6-3. Using the storage features
6
Interior features
List of storage features
Auxiliary boxes ( P. 535)
Glove box ( P. 532)
Bottle holders/door pockets
(  P. 534) Cup holders (
P. 533)
Seat back pockets (P. 535)
Console box ( P. 532)
WARNING
●Do not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into c ontact
with other stored items.
• Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may r elease
gas, causing a fire hazard.
● When driving or when the storage compartments are not in use, k eep the
lids closed.
In the event of sudden braking or sudden swerving, an accident may occur
due to an occupant being struck by an open lid or the items stored inside.
1
2
3
4
5
6

532
PRIUS PRIME_OM_OM47C77U_(U)
6-3. Using the storage features
Pull up the lever.
The glove box light turns on when the tail lights are on.
Press the knob and open the lid.
Glove box
Console box
The tray slides forward/backward and can
be removed.

PRIUS PRIME_OM_OM47C77U_(U)
5336-3. Using the storage features
6
Interior features
Cup holders
FrontRear
Pull down the armrest.
WARNING
Do not place anything other than cups or beverage cans in the c up holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, causing injury. If possible, cover hot drinks t o prevent
burns.

534
PRIUS PRIME_OM_OM47C77U_(U)
6-3. Using the storage features
●When storing a bottle, close the cap.
● The bottle may not be stored depending on its size or shape.
Bottle holders/door pockets
Front doorsRear doors
NOTICE
Put the cap on before stowing a bottle. Do not place open bottles or glass
and paper cups containing liquid in the bottle holders.
The contents may spill and glasses may break.

PRIUS PRIME_OM_OM47C77U_(U)
5356-3. Using the storage features
6
Interior featuresOwner’s manual etc. can be
stored in the left-side seatback
pocket with the slide fastener.
Auxiliary boxes
Ty p e AType B (if equipped)
Press in the lid.
The overhead console is useful for
temporarily storing small items.
Vehicles with the wireless char-
ger: P. 5 4 4
WARNING
Type A:
Do not store items heavier than 0.44 lb. (200 g).
Doing so may cause the auxiliary box to open and the items inside may fall
out, resulting in an accident.
Seat back pockets

536
PRIUS PRIME_OM_OM47C77U_(U)
6-3. Using the storage features
Luggage compartment features
■When installing the deck board
Auxiliary boxes
CenterRight side
Pull the strap upwards to lift up
the deck board.
The luggage cover, charging cable,
tool bag, etc. can be stowed.
Pull the strap upwards to lift up
the deck board.
Insert the claw in to the hole, and return
the deck board.
WARNING
If the deck board is removed, return it to its original positio ns before driving.
In the event of sudden braking, an accident may occur due to an occupant
being struck by the deck board or the items stored in the auxil iary box.

PRIUS PRIME_OM_OM47C77U_(U)
5376-3. Using the storage features
6
Interior features
When using the hooks, press the
bottom side to lift it up.
There also is a hook on the other
side.
The warning reflector can be
stowed.
(The warning reflector itself is not
included as an original equipment)
Depending on the size and shape of the warning reflector case, etc., you may
not be able to store it.
NOTICE
To prevent damage to the deck board, do not apply too much load on the
deck board.
Grocery bag hooks
NOTICE
In order to prevent damage to the grocery bag hooks, do not place large
objects or objects that weight more than 8.8 lb. (4 kg) onto th e hooks.
Warning reflector storage space
WARNING
When storing the warning reflector, etc., make sure that it is properly stored.
If the warning reflector is not properly stored, it may fly out during emer-
gency braking and lead to an accident.

538
PRIUS PRIME_OM_OM47C77U_(U)
6-3. Using the storage features
■Installing the luggage cover
Install one side of the luggage
cover to the holder. While push-
ing that side in, install the other
side to the opposite holder.
■Using the luggage cover
Pull out the luggage cover and
secure it to the hook brackets.
■Removing the luggage cover
Push one end of the luggage
cover inward and remove it
from the holder.
Luggage cover

PRIUS PRIME_OM_OM47C77U_(U)
5396-3. Using the storage features
6
Interior features
■Stowing the luggage cover
Remove the deck boards.
Store cover in the center aux-
iliary box.
Return the deck boards to its original position and close it.
1
2
WARNING
●Do not place anything on the luggage cover. In the event of sud den brak-
ing or turning, the item may go flying and strike an occupant. This could
lead to an unexpected accident, resulting in death or serious i njury.
● Do not allow children to climb on the luggage cover. Climbing on the lug-
gage cover could result in damage to the luggage cover, possibl y causing
death or serious injury to the child.
● Make sure that the rear edge of the cover is laying flat. If th e cover is
installed with the rear edge raised, the view from the rear win dow may be
obstructed, which could cause an accident.
● Make sure that seat belts are not caught up in the luggage cover. If a seat
belt is caught up in the cover, it may not be able to restrain passengers
properly.
3

540
PRIUS PRIME_OM_OM47C77U_(U)
6-4. Using the other interior features
Other interior features
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
To use the side extender, place
the visor in the side position,
then slide it backward.
Slide the cover to open.
The light turns on when the cover
is opened.
If the vanity light remain on when the power switch is turned o ff, the light will
go off automatically after 20 minutes.
Sun visors
1
2
3
Vanity mirrors
NOTICE
To prevent 12-volt battery discharge, do not leave the vanity l ights on for
extended periods while the hybrid system is off.
