TOYOTA PRIUS C 2018 (in English) Owner's Manual

19
USB/AUX port
Steering wheel switches
Audio controlsMeter controls
“MODE”
Push to change audio source, mute or pause the current operation. To mut\
e or
pause the current operation, press and hold. To cancel the mute or pause\
, press
and hold again.
“/” or “/” Use the steering wheel controls to your left, to search within the selec\
ted audio
medium (radio, CD, etc.). Use the steering wheel controls to your righ\
t, to scroll
through menu items and select or return to the previous screen.
“
”
Push and hold to access mobile assistant. Once you connect a compatible,\

registered mobile phone, you can access Siri Eyes Free using mobile assi\
stant
switch.
Refer to Owner’s Manual for more details.
Volume
controlScroll up/down or select menuEnter/select
Previous screen
Phone switches
Talk switch
Mobile assistant switch
USB port
By connecting a USB-compatible portable audio device or USB memory stick\
to the
USB port, you can listen to music from the portable audio device or USB \
memory
stick through the vehicle’s speaker system.
AUX port
By inserting a mini plug into the AUX port, you can listen to music from\
a portable
audio device through the vehicle’s speaker system while in AUX mode.
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES

20
Cruise control
Parking brake
FEATURES & OPERATIONS
1 The set speed may also be cancelled by depressing the brake pedal.
System ON/OFF
Increase speed
Decrease speed
Cancel1
Resume
Set
Set Release
Pull(2) Push(1) Pull slightly
(3) Lower
TURNING SYSTEM ON/OFF
FUNCTIONS

21
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
Tilt & telescopic steering wheel
Multi-Information Display (MID)
Display Meter controls
Hold wheel, push lever down, set angle and length, and return lever.
NOTE: Do not attempt to adjust while the vehicle is in motion.
Angle
Length
Lock release lever
(1) Drive information
(2) Settings and screen OFF
(3) Warning messages
(4) Menu icons
Menu icons
Drive information
ECO fuel consumption information
LDA operational status
Settings display
Push
“/” or “/” to scroll through the following information screens:
* Factory default is OFF. To activate, access settings through “Settin\
gs &
Screen Off.”
Scroll up/down or select menu
Enter/select
Previous screen

22
FEATURES & OPERATIONSClock
Telephone controls (Bluetooth®)
Bluetooth® technology allows dialing or receipt of calls without taking hands from\

the steering wheel or using a cable to connect the telephone and the sys\
tem.
Refer to “Bluetooth
® Device Pairing Section,” in this guide, for more information
about phone connections and compatibility.
Microphone (Type A, with moonroof)
Audio unitSteering wheel telephone switches
Volume
Start call or
Siri
® Eyes Free
switch
End call
Microphone (Type B, without moonroof)
Display
Meter control switches
(1) Press “” switches and select from the Multi-Information Display (MID).
(2) Press “
” switches and press “” to select Meter Settings screen.
(3) Press “
” to select Time and date screen.
(4) Press “
” switches and press “” to select Clock screen to adjust time.
You can press “
” to go back to the previous screen at any time.
Scroll up/down or select menu
Enter/select
Previous screen

23
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
Hill-start Assist Control (HAC)
HAC helps prevent rolling backwards on an incline. To engage, push furth\
er down
on brake pedal while at a complete stop until a beep sounds and slip ind\
icator
illuminates. HAC holds for approximately two seconds after releasing bra\
ke pedal.
Refer to the Owner’s Manual for more details.
Brake
pedal
Rear view monitor system
The rear view monitor system displays an image of the view from the bump\
er of
the rear area of the vehicle. The camera for the rear view monitor syste\
m is located
above the license plate.
To adjust the image on the rear view monitor screen, press the “SETUP\
” button
and select “Display” on the “Setup” screen. Select “Came\
ra” to adjust the screen
contrast and brightness.
Refer to the Owner‘s Manual for limitations and more details on this \
system.
Corners of bumper
Vehicle Stability Control (VSC)/TRAC OFF switch
The VSC OFF switch can be used to help free a stuck vehicle in surroundi\
ngs like
mud, dirt or snow. While car is stopped, press switch to disable the TRA\
C system.
To disable both VSC and TRAC systems, press the switch for at least 3 se\
conds.
Refer to the Owner’s Manual for more details.
Push

24
Pre-Collision System (PCS)PCS is designed to provide alert, mitigation, and/or avoidance
support in certain conditions, when the system detects a potential
collision with a preceding vehicle is likely to occur.
Lane Departure Alert (LDA)LDA is designed to provide notification when the system detects
an unintended lane departure.
Automatic High Beams (AHB)
AHB is designed to detect the headlights of oncoming vehicles
and the tail lights of preceding vehicles and switch between high
beams and low beams as appropriate.
Laser sensor
Camera sensor
Quick overview-Toyota Safety Sense™ C (TSS-C)
Sensors
TOYOTA SAFETY SENSE™
Toyota Safety Sense™ C (TSS-C) is a set of active safety technologies designed to
help mitigate or prevent collisions across a wide range of traffic situa\
tions, in certain
conditions. TSS-C is designed to help support the driver’s awareness,\
decision making
and vehicle operation contributing to a safe driving experience.
Refer to the Owner’s Manual for operation, setting adjustments, limit\
ations and
more details to understand these functions and complete safety precautio\
ns. For
more information, please go to http://www.toyota.com/safety-sense.
TSS-C combines an in-vehicle camera and laser mounted in front of the in\
side rear
view mirror. These sensors support the driver assist systems.

25
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
Pre-Collision System (PCS)
The Pre-Collision System uses a laser sensor and camera sensor to help d\
etect
vehicles in front of your vehicle.
As there is a limit to the degree of recognition accuracy and control pe\
rformance that
this system can provide, do not overly rely on this system. This system \
will not prevent
collisions or lessen collision damage or injury in every situation. Do n\
ot use PCS
instead of normal braking operations under any circumstances. Do not att\
empt to test
the operation of the Pre-Collision System yourself, as the system may no\
t operate or
engage, possibly leading to an accident. In some situations, such as whe\
n driving in
inclement weather such as heavy rain, fog, snow or a sandstorm or while \
driving on a
curve and for a few seconds after driving on a curve, a vehicle may not \
be detected
by the laser and camera sensors, preventing the system from operating or\
engaging
properly.
Refer to a Toyota Owner’s Manual for a list of additional situations \
where the system
may not operate, or system effectiveness is limited.
Refer to the Toyota Owner’s Manual for additional information on PCS \
operation,
settings adjustments, limitations, and precautions before attempting to \
use it. Pre-Collision Warning
When the system determines that the possibility of a frontal collision i\
s high, a buzzer
will sound and a warning message will be displayed on the Multi-Informat\
ion Display
(MID) to urge the driver to take evasive action.
Pre-Collision Brake Assist
If the driver notices the hazard and brakes, the system may provide addi\
tional braking
force using Brake Assist. This system may prime the brakes and may apply\
greater
braking force in relation to how strongly the brake pedal is depressed.
Pre-Collision Braking
If the driver does not brake in a set time and the system determines tha\
t the possibility
of a frontal collision with a preceding vehicle is extremely high, the s\
ystem may
automatically apply the brakes, reducing speed in order to help the driv\
er reduce the
impact and in certain cases avoid the collision.

26
CHANGING THE PRE-COLLISION ALERT TIMING
DISABLING THE PRE-COLLISION SYSTEM (PCS)
Each time the PCS switch is pressed, the response to the PCS alert timin\
g changes.
To disable the system
Press the PCS switch for 3 seconds or more.
The
will turn on and a message will be displayed on the
Multi-Information Display (MID).
To enable the system
Press the PCS switch again.
The system is enabled.
Note: PCS is enabled each time the engine switch is turned to Ignition O\
n.
The system can be disabled/enabled and the alert timing of the system ca\
n be
changed. (Alert timing only, brake operation remains the same).
Far
Middle
(default)
Near
TOYOTA SAFETY SENSE™

27
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
Press the LDA switch to turn the LDA system on. Depress again to turn it\
off.
Note: Operation of the LDA system and setting adjustments continues in t\
he
same condition regardless of Ignition cycle until changed by the driver \
or the
system is reset.
Refer to the Toyota Owner’s Manual for additional information on LDA \
operation,
settings adjustments, limitations, and precautions before attempting to \
use it.
Lane Departure Alert (LDA)
TURNING ON THE LDA SYSTEM
LDA in TSS-C uses an in-vehicle camera designed to detect visible white \
and yellow
lane markers in front of the vehicle and the vehicle’s position on th\
e road. If the system
determines that the vehicle is starting to unintentionally deviate from \
its lane, the system
alerts the driver with an audio and visual alert. When the alerts occur,\
the driver must
check the surrounding road situation and carefully operate the steering \
wheel to move
the vehicle back to the center part of their lane.
LDA is designed to function at speeds of approximately 32 MPH or higher \
on relatively
straight roadways.

28
LDA FUNCTIONS
The LDA function displays when the Multi-Information Display (MID) is \
switched to the
driving assist system information screen.Note: When operation conditions are no longer met, a function may be
temporarily canceled. However, when the operation conditions are met aga\
in,
operation of the function is automatically restored. For example, LDA ma\
y not
function on the side(s) where white/yellow lines are not detectable.
Refer to the Toyota Owner’s Manual for additional information on LDA \
operation,
settings adjustments, limitations, and precautions before attempting to \
use it. The system displays solid white lines
on the LDA indicator when visible lane
markers on the road are detected. A
side flashes orange to alert the driver
when the vehicle deviates from its lane.
The system displays outlines on the
LDA indicator when lane markers on the
road are not detected or the function is
temporarily cancelled.
TOYOTA SAFETY SENSE™
Lane Departure Alert (LDA) indicator flashes orange when operating.LDA function display
Lane
