TOYOTA PRIUS C 2018 (in English) User Guide
Manufacturer: TOYOTA, Model Year: 2018, Model line: PRIUS C, Model: TOYOTA PRIUS C 2018Pages: 48, PDF Size: 1.92 MB
Page 11 of 48
9
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
Engine maintenance
Engine coolant reservoir
Engine oil filler cap
Engine oil level dipstick
Windshield washer fluid tank
NOTE: Regularly scheduled maintenance, including oil changes, will help
extend the life of your vehicle and maintain performance. Please refer to the
“Warranty & Maintenance Guide.”
Maintenance reset light instructions can be found in “Maintenance Req\
uirements
Chapter” in Owner’s Manual.
Page 12 of 48
10
FEATURES & OPERATIONS
The Hybrid Synergy Drive System utilizes a computer-controlled gasoline \
engine
and electric motor to provide the most efficient combination of power fo\
r the
vehicle. To conserve energy, when the brakes are applied the braking for\
ce
generates electricity which is then sent to the traction battery. In add\
ition, the
engine shuts off when the vehicle is stopped. The benefits are better fu\
el economy,
reduced vehicle emissions and improved performance.
NOTE: Fuel consumption and energy information of the Hybrid System are shown on the multi-information display or the Display Audio System.
-Ensure tire pressures are maintained at levels specified in the Owner’\
s Manual.
-When possible, link trips to reduce engine cold starts.
-Avoid driving at speeds that are higher than necessary, especially on t\
he highway.
-When possible, avoid sudden stops to maximize regenerative braking ener\
gy.
-Minimize use of the Air Conditioning.
(1) Put the selector lever in “P.”
(2) Vehicles with Smart Key system:
Depress the brake pedal, and press the “POWER” switch briefly and \
firmly.
Vehicles without Smart Key system:
Depress the brake pedal, and turn the key to the “START” position.\
(3) The “READY” light will blink. After a few seconds, when the \
light remains
steady and a beep sounds, you may begin driving.
Hybrid Synergy Drive System
TIPS FOR IMPROVED FUEL ECONOMY
STARTING THE HYBRID SYSTEM
Page 13 of 48
11
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
Hybrid transmission
Drive mode
ECO MODE
EV MODE
1 The “POWER”/ignition switch must be “ON” and the brake pedal\
depressed to
shift from Park.
2 The engine brake is the equivalent of downshifting. Shift to “B” w\
hen engine
braking is desired (e.g. downhill driving, coasting to a stop).
Park1
Reverse
Neutral
Drive
Engine brake2
Push
Eco Mode helps achieve low fuel consumption during trips that involve fr\
equent
accelerating and braking.
Refer to the Owner’s Manual for more details.
EV Drive Mode allows the electric motor (traction motor), powered by t\
he hybrid
battery (traction battery), to be used to drive the vehicle under cert\
ain driving
conditions.
Push
Page 14 of 48
12
Lock release buttonLock release buttons
FRONT (ADJUSTABLE TYPE)/REAR CENTER
REAR OUTBOARD
Seats-Head restraints
Seat adjustments-Front
Seat position (forward/backward) Height crank
(driver side; if equipped)Seatback angle
FEATURES & OPERATIONS
Page 15 of 48
13
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
SPLIT REAR SEATS
NON-SPLIT REAR SEAT
Seat-Folding down rear seat
Windows-Power
(1) Pull up
(2) Fold down
(1) Pull up
(2) Fold down
Up
Window lock switch
Automatic operation (driver side only) Push the switch completely down or pull
it completely up and release to fully open or close. To stop the window \
partway,
operate the switch in the opposite direction.
Window lock switch Deactivates all passenger windows. Driver’s window remains
operable. Driver side
Down
Page 16 of 48
14
Wash and wipeWipe
Interval wipe
Wash and wipe *
Single wipe
Slow
Fast
Pull to wash and wipe
Interval wipe
Single wipe
Slow
Fast
Pull to wash and wipe
Type AType B
Adjust frequency*Adjust frequency *
* Intermittent windshield wiper frequency adjustment Rotate to increase/
decrease wipe frequency. (if equipped)
Type A
Type B
* The wipers will automatically operate a couple of times after the washe\
r squirts.
FRONT
REAR (IF EQUIPPED)
Wash and wipe
Wipe
Interval wipe
Wash and wipe *
Interval wipe
FEATURES & OPERATIONS
Windshield wipers & washers
Page 17 of 48
15
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
TurnTurn
Lights & turn signals
Daytime Running Light system (DRL) Automatically turns on the headlights at a
reduced intensity.
Low beam
High beam
High beam flasher
Front fog lights come on only when the headlights are on low beam.
Right turn
Lane change
Lane change Left turn
Parking lights Headlights
OFF
DRL
Parking lights Headlights
DRL
Type A
Type A
Type B
Type B
HEADLIGHTS
FRONT FOG LIGHTS (IF EQUIPPED)
TURN SIGNALS
Page 18 of 48
16
FEATURES & OPERATIONS
Automatic air conditioning/heating
Seat heaters (if equipped)
Push
PushDriver seat
Front passenger seat
Automatic climate control ON
Adjusting the temperature setting will cause
the airflow vents, air intake and fan to adjust
automatically.
Temperature setting display
Fan speed display Airflow mode display
Windshield defogger
Outside heated rearview
mirror/Rear window defogger
(if equipped)
Fan speed control Recirculate cabin air
(outside air when OFF)
Airflow vent
In “
” mode, use outside air (“” indicator
OFF)
to
reduce window fogging.
Climate control OFF
Air Conditioning ON/OFF
Temperature selector dial
Page 19 of 48
17
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
Moonroof (if equipped)
Auto lock/unlock
Recommended open position to
minimize wind noise.
Open
Close Push once to open to recommended
position; again to open completely.Close
Tilt
Push once to open; moonroof will automatically stop at the recommended p\
osition.
Push again to open completely.
SLIDING OPERATION
TILTING OPERATION
Automatic door locks can be programmed to operate in different modes, or\
turned
OFF.
Shift position linked door locking/unlocking function
-Doors lock when shifting from Park.
-Doors unlock when shifting into Park.
Speed linked door locking function
-Doors lock when the vehicle speed goes above approximately 12 mph.
Driver’s door linked door unlocking function
-Doors unlock when the engine switch is set from “ON” to “ACC”\
or “LOCK” and driver’s door is opened.
-(With Smart Key) Doors unlock when the “ENGINE START STOP” swit\
ch is set to OFF and driver’s door is opened.
Refer to the Owner’s Manual for more details.
Page 20 of 48
18
FEATURES & OPERATIONSAudio
Power outlet-12V DC
For vehicles with a “POWER” button, make sure vehicle is in “PO\
WER ON” mode.
Or, for vehicles with an ignition switch, key must be in the “ACC”\
or “ON” position
for use.
Touch screen displayEject CD
Seek station/
CD track select
Push to turn
ON/OFF
Push to
display audio
screen
Turn to tune
radio stations
manually or
select tracks
or files
Refer to the “Navigation System Owner’s Manual” and “2018 En\
tune™ Audio
Quick Reference Guide.”
Press to
display
APPS
Press to
display
Home
screen
MAP card insert
ENTUNE™ AUDIO
ENTUNE™ PREMIUM AUDIO WITH INTEGRATED NAVIGATION AND APP SUITE
