check engine TOYOTA PRIUS PRIME 2017 2.G Quick Reference Guide

PRIUS PRIME_QG_OM47B04U_(U)
273. Basic operation
3
Basic operation
■Starting the hybrid systemCheck that the charging cable is disconnected.
Check that the parking brake is set.
Firmly depress the brake
pedal.
and a message will be
displayed on the multi-informa-
tion display.
When the shift position is N, the
hybrid system cannot start. Shift
the shift position to P when start-
ing the hybrid system.
Press the power switch
shortly and firmly.
When operating the power
switch, one short, firm press is
enough. It is not necessary to
press and hold the switch.
If the “READY” indicator turns
on, the hybrid system will oper-
ate normally.
Continue depressing the brake pedal until the “READY” indicator is illu-
minated.
The hybrid system can be started from any power switch mode.
Check that the “READY” indicator is illuminated.
If the “READY” indicator changes from a flashing light to a solid light and
the buzzer sounds, the hybrid system is starting normally.
The vehicle will not move when the “READY” indicator is off.
The vehicle can move when the “READY” indicator is on even if the
engine is stopped. (The gasoline engine starts or stops automatically in
accordance with the state of the vehicle.)
How to operate the power (ignition) switch
1
2
3
4
5

30
PRIUS PRIME_QG_OM47B04U_(U)
3. Basic operation
Shift the shift position to P.
Check that the P position is
highlighted on the shift posi-
tion indicator, and release the
brake pedal gently after
applying the parking brake.
■About engine braking
When shift position B is selected, releasing the accelerator pedal will apply
engine braking.
●When the vehicle is driven at high speeds, compared to ordinary gasoline-
fueled vehicles, the engine braking deceleration is felt less than that of other
vehicles.
● The vehicle can be accelerated even when shift position B is selected.
If the vehicle is driven continuously in the B position, fuel efficiency will
become low. Usually, select the D position.
2
NOTICE
■ Hybrid battery (tract ion battery) charge
If the shift position is in N, the hybrid battery (traction battery) will not be
charged. To help prevent the battery from discharging, avoid leaving the N
position selected for an extended period of time.
