TOYOTA PRIUS V 2016 ZVW40 / 1.G Owners Manual
Manufacturer: TOYOTA, Model Year: 2016, Model line: PRIUS V, Model: TOYOTA PRIUS V 2016 ZVW40 / 1.GPages: 620, PDF Size: 29.83 MB
Page 1 of 620
PRIUS v_OM_OM47B12U_(U)
Pictorial indexSearch by illustration
1For safety
and securityMake sure to read through them
2Instrument
clusterHow to read the gauges and meters, the variety of
warning lights and indicators, etc.
3Operation of
each componentOpening and closing the doors and windows,
adjustment before driving, etc.
4DrivingOperations and advice which are necessary for
driving
5Audio systemOperating the audio system
6Interior featuresUsage of the interior features, etc.
7Maintenance
and careCaring for your vehicle and maintenance
procedures
8When trouble
arisesWhat to do in case of malfunction or emergency
9Vehicle
specificationsVehicle specifications, customizable features, etc.
10For ownersReporting safety defects for U.S. owners, and seat
belt and SRS airbag instructions for Canadian
owners
IndexSearch by symptom
Search alphabetically
Page 2 of 620
TABLE OF CONTENTS2
PRIUS v_OM_OM47B12U_(U)For your information....................... 8
Reading this manual .................... 14
How to search .............................. 15
Pictorial index .............................. 16
1-1. For safe use
Before driving ...................... 28
For safety drive ................... 30
Seat belts ............................ 32
SRS airbags ........................ 41
Front passenger occupant
classification system ......... 52
Safety information for
children ............................. 57
Child restraint systems ........ 58
Installing child restraints ...... 62
Exhaust gas precautions ..... 72
1-2. Hybrid system
Hybrid system features ....... 73
Hybrid system
precautions ....................... 77
1-3. Theft deterrent system
Immobilizer system ............. 822. Instrument cluster
Warning lights and
indicators ........................... 86
Gauges and meters ............. 91
Multi-information display .... 100
Energy monitor/
consumption screen ........ 108
3-1. Key information
Keys................................... 116
3-2. Opening, closing and
locking the doors
Side doors ......................... 120
Back door .......................... 125
Smart key system .............. 130
3-3. Adjusting the seats
Front seats......................... 138
Rear seats ......................... 142
Head restraints .................. 145
1For safety and security
2Instrument cluster
3Operation of each
component
Page 3 of 620
3
1
9 8
7
6 4 3
2
PRIUS v_OM_OM47B12U_(U)
10
5
3-4. Adjusting the steering
wheel and mirrors
Steering wheel .................. 147
Inside rear view mirror....... 149
Outside rear view
mirrors ............................. 151
3-5. Opening and closing the
windows
Power windows ................. 153
4-1. Before driving
Driving the vehicle ............. 158
Cargo and luggage............ 167
Vehicle load limits ............. 171
Trailer towing..................... 172
Dinghy towing.................... 173
4-2. Driving procedures
Power (ignition) switch ...... 174
EV drive mode................... 179
Hybrid transmission........... 181
Turn signal lever................ 187
Parking brake .................... 1884-3. Operating the lights
and wipers
Headlight switch ................ 189
Automatic High Beam ........ 194
Fog light switch .................. 200
Windshield wipers and
washer ............................. 202
Rear window wiper and
washer ............................. 205
4-4. Refueling
Opening the fuel tank
cap................................... 207
4-5. Using the driving support
systems
Cruise control .................... 210
Dynamic radar cruise
control.............................. 214
LDA (Lane Departure
Alert) ................................ 227
Rear view monitor
system ............................. 235
Driving mode select
switch .............................. 245
Driving assist systems ....... 246
PCS (Pre-Collision
System) ........................... 253
4-6. Driving tips
Hybrid vehicle driving
tips ................................... 260
Winter driving tips .............. 263
4Driving
Page 4 of 620
TABLE OF CONTENTS4
PRIUS v_OM_OM47B12U_(U)5-1. Basic Operations
Audio system types .......... 268
Audio system .................... 269
Using the steering wheel
audio switches ................ 272
AUX Port/USB Port........... 273
Basic audio operations ..... 274
5-2. Setup
Setup menu ...................... 276
General settings ............... 277
Audio settings ................... 279
Display settings ................ 281
Voice settings ................... 284
5-3. Using the Multimedia
system
Selecting the audio
source ............................. 285
List screen operation ........ 286
Optimal use of the audio
system ............................ 288
Audio screen
adjustment ...................... 2895-4. Using the radio
Radio operation................. 290
5-5. Playing an audio CD and
MP3/WMA/AAC discs
CD player operation .......... 292
5-6. Using an external device
Listening to an iPod .......... 298
Listening to a USB
memory device ............... 303
Using the AUX .................. 308
VTR ................................... 309
5-7. Connecting Bluetooth
®
Preparations to
use wireless
communication ................ 310
Registering a Bluetooth
®
audio player for the
first time .......................... 313
Registering a Bluetooth
®
phone for the first time .... 314
Registering a
Bluetooth
® device ........... 315
Connecting a
Bluetooth
® device ........... 317
Displaying a Bluetooth®
device details .................. 319
Detailed Bluetooth
®
system settings ............... 320
5-8. Bluetooth
® Audio
Listening to Bluetooth®
Audio............................... 321
5Audio system
Page 5 of 620
5
1
9 8
7
6 4 3
2
PRIUS v_OM_OM47B12U_(U)
10
5
5-9. Bluetooth® phone
Using a Bluetooth®
Phone ............................. 323
Making a call..................... 326
Receiving a call ................ 329
Speaking on the phone..... 330
Bluetooth
® phone
message function ........... 333
Using the steering wheel
switches.......................... 337
Bluetooth
® phone
settings ........................... 338
Contact/Call History
Settings .......................... 339
What to do if...
(Troubleshooting) ........... 348
5-10. Bluetooth
®
Bluetooth®........................ 352
5-11. Using the voice
command system
Voice command system ... 3586-1. Using the air conditioning
system and defogger
Automatic air conditioning
system ............................. 364
Using the steering wheel
climate remote control
switches........................... 371
Seat heaters ...................... 372
6-2. Using the interior lights
Interior lights list................. 373
• Front interior light .......... 374
• Front personal lights ...... 374
• Rear interior light ........... 375
6-3. Using the storage features
List of storage features ...... 376
• Glove boxes .................. 377
• Console box .................. 377
• Cup holders/
bottle holders/
door pockets.................. 378
• Auxiliary boxes .............. 380
• Card holder ................... 380
Luggage compartment
features ........................... 381
6Interior features
Page 6 of 620
TABLE OF CONTENTS6
PRIUS v_OM_OM47B12U_(U)6-4. Using the other interior
features
Other interior features ....... 385
• Sun visors ..................... 385
• Vanity mirrors................ 385
• Clock ............................. 386
• Power outlet .................. 386
• Armrest ......................... 387
• Assist grips ................... 388
• Panoramic roof
shades .......................... 389
Garage door opener .......... 391
Safety Connect.................. 3987-1. Maintenance and care
Cleaning and protecting
the vehicle exterior .......... 406
Cleaning and protecting
the vehicle interior ........... 410
7-2. Maintenance
Maintenance
requirements ................... 413
General maintenance ........ 415
Emission inspection and
maintenance (I/M)
programs ......................... 418
7-3. Do-it-yourself maintenance
Do-it-yourself service
precautions ...................... 419
Hood .................................. 421
Positioning a floor jack....... 423
Engine compartment ......... 425
12-volt battery .................... 439
Tires................................... 443
Tire inflation pressure ........ 452
Wheels............................... 455
Air conditioning filter .......... 457
Wiper rubber
replacement..................... 459
Electronic key battery ........ 461
Checking and replacing
fuses ................................ 463
Light bulbs ......................... 466
7Maintenance and care
Page 7 of 620
7
1
9 8
7
6 4 3
2
PRIUS v_OM_OM47B12U_(U)
10
5
8-1. Essential information
Emergency flashers .......... 482
If your vehicle has to
be stopped in an
emergency ...................... 483
8-2. Steps to take in an
emergency
If your vehicle needs to
be towed ......................... 484
If you think something is
wrong .............................. 489
If a warning light turns on
or a warning buzzer
sounds ............................ 490
If a warning message is
displayed ......................... 503
If you have a flat tire .......... 521
If the hybrid system will
not start ........................... 534
If the electronic key does
not operate properly ........ 536
If the 12-volt battery is
discharged ...................... 538
If your vehicle overheats ... 543
If the vehicle becomes
stuck................................ 5489-1. Specifications
Maintenance data
(fuel, oil level, etc.) .......... 552
Fuel information ................. 561
Tire information.................. 564
9-2. Customization
Customizable features ....... 575
9-3. Initialization
Items to initialize ................ 583
Reporting safety defects
for U.S. owners ........................ 586
Seat belt instructions
for Canadian owners
(in French)................................ 587
SRS airbag instructions
for Canadian owners
(in French)................................ 589
What to do if...
(Troubleshooting) ..................... 600
Alphabetical index ...................... 603
8When trouble arises9Vehicle specifications
10For owners
Index
For vehicles with a navigation system, refer to the “NAVIGATION
SYSTEM OWNER’S MANUAL” for information regarding the equip-
ment listed below.
• Navigation system• Audio/visual system
Page 8 of 620
8
PRIUS v_OM_OM47B12U_(U)
For your infor mation
Please note that this manual applies to all models and explains all equipment,
including options. Therefore, you may find some explanations for equipment
not installed on your vehicle.
All specifications provided in this manual are current at the time of printing.
However, because of the Toyota policy of continual product improvement, we
reserve the right to make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustrations may differ
from your vehicle in terms of color and equipment.
Approximately five hours after the hybrid system is turned off, you may hear
sound coming from under the vehicle for several minutes. This is the sound of
a fuel evaporation leakage check and, it does not indicate a malfunction.
A wide variety of non-genuine spare parts and accessories for Toyota vehi-
cles are currently available in the market. You should know that Toyota does
not warrant these products and is not responsible for their performance,
repair, or replacement, or for any damage they may cause to, or adverse
effect they may have on, your Toyota vehicle.
This vehicle should not be modified with non-genuine Toyota products. Modi-
fication with non-genuine Toyota products could affect its performance, safety
or durability, and may even violate governmental regulations. In addition,
damage or performance problems resulting from the modification may not be
covered under warranty.
Main Owner’s Manual
Noise from under vehicle after turning off the hybrid system
Accessories, spare parts and modification of your Toyota
Page 9 of 620
PRIUS v_OM_OM47B12U_(U)
9
The installation of a mobile two-way radio system in your vehicle could affect
electronic systems such as:
●Multiport fuel injection system/sequential multiport fuel injection system
●Dynamic radar cruise control system
●Cruise control system
●Anti-lock brake system
●SRS airbag system
●Seat belt pretensioner system
Be sure to check with your Toyota dealer for precautionary measures or spe-
cial instructions regarding installation of a mobile two-way radio system.
High voltage parts and cables on the hybrid vehicles emit approximately the
same amount of electromagnetic waves as the conventional gasoline pow-
ered vehicles or home electronic appliances despite of their electromagnetic
shielding.
Unwanted noise may occur in the reception of the mobile two-way radio.
Installation of a mobile two-way radio system
Page 10 of 620
10
PRIUS v_OM_OM47B12U_(U)Your Toyota is equipped with several sophisticated computers that will record
certain data, such as:
• Engine speed
• Electric motor speed (traction motor speed)
• Accelerator status
• Brake status
• Vehicle speed
• Shift position
• Hybrid battery (traction battery) status
The recorded data varies according to the vehicle grade level and options
with which it is equipped. Furthermore, these computers do not record con-
versations, sounds or pictures.
●Data usage
Toyota may use the data recorded in these computers to diagnose malfunc-
tions, conduct research and development, and improve quality.
Toyota will not disclose the recorded data to a third party except:
• With the consent of the vehicle owner or with the consent of the lessee if
the vehicle is leased
• In response to an official request by the police, a court of law or a govern-
ment agency
• For use by Toyota in a lawsuit
• For research purposes where the data is not tied to a specific vehicle or
vehicle owner
●Usage of data collected through Safety Connect (U.S. mainland only)
If your Toyota has Safety Connect and if you have subscribed to those ser-
vices, please refer to the Safety Connect Telematics Subscription Service
Agreement for information on data collected and its usage.
Vehicle data recordings
