TOYOTA PRIUS V 2016 ZVW40 / 1.G Owners Manual

PRIUS v_OM_OM47B12U_(U)
2715-1. Basic Operations
5
Audio system
■When using the touch screen
●If the screen is cold, the display may be dark, or the system may seem to be
operating slightly slower than normal.
●The screen may seem dark and hard to see when viewed through sun-
glasses. Change your angle of viewing, adjust the display on the “Display
Settings” screen (P. 281) or remove your sunglasses.
●Flick operations may not be performed smoothly in high altitudes.
NOTICE
■To avoid damaging the touch screen
●To prevent damaging the screen, lightly touch the screen buttons with your
finger.
●Do not use objects other than your finger to touch the screen.
●Wipe off fingerprints using a glass cleaning cloth. Do not use chemical
cleaners to clean the screen, as they may damage the touch screen.

272
PRIUS v_OM_OM47B12U_(U)
5-1. Basic Operations
Using the steering wheel audio switches
Vo l u m e s w i t c h
• Press: Increases/decreases
volume
• Press and hold: Continuously
increases/decreases volume
Cursor switch (Radio mode)
• Press: Selects a radio station
• Press and hold: Seeks up/
down
Cursor switch (CD, MP3/WMA disc, Bluetooth
®, iPod or USB
mode)
• Press: Selects a track/file/song
• Press and hold: Fast up/down
“MODE” switch
• Press: Turns the power on, selects an audio source
• Press and hold: Turns the power off
■Canceling automatic selection of a radio station
Press the “” or “” button again.
Some audio features can be controlled using the switches on
the steering wheel.
Operation may differ depending on the type of audio system or
navigation system. For details, refer to the manual provided with
the audio system or navigation system.
1
2
WARNING
Exercise care when operating the audio switches on the steering wheel.
3

273
PRIUS v_OM_OM47B12U_(U)
5-1. Basic Operations
5
Audio system
AUX Por t/USB Por t
■iPod
Open the cover and connect an
iPod using an iPod cable.
Turn on the power of the iPod if
it is not turned on.
■
USB memory
Open the cover and connect the USB memory device.
Turn on the power of the USB memory device if it is not turned on.
■
Portable audio player
Open the cover and connect the portable audio player.
Turn on the power of the portable audio player if it is not turned on.
Connect an iPod, USB memory device or portable audio player
to the AUX port/USB port as indicated below. Select “iPod”,
“USB”, “AUX” or “A/V” on the audio source selection screen
and the device can be operated via audio system.
Connecting the AUX port/USB port
WARNING
■While driving
Do not connect a device or operate the device controls.

274
PRIUS v_OM_OM47B12U_(U)
5-1. Basic Operations
Basic audio operations
Press this knob to turn the audio system on and off, and turn it to
adjust the volume.
Insert a disc into the disc slot.
Turn this knob to select radio station bands, tracks and files. Also
the knob can be used to select items in the list display.
Press to pause or resume playing music.
Press the “” or “” button to seek up or down for a radio station, or
to access a desired track or file.
: Select to pause music.
: Select to resume playing music.
Press this button to eject a disc.
Basic audio operations and functions common to each mode are
explained in this section.
Operating the audio system
1
2
3
4
5
6
7

PRIUS v_OM_OM47B12U_(U)
2755-1. Basic Operations
5
Audio system
Select to change on/off.
Select to change on/off.
■Certification
CAUTION:
THIS PRODUCT IS A CLASS  LASER PRODUCT. USE OF CONTROLS
OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIA-
TION EXPOSURE. DO NOT OPEN COVERS AND DO NOT REPAIR BY
YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL.
Random playback
Repeat play

276
PRIUS v_OM_OM47B12U_(U)
5-2. Setup
Setup menu
Press the “SETUP” button to display the “Setup” screen.
Select to adjust the settings for
operation sounds, screen ani-
mation, etc. (P. 277)
Select to set the voice settings.
(P. 284)
Select to adjust the settings for
contrast and brightness of the
screen. (P. 281)
Select to adjust the settings for registering, removing, connecting
and disconnecting Bluetooth
® devices. (P. 312)
Select to adjust the settings for contact, message, etc. (P. 338)
Select to set audio settings. (P. 279)
Select to turn the screen off.
Select to set the vehicle customization. (P. 575)
You can adjust the audio system to your desired settings.
Display “Setup” screen
1
2
3
4
5
6
7
8

277
PRIUS v_OM_OM47B12U_(U)
5-2. Setup
5
Audio system
General settings
Press the “SETUP” button.
Select “General” on the “Setup”
screen.
“English”, “Français” or
“Español” can be selected.
Select to change the unit of
measure for distance. (If
equipped)
On/off can be selected to
sound beeps.
Select to change the screen
color.
Select to change the key-
board layout.
Select to change the capacitive touch button sensor sensitivity.
The animation effect for the screen can be set to on/off.
Select to delete personal data. (P. 278)
Select to update program versions. For details, contact your
Toyota dealer.
Select to display the software information. Notices related to third
party software used in this product are enlisted. (This includes
instructions for obtaining such software, where applicable.)
■To return to the default volume settings
Select “Default”, and then “Yes”.
Settings are available for adjusting the operation sounds,
screen animation, etc.
Screen for general settings
1
2
1
2
3
4
5
6
7
8
9
10

2785-2. Setup
PRIUS v_OM_OM47B12U_(U)
Select “Delete Personal Data” on the “General Settings” screen.
Select “Delete”.
Check carefully beforehand, as data cannot be retrieved once deleted.
A confirmation screen will be displayed. Select “Yes”.
The following personal data will be deleted or changed to its default
settings.
• General settings
• Audio settings
• Phone settings
Delete personal data
1
2
3

279
PRIUS v_OM_OM47B12U_(U)
5-2. Setup
5
Audio system
Audio settings
Press the “SETUP” button.
Select “Audio” on the “Setup” screen.
Number of Radio Presets
Select the number of radio
preset stations.
Select input video sound.
Select video signal.
Display Cover Art on/off.
Automatic Sound Levelizer.
(P. 280)
Select “iPod Video Sound Input” on the “Audio Settings” screen.
Select a screen button for the
desired setting.
Settings are available for adjusting the radio operation, cover
art, etc.
Screen for audio settings
1
2
1
2
3
4
5
iPod Video Sound Input
1
2

2805-2. Setup
PRIUS v_OM_OM47B12U_(U)
Select “Video Input Mode” on the “Audio Settings” screen.
(P. 279)
Select a screen button for the
desired setting.
Select “Automatic Sound Levelizer” on the “Audio Settings” screen.
Select a screen button for the
desired setting.
■About Automatic Sound Leveliser (ASL)
ASL automatically adjusts the volume and tone quality according to the vehi-
cle speed.
Video Input Mode
1
2
Automatic Sound Leveliser (ASL)
1
2
