SAFETY AND EMERGENCY FEATURES
If belt is fully extended, then retracted even slightly, it cannot be re-extended
beyond that point, unless fully retracted again. This feature is used to help hold
child restraint systems securely.
To find more information about seat belts, and how to install a child restraint
system, refer to the Owner’s Manual.
Keep as low on
hips as possible
Take up slack
Too high
Seat belts
Push up, or squeeze
lock release to lower
Seat belts-Shoulder belt anchor
Door locks
If the Tire Pressure Warning indicator “” illuminates without blinking, adjust
tire pressures to factory-specified levels.* The light will turn off after a few
minutes. The warning light is designed to turn on when tire pressure is critically
low, but it may also come on due to temperature changes or changes in tire
pressure from natural air leakage.
If the tire pressure indicator flashes for more than 60 seconds and then remains
on, take the vehicle to your local Toyota dealer.
Refer to the Owner’s Manual for more details.
* Refer to load label on door jamb or the Owner’s Manual for tire inflation specifications.
Tire Pressure Monitoring (warning)
System
Tire Repair System
Tool location
NOTE: Please call your roadside assistance provider as your first course of
action for tire concerns. Use of the Tire Repair System may lead to additional
maintenance requirements at your expense, including but not limited to
replacement of a Tire Pressure Monitoring System (TPMS) sensor. Your Prius Plug-
in comes with complimentary Roadside Assistance for 3 years from the date of
original purchase. Toyota Roadside Assistance can be reached at 1-800-444-4195.

Refer to the Owner’s Manual for more details.
Tire Repair System
Moving the lever to lock position will allow the door to be opened only from the
outside.
Rear door
Doors-Child safety locks
Unlock
Side deck board Lock
Lock
