TOYOTA PRIUS C 2019 Owners Manual (in English)

5318-2. Steps to take in an emergency
8
When trouble arises
PRIUS c_U
NOTICE
■To avoid damage to the trans mission and other components
● Avoid spinning the wheels and depressing the accelerator pedal more
than necessary.
● If the vehicle remains stuck even after these procedures are pe rformed,
the vehicle may require towing to be freed.

5328-2. Steps to take in an emergency
PRIUS c_U

533
9Vehicle specifications
PRIUS c_U9-1. Specifications
Maintenance data (fuel, oil level, etc.) .......... 534
Fuel information ................ 543
Tire information ................. 546
9-2. Customization Customizable features ...... 558
Items to initialize ............... 563

534
PRIUS c_U
9-1.Specifications
*1: Unladen vehicles
*2: Without roof molding
*3: With roof molding
*4: P175/65R15 tires
*5: P195/50R16 tires
Maintenance data (fuel, oil level, etc.)
Dimensions and weights
Overall length159.4 in. (4050 mm)*2
159.8 in. (4060 mm)*3
Overall width66.7 in. (1695 mm)*2
67.5 in. (1715 mm)*3
Overall height*157.3 in. (1455 mm)*2
58.7 in. (1490 mm)*3
Wheelbase
100.4 in. (2550 mm)
Tread
Front58.5 in. (1485 mm)*4
57.5 in. (1460 mm)*5
Rear58.1 in. (1475 mm)*4
57.1 in. (1450 mm)*5
Vehicle capacity weight
(Occupants + luggage) 845 lb. (380 kg)

5359-1. Specifications
9
Vehicle specifications
PRIUS c_U■
Vehicle identification number
The vehicle identification number (VIN) is the legal identifier
for
your vehicle. This is the primary identification number for you r
Toyota. It is used in registeri ng the ownership of your vehicle .
This number is stamped under
the front passenger’s seat.
This number is stamped on the
top left of the instrument panel.
This number is also on the Cer-
tification Label.
Vehicle identification

5369-1. Specifications
PRIUS c_U■
Engine number
The engine number is stamped
on the engine block as shown.
Engine
Model
1NZ-FXE
Type4-cylinder in line, 4-cycle, gasoline
Bore and stroke 2.95  3.33 in. (75.0  84.7 mm)
Displacement 91.3 cu. in. (1496 cm3)
Valve clearance
(engine cold)Intake: 0.006  0.010 in. (0.15  0.25 mm)
Exhaust: 0.010
 0.014 in. (0.25  0.35 mm)
Fuel
Fuel type Unleaded gasoline only
Octane rating 87 (Research octane number 91) or higher
Fuel tank capacity
(Reference)9.5 gal. (36 L, 7.9 Imp. gal.)
Electric motor (t
raction motor)
Type Permanent magnet synchronous motor
Maximum output 45 kW
Maximum torque 125 ft•lbf (169 N•m, 17.2 kgf•m)

5379-1. Specifications
9
Vehicle specifications
PRIUS c_U
*: The engine oil capacity is a reference quantity to be used when changing
the engine oil. Warm up the engine and turn off the hybrid system, wait
more than 5 minutes, and check the oil level on the dipstick.
■
Engine oil selection
“Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat isfy
the following grade and viscosity.
Oil grade: ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice
for good fuel economy and
good starting in cold weather.
If SAE 0W-20 is not available,
SAE 5W-20 oil may be used.
However, it must be replaced
with SAE 0W-20 at the next oil
change.
Hybrid battery (traction battery)
Type Nickel-metal hydride battery
Voltage7.2 V/module
Capacity 6.5 Ah (3HR)
Quantity20 modules
Overall voltage 144 V
Lubrication system
Oil capacity (Drain and
refill reference
*)
With filter
Without filter 3.9 qt. (3.7 L, 3.3 Imp. qt.)
3.6 qt. (3.4 L, 3.0 Imp. qt.)
Outside temperature

5389-1. Specifications
PRIUS c_U
Oil viscosity (0W-20 is explained here as an example):
• The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils wi th a lower value before the W allow
for easier starting of the engine in cold weather.
• The 20 in 0W-20 indicates the vi scosity characteristic of the oil
when the oil is at high temperature. An oil with a higher visco sity
(one with a higher value) may be better suited if the vehicle i s
operated at high speeds, or un der extreme load conditions.
How to read oil container label:
The International Lubricant
Specification Advisory Commit-
tee (ILSAC) Certification Mark
is added to some oil containers
to help you select the oil you
should use.
Cooling system
Capacity Gasoline engine
Power control unit 5.6 qt. (5.3 L, 4.7 Imp. qt.)
1.7 qt. (1.6 L, 1.4 Imp. qt.)
Coolant type Use either of the following:
• “Toyota Super Long Life Coolant”
• A similar high-quality ethylene glycol-
based non-silicate, non-amine, non-
nitrite, and non-borate coolant with long-
life hybrid organic acid technology
Do not use plain water alone.

5399-1. Specifications
9
Vehicle specifications
PRIUS c_U
Ignition system
Spark plug
Make
GapDENSO FK16R-A8
0.03 in. (0.8 mm)
NOTICE
■
Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust the spark pl ug gap.
Electrical system
12-volt battery
Open voltage at
68 F (20 C): 12.0 V or higher
If the voltage is lower than the standard value,
charge the battery.
(Voltage checked 20 minutes after the hybrid sys-
tem and all the lights are turned off)
Charging rates
Quick charge
Slow charge 15 A max.
5 A max.

5409-1. Specifications
PRIUS c_U
*: The fluid capacity is a reference quantity. If replacement is necessary, con-
tact your Toyota dealer.
*1: Minimum pedal clearance when depressed with a force of 66 lbf (294 N, 30
kgf) while the hybrid system is operating
*2: Parking brake lever travel when pulled up with a force of 45 l bf (200 N, 20
kgf)
Hybrid transmission
Fluid capacity*3.5 qt. (3.3 L, 2.9 Imp. qt.)
Fluid type Toyota Genuine ATF WS
NOTICE
■Transmission fluid type
Using transmission fluid other than “Toyota Genuine ATF WS” may ulti-
mately damage the hybrid transmission of your vehicle.
Brakes
Pedal clearance*12.8 in. (70 mm) Min.
Pedal free play 0.04  0.24 in. (1.0  6.0 mm)
Brake pad wear limit 0.04 in. (1.0 mm)
Brake lining wear limit 0.04 in. (1.0 mm)
Parking brake lever travel*28  11 clicks
Fluid typeSAE J1703 or FMVSS No.116 DOT 3
Steering
Free playLess than 1.2 in. (30 mm)
