key TOYOTA PRIUS PLUG-IN 2012 Workshop Manual

590
5-2. Steps to take in an emergency
PRIUS PHV_OM_OM47818U_(U)
If you lose your keys
New genuine keys can be made by your Toyota dealer using the
other key and the key number stamped on your key number plate.

5
When trouble arises
591
5-2. Steps to take in an emergency
PRIUS PHV_OM_OM47818U_(U)
If the electronic key does not operate properly
Locking and unlocking the doors
Use the mechanical key (→P. 1 0 5 )
in order to perform the following
operations:
Locks all the doors
Unlocks the door
Turning the key rearward unlocks
the driver’s door. Turning the key
once again within 3 seconds
unlocks the other doors.
If communication between the electronic key and vehicle is inter-
rupted (→P. 1 1 9 ) o r t h e e l e c t r o n i c k e y c a n n o t b e u s e d b e c a u s e t h e
battery is depleted, the smart key system and wireless remote con-
trol cannot be used. In such cases, the doors can be opened and the
hybrid system can be started by following the procedure below.
ITO52P121

592
5-2. Steps to take in an emergency
PRIUS PHV_OM_OM47818U_(U)
Starting the hybrid system
Depress the brake pedal.
To u c h t h e To y o t a e m b l e m s i d e o f
the electronic key to the
“POWER” switch.
If any of the doors is opened or
closed while the key is being
touched to the switch, an alarm
will sound to indicate that the start
function cannot detect the elec-
tronic key.
Press the “POWER” switch within 10 seconds of the buzzer
sounding, keeping the brake pedal depressed.
In the event that the hybrid system still cannot be operated, contact
your Toyota dealer.
STEP 1
STEP 2
STEP 3

5
When trouble arises
593
5-2. Steps to take in an emergency
PRIUS PHV_OM_OM47818U_(U)
■Stopping the hybrid system
Set the parking brake, shift the shift position to P and press the “POWER”
switch as you normally do when stopping the hybrid system.
■Replacing the key battery
As the above procedure is a temporary measure, it is recommended that the
electronic key battery be replaced immediately when the battery is depleted.
(→P. 4 9 3 )
■Changing “POWER” switch modes
Within 10 seconds of the buzzer sounding, release the brake pedal and
press the “POWER” switch.
The hybrid system does not start and modes will be changed each time the
switch is pressed. (→P. 2 4 0 )

640
6-2. Customization
PRIUS PHV_OM_OM47818U_(U)
ItemFunctionDefault
setting
Custom-
ized
setting
Smart key
system
(→P. 1 0 8 )
Smart key
systemON OFF O O O
Select doors to
unlock
Driver’s
doorAll doors O O O
Wireless
remote
control
(→P. 1 3 2 )
Wireless remote
control ON OFF – – O
Unlocking
operation
Driver’s
door
unlocked in
1-step, all
doors
unlocked
in 2-step
All doors
unlocked
in 1-step
OOO
Panic function ON OFF – – O
Buzzer sounds
when pushing
with any
door not closed
ON OFF – – O

641
6-2. Customization
6
Vehicle specifications
PRIUS PHV_OM_OM47818U_(U)
ItemFunctionDefault
setting
Custom-
ized
setting
Smart key
system
(→P. 1 0 8 )
and wire-
less remote
control
(→P. 1 3 2 )
Operation
signals
(Emergency
flashers)
ON OFF – O O
Operation
signals
(Buzzers)
Level 7
Level 1 to 6
OOO
OFF
Time elapsed
before
automatic door
lock function is
activated if door
is not opened
after being
unlocked
60 seconds
OFF
–OO30
seconds
120
seconds

642
6-2. Customization
PRIUS PHV_OM_OM47818U_(U)
*:This function cannot be customized for vehicles sold in Canada.
ItemFunctionDefault set-
ting
Custom-
ized
setting
Door lock
(→P. 1 3 4 ,
591)
Unlocking using
a key
Driver’s
door
unlocked in
1-step, all
doors
unlocked in
2-step
All doors
unlocked in
1-step
–OO
Speed-detecting
automatic door
lock function
OFF ON O O O
Shifting the shift
position to any
position other
than P locks all
doors
ON OFF O O O
Shifting the shift
position to P
unlocks all doors
ON OFF O O O
Opening driver’s
door unlocks all
doors
OFF ON – O O
Automatic
light control
system
(→P. 2 9 2 )
Light sensor
sensitivityLevel 3Levels 1 to
5OOO
Time elapsed
before head-
lights automati-
cally turn off after
doors are closed
30 seconds
0 seconds
OOO60 seconds
90 seconds
Daytime running
lights*ON OFF O O O

643
6-2. Customization
6
Vehicle specifications
PRIUS PHV_OM_OM47818U_(U)
ItemFunctionDefault set-
ting
Custom-
ized
setting
Power
windows
(→P. 1 7 1 )
The one-touch
closing operation
except for
driver’s seat
ON OFF – – O
Illumination
(→P. 3 8 2 )
Time elapsed
before lights turn
off
15 seconds
OFF
–OO7.5
seconds
30 seconds
Operation when
the doors are
unlocked
ON OFF – – O
Operation after
the “POWER”
switch turned
OFF
ON OFF – – O
Operation when
you approach
the vehicle with
the electric key
on your person
(When the per-
sonal/interior
light main switch
is door position)
ON OFF – – O
Foot lights ON OFF – – O
Foot lights oper-
ation when the
vehicle is run-
ning
ON OFF – – O

669
Alphabetical index
PRIUS PHV_OM_OM47818U_(U)
Back door
Back door ............................. 140
Smart key system ................. 108
Wireless remote control........ 132
Back-up lights
Replacing light bulbs ............ 507
Wattage ................................ 620
Battery
Checking .............................. 471
If the 12-volt battery is
discharged ......................... 594
Preparing and checking
before winter ...................... 349
Bluetooth®*
Bottle holders .......................... 390
Brake
Fluid...................................... 619
Parking brake ....................... 255
Brake assist ............................. 328
Break-in tips ............................ 226
Brightness control
Instrument panel light
control ................................ 260
Camera*
Care
Exterior ..................................424
Interior ...................................428
Seat belts ..............................429
Cargo capacity .........................348
Cargo hooks .............................403
CD player*
Chains .......................................351
Charging
Charging cable ........................74
Charging equipment ................73
Charging messages ..............562
Charging precautions ..............94
Charging procedure ................80
Charging timer function ...........86
Charging time will
increase when.......................93
High voltage components........44
Information related to
charging display ....................89
Maintenance..........................103
Power sources precautions .....79
Power sources that can be
used ......................................77
Safety functions.................75, 91
When charging cannot be
carried out .............................98
BC
*: Refer to “Display Audio System Owner’s Manual”
or “Navigation System Owner’s Manual”.

670
Alphabetical index
PRIUS PHV_OM_OM47818U_(U)
Child restraint system
Booster seats, definition ........204
Booster seats, installation .....212
Convertible seats,
definition ............................. 204
Convertible seats,
installation ...........................212
Front passenger occupant
classification system ...........198
Infant seats, definition ...........204
Infant seats, installation.........212
Installing child restraint system
with LATCH anchors ...........210
Installing child restraint system
with seat belts ..................... 212
Installing child restraint system
with top tether strap ............216
Child safety
Airbag precautions ................192
Back door precautions .......... 142
Child restraint system............204
Child-protectors ..................... 135
How to charge ......................... 80
How your child should wear
the seat belt ........................159
Installing child restraints ........209
Power window lock switch..... 171
Power window precautions ...173
Remote Air Conditioning
System precautions ............374
Removed electronic key
battery precautions ............. 494
Seat belt extender
precautions .........................164
Seat belt precautions ............160
Seat heater precautions ........ 398
12-volt battery precautions ....474
Child-protectors ....................... 135
Cleaning
Exterior.................................. 424
Interior ................................... 428
Seat belts .............................. 429
Clock ......................................... 275
Condenser ................................ 466
Console box ............................. 387
Cooling system
Engine overheating ............... 600
Hybrid system overheating ... 600
Cruise control
Cruise control ........................ 308
Dynamic radar cruise
control ................................. 312
Cup holders .............................. 388
Curtain shield airbags ............. 184
Customizable features ............ 639
