TOYOTA PRIUS PRIME 2020 Accessories, Audio & Navigation (in English)

51
3
3
Audio/visual system
Audio/visual system
3-1. Basic operationQuick reference.............. 52
Some basics .................. 53
3-2. Radio operation AM/FM/SiriusXM (SXM) radio ............................. 58
Internet radio .................. 66
3-3. Media operation CD .................................. 67
USB memory.................. 69
iPod/iPhone.................... 71
Bluetooth
® audio ............ 74
AUX................................ 77
3-4. Audio/visual remote con- trols
Steering switches ........... 79
3-5. Setup Audio settings ................ 81
3-6. Tips for operating the audio/visual system
Operating information .... 83

523-1. Basic operation
3-1.Basic operation
The audio control screen can be reached by the following methods:
From the “AUDIO” button
1 Press the “AUDIO” button.
From the “MENU” button
1 Press the “MENU” button, then select “Audio”.
 Using the radio ( P. 5 8 )
 Playing an audio CD or MP3/WMA/AAC disc ( P.67)
 Playing a USB memory ( P.69)
 Playing an iPod/iPhone ( P. 7 1 )
 Playing a Bluetooth
® device ( P.74)
 Using the AUX port ( P. 7 7 )
 Using the steering wheel audio switches ( P.79)
 Audio system settings ( P.81)
Quick reference
Functional overview

533-1. Basic operation
3
Audio/visual system
“POWER VOLUME” knob:
Press to turn the audio/visual
system on and off. The system
turns on in the last mode used.
Turn this knob to adjust the vol-
ume.1
Press the “AUDIO” button.
2 Select “Source” or press
“AUDIO” button again.
3 Select the desired source.
●Dimmed screen buttons cannot be
operated.
●When there are tw o pages, select
or to change the page.
●When an Apple Carplay connec-
tion is established, some system
functions, such as the following,
will be replaced by similar Apple
CarPlay function or will become
unavailable
*:
• iPod (Audio Playback)
• USB audio/USB video
• Bluetooth
® audio
• Toyota Entune App Suite Connect
*: This function is not made avail-
able in some countries or areas.
1 Display the audio source
selection screen. ( P.53)
2 Select “Reorder”.
Some basics
This section describes
some of the basic features
of the audio/visual system.
Some information may not
pertain to your system.
Your audio/visual system
works when the power
switch is in ACCESSORY or
ON mode.
NOTICE
●To prevent the 12-volt battery
from being discharged, do not
leave the audio/visual system
on longer than necessary when
the hybrid system is not operat-
ing.
Turning the system on
and off
Selecting an audio source
Reordering the audio
source

543-1. Basic operation
3Select the desired audio
source then or to reor-
de r.
4 Select “OK”.
■Inserting a disc
1 Insert a disc into the disc slot.
 After insertion, the disc is
automatically loaded.
■Ejecting the disc
1 Press the button and
remove the disc.
●The player is intended for use with
12 cm discs only.
●When inserting a disc, gently
insert the disc with the label facing
up.
1Open the lid and connect a
device.
 Turn on the power of the
device if it is not turned on.
●The AUX port only supports audio
input.
●If a USB hub is plugged-in, two
devices can be connected at a
time.
●Even if a USB hub is used to con-
nect more than two USB devices,
only the first two connected
devices will be recognized.
●If a USB hub that has more than
two ports is connected to the USB
port, devices connected to the
USB hub may not charge or be
inoperable, as the supply of cur-
rent may be insufficient.
1 Display the audio control
screen. ( P.53)
2 Select “Sound”.
Disc slot
NOTICE
●Never try to disassemble or oil
any part of the CD player. Do
not insert anything other than a
disc into the slot.
USB/AUX port
Sound settings

553-1. Basic operation
3
Audio/visual system
3Select the desired item to be
set.
Select to set the tre-
ble/mid/bass. ( P.55)
Select to set the fader/bal-
ance. ( P. 5 5 )
Select to set the automatic
sound leveliser. ( P. 5 5 )
■Treble/Mid/Bass
How good an audio program
sounds is largely determined by
the mix of the treble, mid and
bass levels. In fact, different
kinds of music and vocal pro-
grams usually sound better with
different mixes of treble, mid
and bass.
1 Select “Treble/Mid/Bass”.
2 Select the desired screen
button.
Select “+” or “-” to adjust
high-pitched tones. Select “+” or “-” to adjust mid-
pitched tones.
Select “+” or “-” to adjust low-
pitched tones.
■Fader/Balance
A good balance of the left and
right stereo channels and of the
front and rear sound levels is
also important.
Keep in mind that when listening
to a stereo recording or broad-
cast, changing the right/left bal-
ance will increase the volume of
1 group of sounds while
decreasing the volume of
another.
1 Select “Fader/Balance”.
2 Select the desired screen
button.
Select to adjust the sound
balance between the front
and rear speakers.
Select to adjust the sound
balance between the left and
right speakers.
■Automatic sound levelizer
(ASL)
The system adjusts to the opti-
mum volume and tone quality
A
B
C
A
B
C
A
B

563-1. Basic operation
according to vehicle speed to
compensate for increased road
noise, wind noise, or other
noises while driving.
1Select “Automatic Sound
Levelizer”.
2 Select “High”, “Mid”, “Low” or
“Off”.
■Screen format settings
The screen format can be
selected for USB video.
1 Press the “MENU” button.
2 Select “Setup”.
3 Select “Audio”.
4 Select “Common”.
5 Select “Screen Format”.
6 Select the desired item to be
adjusted.
Select to display a 4:3
screen, with either side in
black.
Select to enlarge the image
horizontally and vertically to
full screen.
Select to enlarge the image
by the same ratio horizontally and vertically.
■Contrast and brightness
adjustment
The contrast and brightness of
the screen can be adjusted.
1 Press the “MENU” button.
2 Select “Setup”.
3 Select “Audio”.
4 Select “Common”.
5 Select “Display”.
6 Select the desired item to be
adjusted.
 “Contrast”
“+”: Select to strengthen the con-
trast of the screen.
“-”: Select to weaken the contrast of
the screen.
“Brightness”
“+”: Select to brighten the screen.
“-”: Select to darken the screen.
●Depending on the audio source,
some functions m ay not be avail-
able.
1 Press this switch to operate
the voice command system.
Audio screen adjustment
A
B
C
9RLFHFRPPDQG\
V\VWHP

573-1. Basic operation
3
Audio/visual system
The voice command system
and its list of commands can
be operated. ( P. 9 6 )

583-2. Radio operation
3-2.Radio operation
*: If equipped
The radio operation screen can
be reached by the following
methods:
P. 5 3
Select to display the audio
source selection screen.
Select to display the preset
stations screen. ( P.59)
Select to display the cache
radio operation screen.
( P. 5 9 )
Select to display a list of
receivable stations. ( P.60)
Select to display the radio
options screen. ( P.60)
Select to display the sound
setting screen. ( P. 5 4 )
Select to tune to preset sta-
tions/channels. ( P.59) Displays items on the chan-
nels registered to smart
favorites (
P.64, P.82)
Displays the artist info and
song title or album
Select to change the dis-
played information.
Displays messages when
available
Displays cover art, station
logo, etc.
Displays information about
the song/track currently
being played
Select to display HD) multi-
cast channels available.
( P.62)
Press to seek for stations in
the relevant program
type/channel category.
Press and hold for continu-
ous seek.
Turn to step up/down fre-
quencies/channels.
Turn to move up/down the
station list. Also, the knob
AM/FM/SiriusXM
(SXM)* radio
Overview
Control screen
A
B
C
D
E
F
G
&RQWUROSDQHO
H
I
J
K
L
A
B

593-2. Radio operation
3
Audio/visual system
can be used to enter selec-
tions on the list screens by
pressing it.
●The radio automatically changes
to stereo reception when a stereo
broadcast is received.
●The radio automatically blends to
an HD Radio signal in AM or FM
where available.
Radio mode has a mix preset
function, which can store up to
36 stations (6 stations per page
x 6 pages) from any of the AM,
FM or SXM bands.
1Tune in the desired station.
2 Select and hold preset num-
ber.
 When “(Add New)” is
selected, a confirmation mes-
sage appears. Select “Yes”
and select “OK”.
 To change a previously regis-
tered preset station to a differ-
ent one, select and hold the
preset station.
●The number of preset radio sta-
tions displayed on the screen can
be changed. ( P. 8 1 )
SXM radio program can be
cached and played back in a
time-shifted manner.
■Automatic playback of the
cache
If the radio broadcast is inter-
rupted by another audio output,
such as an incoming phone call,
the system will automatically
cache the interrupted portion
and perform time-shift playback
when the interruption ends. This
function is available when “Auto
Pause” is set to on. ( P. 6 0 )
■Playing back the cache
manually
The broadcast cached in the
program cache can be played
back manually.
1 Select “SXM Replay”.
2 Select the desired cache
radio operation button.
Returns to the live radio
broadcast
Displays the replay offset
from the current time
Select to change current/pre-
Presetting a station
Caching a radio program
A
B
C

603-2. Radio operation
vious track
Fast rewinds continuously
Pauses the playback (To
restart, select )
Fast forwards continuously
Select to change the next
track
●The system can store less than 60
minutes of SXM. Cached data will
be erased when the radio mode or
station is changed or when the
audio system is turned off.
1 Select “Station List”.
2 Select “AM”, “FM” or “SXM”.
 Select the desired program
genre when the genre selec-
tion screen is displayed.
3 Select the desired station.
■Refreshing the station list
(AM/FM)
1 Select “Station List”.
“Cancel Refresh”: Select to can-
cel the refresh.
“Source”: Select to change to
another audio source while
refreshing.
●The audio/visual system sound is
muted during refresh operation.
●In some situations, it may take
some time to update the station
list.
1 Select “Options”.
2 Select the desired item to be
set.
Select to turn automatic play-
back of the cache on/off.
When “SXM Tune Start” is
turned on, the current song is
played from the beginning
when you select the channel.
Select to turn digital AM
Radio mode on/off.
Select to turn digital FM
Radio mode on/off.
Analog FM only: Select to
display RBDS text mes-
sages.
Select to scan for receivable
stations. (Type scan in case
SXM is current program
type/channel category.)
This audio/visual system is
equipped with Radio Broadcast
Data Systems (RBDS). RBDS
mode allows text messages to
Selecting a station from
the list
D
E
F
G
5DGLRRSWLRQV
5DGLREURDGFD\
VWGDWDV\V
WHP
A
B
C
D
E
F
