TOYOTA PRIUS C 2018 Owners Manual (in English)

4617-3. Do-it-yourself maintenance
7
Maintenance and care
PRIUS c_U (OM52G95U)■
Front
Front turn signal light/parking light
■Rear
Bulb locations
1
Rear turn signal light
Back-up light License plate lights1
2
3

4627-3. Do-it-yourself maintenance
PRIUS c_U (OM52G95U)■
Front turn signal
lights/parking lights
Turn the bulb base counter-
clockwise.
Remove the light bulb.
When installing, reve rse the steps listed.
Replacing light bulbs
1
2
3

4637-3. Do-it-yourself maintenance
7
Maintenance and care
PRIUS c_U (OM52G95U)■
Rear turn signal lights and back-up lights
Open the back door and
remove the bolts. Pull the
lamp assembly straight back
to disengage the clip and 2
pins.Guide (where the clip
attaches)
Pin
Turn the bulb base counter-
clockwise. Rear turn signal light
Back-up light
Remove the light bulb. Rear turn signal light
Back-up light
1
1
2
2
1
2
3
1
2

4647-3. Do-it-yourself maintenance
PRIUS c_U (OM52G95U)
When installing the light bulb, install by conducting and
with the directions reversed.
Install the lamp assembly
and then install the 2 bolts.
When installing the lamp assem-
bly, align the guide (where the
clip attaches) and pins of
the lamp assembly with the con-
necting parts on the vehicle
body.
432
5
12

4657-3. Do-it-yourself maintenance
7
Maintenance and care
PRIUS c_U (OM52G95U)■
License plate lights
Remove the lens.Insert a properly sized
screwdriver into the hole of
the lens.
Push the screwdriver side-
ways in the direction of the
arrow shown in the illustra-
tion, disengage the hook,
and then remove the lens.
To prevent damaging the
vehicle, wrap the screwdriver
with a tape.
Remove the light bulb.
Install a new light bulb.
Lens
1
1
Hook
2
2
3

4667-3. Do-it-yourself maintenance
PRIUS c_U (OM52G95U)
Install the lens.Fit the lens into either the
right or left hooks.
Push the lens into place.
After installation, confirm that
the lens is properly installed
by gently pulling it.
■Lights other than the above
If any of the lights listed below has burnt out, have it replaced by
your Toyota dealer.
● Headlights/daytime running lights
● Front fog lights (if equipped)
● Side marker lights
● Side turn signal lights
● Stop/tail lights
● High mounted stoplight
Hooks
4
1
2

4677-3. Do-it-yourself maintenance
7
Maintenance and care
PRIUS c_U (OM52G95U)
■LED light bulbs
The headlights/daytime running lights, front fog lights (if equipped), side
marker lights, stop/tail lights and high mounted stoplight consist of a number
of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer
to have the light replaced.
■ Condensation build-up on the inside of the lens
Temporary condensation build-up on the inside of the headlight lens does not
indicate a malfunction. Contact your Toyota dealer for more information in the
following situations:
●Large drops of water have built up on the inside of the lens.
● Water has built up inside the headlight.
WARNING
■Replacing light bulbs
● Turn off the lights. Do not attempt to replace the bulb immediately after
turning off the lights.
The bulbs become very hot and may cause burns.
● Do not touch the glass portion of the light bulb with bare hands. When it is
unavoidable to hold the glass portion, use and hold with a clean dry cloth
to avoid getting moisture and oils on the bulb.
Also, if the bulb is scratched or dropped, it may blow out or crack.
● Fully install light bulbs and any parts used to secure them. Failure to do so
may result in heat damage, fire, or water entering the headlight unit. This
may damage the headlights or cause condensation to build up on the lens.
■ To prevent damage or fire
Make sure bulbs are fully seated and locked.

4687-3. Do-it-yourself maintenance
PRIUS c_U (OM52G95U)

469
8When trouble arises
PRIUS c_U (OM52G95U)8-1. Essential information
Emergency flashers .......... 470
If your vehicle has to be stopped in an
emergency ...................... 471
8-2. Steps to take in an emergency
If your vehicle needs to be towed ..................... 473
If you think something is wrong .............................. 480
If a warning light turns on or a warning buzzer
sounds ............................ 481
If a warning message is displayed......................... 490
If you have a flat tire.......... 507
If the hybrid system will not start ........................... 520
If the electronic key does not operate properly........ 522
If the vehicle 12-volt battery is discharged ....... 524
If your vehicle overheats ........................ 531
If the vehicle becomes stuck ............................... 535

470
PRIUS c_U (OM52G95U)
8-1. Essential information
Press the switch.
All the turn signal lights will flash.
To turn them off, press the switch
once again.
■Emergency flashers
If the emergency flashers are used for a long time while the hybrid system is
not operating (while the “READY” indicator is not illuminated), the 12-volt \
bat-
tery may discharge.
Emergency flashers
The emergency flashers are used to warn other drivers when the
vehicle has to be stopped in th e road due to a breakdown, etc.
