972. Instrument cluster
2
Instrument cluster
PRIUS c_U
The units used on the meters may differ depending on the target
region.Speedometer
Displays the vehicle speed.
Shift position display
Displays the selected shift position. ( P. 200)
Outside temperature
Displays the outside temperature within the range of -40°F (-40 °C) to
122°F (50°C). Low outside temperat ure indicator comes on when the
ambient temperature is 37°F (3°C) or lower.
Clock
Change the time on the settings screen. ( P. 1 0 6 )
Multi-information display
Presents the driver with a variety of driving-related data. ( P. 101)
Fuel gauge
Displays the quantity of fuel remaining in the tank.
Odometer/trip meter
P. 9 8
Average fuel consumption
Depending on whether the odometer or trip meter is displayed, t he
displayed contents differ. Use the displayed average fuel consu mp-
tion as a reference.
● When the odometer is displayed: the average fuel consumption
since the hybrid system was started is displayed.
Gauges and meters
1
2
3
4
5
6
7
8

982. Instrument cluster
PRIUS c_U
●When the trip meter is displaye d: the average fuel consumption
since the trip meter was reset is displayed. The average fuel c on-
sumption for trip meter A and trip meter B is displayed separat ely.
When the trip meter is reset, average fuel consumption is also reset.
( P. 98)
◆Changing the display
Items in this area are operated using the “TRIP” switch.
Press: Change displayed item
Each time the switch is pressed,
the displayed item will be
changed.
Press and hold: Reset
Display the desired trip meter
and press and hold the switch to
reset the trip meter.
◆Display items
■Odometer
Displays the total distance the vehicle has been driven.
■Trip meter A/trip meter B
Displays the distance the vehicl e has been driven since the met er
was last reset. Trip meters A and B can be used to record and d is-
play different distances independently.
To reset, display the desired trip meter and press and hold the “TRIP”
switch.
Odometer/trip meter

1022. Instrument cluster
PRIUS c_U
◆Operating the meter control switches
The multi-information display is operated using the meter control
switches.
: Select menu icons
: Change displayeditem, scroll up/down
the screen and
move the cursor up/
down
Enter switch
Press: Enter/Set
Press and hold: Reset
Return to the previous screen
◆Drive Information
Depending on whether the odometer or trip meter is displayed, t he
displayed contents of average speed, driving time, and EV drivi ng
rate/EV driven distance differ.
● When the odometer is displayed: the record since the hybrid sys -
tem was started is displayed.
● When the trip meter is displayed: the record since the trip met er
was reset is displayed. The record for trip meter A and trip me ter
B is displayed separately.
When the trip meter is reset, the record is also reset. ( P. 98)
■
(average speed)
Average speed will be displayed.
■ (driving time)
Driving time will be displayed.
■ (EV driving rate/EV driven distance)
EV driving rate and driven distance (percentage and distance
driven using just the electric motor [traction motor] only) wil l be dis-
played.
1
2
Driving information
3
AV G

1042. Instrument cluster
PRIUS c_U
◆ECO Savings
Displays the cost of the con-
sumed fuel or the fuel economy,
depending on the data entered
for eco savings.Savings and fuel cost
If the fuel consumption comparison is input ( P. 106), the possi-
ble savings are displayed. If the fuel consumption comparison
has not been input, your vehicle's actual fuel cost will be dis -
played.
Depending on whether the odometer or trip meter is displayed,
the displayed contents differ.
● When the odometer is displayed: the savings or fuel cost since
the hybrid system was started is displayed.
● When the trip meter is displayed: the savings or fuel cost since
the trip meter was reset is displayed. The savings or fuel cost
for trip meter A or trip meter B is displayed separately.
When the trip meter is reset, savings or fuel cost is also rese t.
( P. 98)
“Fuel Cons. Comparison”
On the settings screen, input t he fuel consumption comparison.
(  P. 106)
◆ECO Savings Record
If the fuel consumption comparison is input in “ECO Savings”, t he
savings history will be displayed . If the fuel consumption compari-
son is not input, fuel cost h istory will be displayed.
Fuel costs for the current month, the last 3 months and the sam e
month last year are displayed, enabling a comparison to be made .
If the dollar amount will be displayed on the graph.
1
2

1052. Instrument cluster
2
Instrument cluster
PRIUS c_U
◆Past Record
Displays average fuel consumption by the month.
The current month, the last 3 months and the same month last year are
displayed, enabling a comparison to be made.
Press and hold the enter switch to reset. ( P. 102)
◆Personal Best
Displays the best 3 fuel consumption records and the current fuel
consumption ranking.
Depending on whether the odometer or trip meter is displayed, t he
displayed contents differ.
● When the odometer is displayed: the record since the hybrid sys -
tem was started is displayed.
● When the trip meter is displayed: the record since the trip met er
was reset is displayed. The record for trip meter A and trip me ter
B is displayed separately.
The top 100 rankings are displayed. Records that are outside th e top
100 are not displayed as a ranking.
Fuel consumption data for trips of less than 0.1 miles are not recorded.
◆5 min./1 min. fuel consumption display
Select to display the fuel consumption history since the hybrid sys-
tem was started in intervals of 5 minutes or 1 minute. Current fuel
consumption will also be displaye d, enabling it to be compared to
the fuel consumption of up to t he last 30 minutes (in 5 min. in ter-
vals) or 6 minutes (in 1 min. intervals).
To change the interval, press and hold the enter switch. (P. 102)

591Alphabetical index
PRIUS c_U
MaintenanceDo-it-yourself
maintenance ....................... 414
Emission inspection and maintenance (I/M)
programs ............................ 413
General maintenance ........... 410
Maintenance data ................. 534
Maintenance requirements ... 407
Meter Instrument panel light
control................................... 99
Meters ..................................... 97
Microphone .............................. 331
Mirrors
Inside rear view mirror .......... 158
Outside rear view mirror defogger ............................. 376
Outside rear view mirrors...... 159
Vanity mirrors........................ 391
Moon roof ................................. 165
MP3 disc ................................... 298
Multi-information display ........ 101
Navigation system
*
Noise from under vehicle............ 8 Odometer ................................... 98
Oil
Engine oil .............................. 537
Opener Back door ............................. 134
Fuel filler door ....................... 219
Hood ..................................... 417
Outside rear view mirrors
Adjusting and folding ............ 159
Defogger ............................... 376
Outside temperature
display...................................... 99
Overheating, Hybrid system.................................... 526
Parking brake........................... 205
Parking lights Replacing light bulbs ............ 458
Switch ................................... 206
Wattage ................................ 542
PCS (Pre-Collision system) .... 229 PCS (Pre-Collision
system) switch...... .............. 232
Warning light......................... 479
Personal lights Switch ................................... 384
Wattage ................................ 542
Power outlet ............................. 392
Power switch ................... 186, 190
Power windows ....................... 161
Pre-Collision system (PCS) .... 229 PCS (Pre-Collision
system) switch...... .............. 232
Warning light......................... 479
M
N
O
P
