE
OWNER’S MANUAL” is no longer displayed on the multi-infor-
mation display.
It may take approximately 20 minutes for the warning message to
disappear after the hybrid system is started. If the warning mes-
sage does not disappear even th ough the filter has been cleaned,
have the vehicle inspected by your Toyota dealer.
■Caring for leather areas
Toyota recommends cleaning the interior of the vehicle at least twice a year to
maintain the quality of the vehicle's interior.
■ Shampooing the carpets
There are several commercial foaming-type cleaners available. Use a sponge
or brush to apply the foam. Rub in overlapping circles. Do not use water.
Wipe dirty surfaces and let them dry. Excellent results are obtained by keep-
ing the carpet as dry as possible.
■ Air intake vent maintenance
●If the vehicle is driven with the air intake vent clogged, the hybrid battery
(traction battery) may overheat and the fuel consumption may increase.
● Depending on the conditions under which the vehicle is used, the air intake
vent may need to be cleaned more regularly.
■ Seat belts
Clean with mild soap and lukewarm water using a cloth or sponge. Also
check the belts periodically for excessive wear, fraying or cuts.
■ Cleaning the air intake vent filter
●Improper handling of the air intake vent cover and filter may result in dam-
age to them. If you have any concerns about cleaning the filter, contact your
Toyota dealer.
● If the vehicle is driven with the air intake vent filter clogged, the hybrid bat-
tery (traction battery) may overheat and the fuel consumption may increase.
● Depending on the conditions under which the vehicle is used, the air intake
vent filter may need to be cleaned more regularly.
6

4097-1. Maintenance and care
7
Maintenance and care
PRIUS c_U (OM52G95U)■
If “MAINTENANCE REQUIRED FOR TRACTION BATTERY COOLING
PARTS SEE OWNER’S MANUAL” is di splayed on the multi-information
display
● It is possible the air intake vent or filter is clogged due to accumulated dust.
Clean the air intake vent and filter, referring to the cleaning method.
● When continuously driven in this state, the hybrid battery (traction battery)
may overheat, which may lead to the driving distance by the electric motor
getting shorter, the fuel consumption worsening, and causing damage.
Clean the air intake vent periodically to prevent dust, etc., from collecting in
the air intake vent or filter.
● If the massage in the multi-information display does not turn off, even if the
air intake vent is cleaned, have the vehicle inspected at your Toyota dealer.
WARNING
■Water in the vehicle
● Do not splash or spill liquid in the vehicle, such as on the floor, in the
hybrid battery (traction battery) air vents, and in the luggage compartment.
Doing so may cause the hybrid battery, electrical components, etc. to mal-
function or catch fire.
● Do not get any of the SRS components or wiring in the vehicle interior wet.
(→P. 41)
An electrical malfunction may cause the airbags to deploy or not function
properly, resulting in death or serious injury.
■ Cleaning the interior (especially instrument panel)
Do not use polish wax or polish cleaner. The instrument panel may reflect
off the windshield, obstructing the driver's view and leading to an accident,
resulting in death or serious injury.
■ When cleaning the hybrid battery (tr action battery) air intake vent/filter
● Do not use water or other liquids to clean the air intake vent/filter. If water
is applied to the hybrid battery (traction battery) or other components, a
malfunction or fire may occur.
● When the air intake vent cover, located below the rear seat cushion on the
left side is to be removed, make sure to turn the power switch off to stop
the hybrid system.

4107-1. Maintenance and care
PRIUS c_U (OM52G95U)
NOTICE
■Cleaning detergents
● Do not use the following types of detergent, as they may discolor the vehi-
cle interior or cause streaks or damage to painted surfaces:
• Non-seat portions: Organic substances such as benzene or gasoline,
alkaline or acidic solutions, dye, and bleach
• Seats: Alkaline or acidic solutions, such as thinner, benzene, and alco- hol
● Do not use polish wax or polish cleaner. The instrument panel's or other
interior part's painted surface may be damaged.
■ Preventing damage to leather surfaces
Observe the following precautions to avoid damage to and deterioration of
leather surfaces:
● Remove any dust or dirt from leather surfaces immediately.
● Do not expose the vehicle to direct sunlight for extended periods of time.
Park the vehicle in the shade, especially during summer.
● Do not place items made of vinyl, plastic, or containing wax on the uphol-
stery, as they may stick to the leather surface if the vehicle interior heats
up significantly.
■ Water on the floor
Do not wash the vehicle floor with water.
Vehicle systems such as the audio system may be damaged if water comes
into contact with electrical components such as the audio system above or
under the floor of the vehicle. Water may also cause the body to rust.
■ Cleaning the inside of the rear window
● Do not use glass cleaner to clean the rear window, as this may cause
damage to the rear window defogger heater wires. Use a cloth dampened
with lukewarm water to gently wipe the window clean. Wipe the window in
strokes running parallel to the heater wires.
● Be careful not to scratch or damage the heater wires.
