TOYOTA PRIUS C 2020 Owners Manual

5318-2. Steps to take in an emergency
8
When trouble arises
PRIUS c_U■
If the hybrid system overheat warning message is shown on
the multi-information display
Stop the vehicle in a safe place.
Stop the hybrid system and carefully lift the hood.
After the hybrid system has
cooled down, inspect the
hoses and radiator core
(radiator) for any leaks. Radiator
Cooling fan
If a large amount of coolant
leaks, immediately contact
your Toyota dealer.
The coolant level is satisfac-
tory if it is between the “F”
and “L” lines on the reservoir.
Reservoir
“F” line
“L” line
Add coolant if necessary.
Water can be used in an emer-
gency if coolant is unavailable.
Start the hybrid system and chec k for the multi-information dis-
play.
If the message d oes not disappear:
Stop the hybrid system and contact your Toyota dealer.
If the message is not displayed:
Have the vehicle inspected at the neare st Toyota dealer.
1
2
3
1
2
4
1
2
3
5
6

5328-2. Steps to take in an emergency
PRIUS c_U
WARNING
■To prevent an accident or injury when inspecting under the hood of
your vehicle
● If steam is seen coming from under the hood, do not open the ho od until
the steam has subsided. The engine compartment may be very hot, caus-
ing serious injuries such as burns.
● After the hybrid system has been turned off, check that on the multi-
information display and the “READY” indicator are off.
When the hybrid system is operating, the gasoline engine may au tomati-
cally start, or the cooling fan may suddenly operate even if th e gasoline
engine stops. Do not touch or approach rotating parts such as t he fan,
which may lead to fingers or clothing (especially a tie, a scarf or a muffler)
getting caught, resulting in serious injury.
● Do not loosen the radiator cap while the hybrid system and radi ator are
hot.
Serious injuries, such as burns, may result from hot coolant an d steam
released under pressure.
NOTICE
■ When adding engine/power control unit coolant
Wait until the hybrid system has cooled down before adding engine/power
control unit coolant.
When adding coolant, do so slowly. Adding cool coolant to a hot hybrid sys-
tem too quickly can cause damage to the hybrid system.
■ To prevent damage to the cooling system
Observe the following precautions:
● Avoid contaminating the coolant with foreign matter (such as sa nd or dust
etc.).
● Do not use any coolant additive.

5338-2. Steps to take in an emergency
8
When trouble arises
PRIUS c_U
Shift the shift lever to P and set the parking brake. Stop the hybrid
system.
Remove the mud, snow or sand from around the stuck tire.
Place wood, stones or some other material under the tires to help
provide traction.
Restart the hybrid system.
Shift the shift lever to the D or R position and carefully appl y the
accelerator to free the vehicle.
■ When it is difficult to free the vehicle
If the vehicle becomes stuck
Carry out the following procedures if the tires spin or the vehicle
becomes stuck in mud, dirt or snow:
Press to turn off TRAC.
WARNING
■When attempting to f ree a stuck vehicle
If you choose to push the vehicle back and forth to free it, ma ke sure the
surrounding area is clear to avoid striking other vehicles, obj ects or people.
The vehicle may also lunge forward or lunge back suddenly as it becomes
free. Use extreme caution.
■ When shifting the shift lever
Be careful not to shift the shift lever with the accelerator pedal depressed.
This may lead to unexpected rapid acceleration of the vehicle t hat may
cause an accident resulting in death or serious injury.
1
2
3
4
5

5348-2. Steps to take in an emergency
PRIUS c_U
NOTICE
■To avoid damage to the trans mission and other components
● Avoid spinning the wheels and depressing the accelerator pedal more
than necessary.
● If the vehicle remains stuck even after these procedures are pe rformed,
the vehicle may require towing to be freed.

535
9Vehicle specifications
PRIUS c_U9-1. Specifications
Maintenance data (fuel, oil level, etc.) .......... 536
Fuel information ................ 545
Tire information ................. 548
9-2. Customization Customizable features ...... 560
Items to initialize ............... 565

536
PRIUS c_U
9-1.Specifications
*1: Unladen vehicles
*2: Without roof molding
*3: With roof molding
*4: P175/65R15 tires
*5: P195/50R16 tires
Maintenance data (fuel, oil level, etc.)
Dimensions and weights
Overall length159.4 in. (4050 mm)*2
159.8 in. (4060 mm)*3
Overall width66.7 in. (1695 mm)*2
67.5 in. (1715 mm)*3
Overall height*157.3 in. (1455 mm)*2
58.7 in. (1490 mm)*3
Wheelbase
100.4 in. (2550 mm)
Tread
Front58.5 in. (1485 mm)*4
57.5 in. (1460 mm)*5
Rear58.1 in. (1475 mm)*4
57.1 in. (1450 mm)*5
Vehicle capacity weight
(Occupants + luggage) 845 lb. (380 kg)

5379-1. Specifications
9
Vehicle specifications
PRIUS c_U■
Vehicle identification number
The vehicle identification number (VIN) is the legal identifier
for
your vehicle. This is the primary identification number for you r
Toyota. It is used in registeri ng the ownership of your vehicle .
This number is stamped under
the front passenger’s seat.
This number is stamped on the
top left of the instrument panel.
This number is also on the Cer-
tification Label.
Vehicle identification

5389-1. Specifications
PRIUS c_U■
Engine number
The engine number is stamped
on the engine block as shown.
Engine
Model
1NZ-FXE
Type4-cylinder in line, 4-cycle, gasoline
Bore and stroke 2.95  3.33 in. (75.0  84.7 mm)
Displacement 91.3 cu. in. (1496 cm3)
Valve clearance
(engine cold)Intake: 0.006  0.010 in. (0.15  0.25 mm)
Exhaust: 0.010
 0.014 in. (0.25  0.35 mm)
Fuel
Fuel type Unleaded gasoline only
Octane rating 87 (Research octane number 91) or higher
Fuel tank capacity
(Reference)9.5 gal. (36 L, 7.9 Imp. gal.)
Electric motor (traction motor)
Type
Permanent magnet synchronous motor
Maximum output 45 kW
Maximum torque 125 ft•lbf (169 N•m, 17.2 kgf•m)

5399-1. Specifications
9
Vehicle specifications
PRIUS c_U
*: The engine oil capacity is a reference quantity to be used when changing
the engine oil. Warm up the engine and turn off the hybrid system, wait
more than 5 minutes, and check the oil level on the dipstick.
■
Engine oil selection
“Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat isfy
the following grade and viscosity.
Oil grade: ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice
for good fuel economy and
good starting in cold weather.
If SAE 0W-20 is not available,
SAE 5W-20 oil may be used.
However, it must be replaced
with SAE 0W-20 at the next oil
change.
Hybrid battery (traction battery)
Type Nickel-metal hydride battery
Voltage7.2 V/module
Capacity 6.5 Ah (3HR)
Quantity20 modules
Nominal voltage 144 V
Lubrication system
Oil capacity (Drain and
refill reference
*)
With filter
Without filter 3.9 qt. (3.7 L, 3.3 Imp. qt.)
3.6 qt. (3.4 L, 3.0 Imp. qt.)
Outside temperature

5409-1. Specifications
PRIUS c_U
Oil viscosity (0W-20 is explained here as an example):
• The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils wi th a lower value before the W allow
for easier starting of the engine in cold weather.
• The 20 in 0W-20 indicates the vi scosity characteristic of the oil
when the oil is at high temperature. An oil with a higher visco sity
(one with a higher value) may be better suited if the vehicle i s
operated at high speeds, or un der extreme load conditions.
How to read oil container label:
The International Lubricant
Specification Advisory Commit-
tee (ILSAC) Certification Mark
is added to some oil containers
to help you select the oil you
should use.
Cooling system
Capacity Gasoline engine
Power control unit 5.6 qt. (5.3 L, 4.7 Imp. qt.)
1.7 qt. (1.6 L, 1.4 Imp. qt.)
Coolant type Use either of the following:
• “Toyota Super Long Life Coolant”
• A similar high-quality ethylene glycol-
based non-silicate, non-amine, non-
nitrite, and non-borate coolant with long-
life hybrid organic acid technology
Do not use plain water alone.
