lock TOYOTA PRIUS C 2020 Owners Manual

TABLE OF CONTENTS2
PRIUS c_UFor your information....................... 8
Reading this manual .................... 14
How to search .............................. 15
Pictorial index .............................. 16
1-1. For safe use
Before driving ...................... 26
For safe driving ................... 28
Seat belts ............................ 30
SRS airbags ........................ 39
Front passenger occupant classification system ......... 52
Exhaust gas precautions ..... 57
1-2. Child safety Riding with children ............. 58
Child restraint systems ........ 59
1-3. Hybrid system Hybrid system features ....... 76
Hybrid system precautions ....................... 81
1-4. Theft deterrent system Immobilizer system ............. 88
Theft prevention labels ........ 91 2. Instrument cluster
Warning lights and indicators ........................... 94
Gauges and meters ............. 99
Multi-information display .... 103
Energy monitor/ consumption screen ........ 112
3-1. Key information Keys................................... 120
3-2. Opening, closing and locking the doors
Side doors ......................... 127
Back door .......................... 136
Smart key system .............. 141
3-3. Adjusting the seats Front seats......................... 150
Rear seats ......................... 151
Head restraints .................. 155
3-4. Adjusting the steering wheel and mirrors
Steering wheel ................... 158
Inside rear view mirror ....... 160
Outside rear view mirrors ............................. 161
3-5. Opening and closing the windows
Power windows.................. 163
Moon roof .......................... 167
1For safety and security
2Instrument cluster
3Operation of each
component

9
PRIUS c_UThe installation of a mobile two-way radio system in your vehic
le could affect
electronic systems such as:
● Multiport fuel injection system/sequential multiport fuel injection system
● Toyota Safety Sense C
● Cruise control system
● Anti-lock brake system
● SRS airbag system
● Seat belt pretensioner system
Be sure to check with your Toyota dealer for precautionary meas ures or spe-
cial instructions regarding instal lation of a mobile two-way radio system.
High voltage parts and cables on the hybrid vehicles emit appro ximately the
same amount of electromagnetic waves as the conventional gasoli ne pow-
ered vehicles or home electronic appliances despite of their el ectromagnetic
shielding.
Unwanted noise may occur in the reception of the mobile two-way radio.
Installation of a mobile two-way radio system

16
PRIUS c_U
Pictorial index
Pictorial index
■
Exterior
Doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 127
Locking/unlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 127
Opening/closing the door glasses . . . . . . . . . . . . . . . . . . . . . . P. 163
Locking/unlocking by using the mechanical key
* . . . . . . . . . . P. 520
Warning message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 491
Back door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 136
Locking/unlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 136
Warning message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 492
Outside rear view mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 161
Adjusting the mirror angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 161
Folding the mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 161
Defogging the mirrors
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 378
1
2
3

19Pictorial index
PRIUS c_UTurn signal lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 206
Headlight switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 208
Headlights/parking lights/tail lights/daytime running lights . .
. . P. 208
Front fog lights
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 212
Windshield wiper and washer switch . . . . . . . . . . . . . . . . . P. 214
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 214
Adding washer fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 430
Emergency flasher switch . . . . . . . . . . . . . . . . . . . . . . . . . . P. 468
Fuel filler door opener . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 221
Hood lock release lever. . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 419
Tilt and telescopic steering lock release lever . . . . . . . . . . P. 158
Air conditioning system . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 376
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 376
Rear window defogger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 378
Multimedia system
*1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 281
Navigation system
*1, 2
Power outlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 394
*1: If equipped
*2: Refer to “NAVIGATION SYSTEM OWNER’S MANUAL”.
4
5
6
7
8
9
10
11
12

20Pictorial index
PRIUS c_U
■Switches
Automatic High Beam switch . . . . . . . . . . . . . . . . . . . . . . . . P. 246
Outside rear view mirror switches . . . . . . . . . . . . . . . . . . . . P. 161
Instrument panel light control dial . . . . . . . . . . . . . . . . . . . . P. 101
PCS (Pre-Collision system) switch . . . . . . . . . . . . . . . . . . . P. 231
LDA (Lane Departure Alert) switch. . . . . . . . . . . . . . . . . . . . P. 241
Window lock switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 163
Door lock switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 130
Power window switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 163
USB port/AUX port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 284
Tire pressure warning reset switch . . . . . . . . . . . . . . . . . . . P. 4361
2
3
4
5
6
7
8
9
10

23Pictorial index
PRIUS c_U
■Interior
SRS airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 39
Floor mats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 26
Front seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 150
Head restraints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 155
Seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 30
Console box
*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 389
Inside lock buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 130
Cup holders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 391
Rear seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 151
Luggage cover
*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 397
Parking brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 207
Applying/releasing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 207
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . P. 275
Warning buzzer/message . . . . . . . . . . . . . . . . . . . . . . . . P. 481, 492
*: If equipped
1
2
3
4
5
6
7
8
9
10
11

281-1. For safe use
PRIUS c_U
Adjust the angle of the seat-
back so that you are sitting
straight up and so that you do
not have to lean forward to
steer. (P. 1 5 0 )
Adjust the seat so that you can
depress the pedals fully and so
that your arms bend slightly at
the elbow when gripping the
steering wheel. ( P. 150)
Vehicles with adjusta ble type head restraints: Lock the head
restraint in place with the center of the head restraint closes t to the
top of your ears. ( P. 155)
Wear the seat belt correctly. ( P. 3 0 )
Make sure that all occupants are wearing their seat belts before driv-
ing the vehicle. ( P. 3 0 )
Use a child restraint system appropriate for the child until th e child
becomes large enough to properly wear the vehicle’s seat belt.
(  P. 59)
For safe driving
For safe driving, adjust the seat and mirror to an appropriate
position before driving.
Correct driving posture
1
2
Correct use of the seat belts
3
4

291-1. For safe use
1
For safety and security
PRIUS c_U
Make sure that you can see backward clearly by adjusting the inside
and outside rear view mirrors properly. (P. 160, 161)
Adjusting the mirrors
WARNING
Observe the following precautions.
Failure to do so may result in death or serious injury.
●Do not adjust the position of the driver’s seat while driving.
Doing so could cause the driver to lose control of the vehicle.
● Do not place a cushion between the driver or passenger and the seatback.
A cushion may prevent correct posture from being achieved, and reduce
the effectiveness of the seat belt and head restraint.
● Do not place anything under the front seats.
Objects placed under the front seats may become jammed in the s eat
tracks and stop the seat from locking in place. This may lead t o an acci-
dent and the adjustment mechanism may also be damaged.
● Always observe the legal speed limit when driving on public roads.
● When driving over long distances, take regular breaks before yo u start to
feel tired.
Also, if you feel tired or sleepy while driving, do not force y ourself to con-
tinue driving and take a break immediately.

331-1. For safe use
1
For safety and security
PRIUS c_U
Holding tab “A” and “B”
together, insert both tabs all
the way into the cover on the
roof.
With tab “B” inserted all the
way into the cover, move tab
“A” slightly back toward the
cover’s inlet, so that it blocks
the inlet.
B
A
3
BA
Q

341-1. For safe use
PRIUS c_U
The pretensioners help the seat
belts to quickly restrain the occu-
pants by retracting the seat belts
when the vehicle is subjected to
certain types of severe frontal or
side collision or a vehicle rollover.
The pretensioners do not activate
in the event of a minor frontal
impact, a minor side impact or a
rear impact.
■Emergency locking retractor (ELR)
The retractor will lock the belt during a sudden stop or on imp act. It may also
lock if you lean forward too quickly. A slow, easy motion will allow the belt to
extend so that you can move around fully.
■ Automatic locking retractor (ALR)
When a passenger’s shoulder belt is completely extended and then retracted
even slightly, the belt is locked in that position and cannot be extended. This
feature is used to hold the child restraint system (CRS) firmly . To free the belt
again, fully retract the belt and then pull the belt out once m ore. (P. 61)
■ Child seat belt usage
The seat belts of your vehicle were principally designed for persons of adult
size.
●Use a child restraint system appropriate for the child, until the child
becomes large enough to properly wear the vehicle’s seat belt. ( P. 59)
● When the child becomes large enough to properly wear the vehicle’s seat
belt, follow the instructions on P. 30 regarding seat belt usag e.
Seat belt pretensioners (front seats)
