Page 281 of 624

281
RAV4_OM_OM42809U_(U)
4-6. Driving tips
4
Driving
Utility vehicle precautions
●Specific design characte ristics give it a higher center of gravity than
ordinary passenger cars. This vehi cle design feature causes this
type of vehicle to be more likely to rollover. And, utility vehicles
have a significantly higher rollover rate than other types of vehicles.
● An advantage of the higher ground clearance is a better view of the
road allowing you to anticipate problems.
● It is not designed for cornering at the same speeds as ordinary pas-
senger cars any more than low-slung sports cars designed to per-
form satisfactorily under off-road co nditions. Therefore, sharp turns
at excessive speeds may cause the vehicle to rollover.
This vehicle belongs to the util ity vehicle class, which has
higher ground clearance and narrowe r tread in relation to the
height of its center of gravity to make it capable of performing in
a wide variety of off-road applications.
Utility vehicle feature
Page 282 of 624

282
RAV4_OM_OM42809U_(U)
4-6. Driving tips
CAUTION
■Utility vehicle precautions
Always observe the following precautions to minimize the risk of death, seri-
ous injury or damage to your vehicle:
●In a rollover crash, an unbelted person is significantly more likely to die
than a person wearing a seat belt. Th erefore, the driver and all passengers
should fasten their seat belts whenever the vehicle is moving.
● Avoid sharp turns or abrupt maneuvers, if at all possible.
Failure to operate this vehicle correctly may result in loss of control or
vehicle rollover causing death or serious injury.
● Loading cargo on the roof luggage carrier (if equipped) will make the cen-
ter of the vehicle gravity higher. Avoid high speeds, sudden starts, sharp
turns, sudden braking or abrupt maneuvers, otherwise it may result in loss
of control or vehicle rollover due to failure to operate this vehicle correctly.
● Always slow down in gusty crosswinds. Because of its profile and higher
center of gravity, your vehicle is more sensitive to side winds than an ordi-
nary passenger car. Slowing down will allow you to have better control.
● Do not drive horizontally across steep slopes. Driving straight up or
straight down is preferred. Your vehicle (or any similar off-road vehicle)
can tip over sideways much more easily than forward or backward.
Page 283 of 624

RAV4_OM_OM42809U_(U)
2834-6. Driving tips
4
Driving
When driving your vehicle off-road, please observe the following pre-
cautions to ensure your driving enjoyment and to help prevent the clo-
sure of areas to off-road vehicles.
● Drive your vehicle only in areas where off-road vehicles are permit-
ted to travel.
● Respect private property. Get owner’s permission before entering
private property.
● Do not enter areas that are clos ed. Honor gates, barriers and signs
that restrict travel.
● Stay on established roads. When conditions are wet, driving tech-
niques should be changed or trav el delayed to prevent damage to
roads.
■ Additional information for off-road driving
For owners in U.S. mainland, Hawaii and Puerto Rico:
To obtain additional information pertaini ng to driving your vehicle off-road,
consult the following organizations.
● State and Local Parks and Recreation Departments
● State Motor Vehicle Bureau
● Recreational Vehicle Clubs
● U.S. Forest Service and Bureau of Land Management
Off-road driving
Page 284 of 624

284
RAV4_OM_OM42809U_(U)
4-6. Driving tips
CAUTION
■Off-road driving precautions
Always observe the following precautions to minimize the risk of death, seri-
ous injury or damage to your vehicle:
●Drive carefully when off the road. Do not take unnecessary risks by driving
in dangerous places.
● Do not grip the steering wheel spok es when driving off-road. A bad bump
could jerk the wheel and injure your hands. Keep both hands and espe-
cially your thumbs on the outside of the rim.
● Always check your brakes for effectiveness immediately after driving in
sand, mud, water or snow.
● After driving through tall grass, mud, rock, sand, water, etc., check that
there is no grass, bush, paper, rags, stone, sand, etc. adhering or trapped
on the underbody. Clear off any such matter from the underbody. If the
vehicle is used with these materials trapped or adhering to the underbody,
a breakdown or fire could occur.
● When driving off-road or in rugged te rrain, do not drive at excessive
speeds, jump, make sharp turns, strike objects, etc. This may cause loss
of control or vehicle rollover causing death or serious injury. You are also
risking expensive damage to your vehicle’s suspension and chassis.
Page 285 of 624

RAV4_OM_OM42809U_(U)
2854-6. Driving tips
4
Driving
NOTICE
■To prevent the water damage
Take all necessary safety measures to ensure that water damage to the
engine or other components does not occur.
●Water entering the engine air intake will cause severe engine damage.
● Water entering the automatic transmission will cause deterioration in shift
quality, locking up of your transmission accompanied by vibration, and ulti-
mately damage.
● Water can wash the grease from wheel bearings, causing rusting and pre-
mature failure, and may also enter the differentials, transmission and
transfer case, reducing the gear oil’s lubricating qualities.
■ When you drive through water
If driving through water, such as when crossing shallow streams, first check
the depth of the water and the bottom of the stream for firmness. Drive
slowly and avoid deep water.
■ Inspection after off-road driving
●Sand and mud that has accumulated around brake drums and around
brake discs may affect braking efficiency and may damage brake system
components.
● Always perform a maintenance inspection after each day of off-road driv-
ing that has taken you through rough terrain, sand, mud, or water. For
scheduled maintenance information, refer to the “Scheduled Maintenance
Guide” or “Owner’s Manual Supplement”.
Page 286 of 624

286
RAV4_OM_OM42809U_(U)
5-1. Using the air conditioning system and defogger
Manual air conditioning system ............................ 288
Automatic air conditioning system ... 295
Rear window and outside rear view mirror
defoggers ........................ 305
Windshield wiper de-icer ... 307
5Interior features
Page 287 of 624

287
RAV4_OM_OM42809U_(U)
5Interior features
5-2. Using the audio systemAudio system types ........... 308
Using the radio .................. 312
Using the CD player .......... 315
Playing back MP3 and WMA discs ...................... 320
Operating an iPod ............. 327
Operating a USB memory................... 335
Optimal use of the audio system ................... 343
Using the AUX port ........... 345
Using the steering wheel audio switches ................ 346
Bluetooth
® audio/phone .... 349
Using the Bluetooth®
audio/phone .................... 354
Operating a Bluetooth
®
enabled portable
player .............................. 359
Making a phone call .......... 362
Using the “SETUP” menu (“Bluetooth
*”
menu) .............................. 367
Using the “SETUP” menu (“PHONE” menu) ............ 372 5-3. Using the interior lights
Interior lights list ................ 377
• Interior lights ................. 378
• Personal lights .............. 378
5-4. Using the storage features List of storage features ..... 380
• Glove box...................... 381
• Console box .................. 382
• Cup holders .................. 383
• Bottle holders ................ 384
Luggage compartment features ........................... 385
5-5. Other interior features Sun visors and vanity mirrors ............................. 395
Clock ................................. 396
Power outlets .................... 397
Seat heaters...................... 398
Armrest ............................. 400
Coat hooks ........................ 401
Assist grips........................ 402
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Page 288 of 624

288
RAV4_OM_OM42809U_(U)
5-1. Using the air conditioning system and defogger
Manual air conditioning system
: If equipped
Air outlet selector dial
Fan speed control dial
Temperature control dial Cooling and dehumidification
function on/off button
Outside/recirculated air mode
button1
2
3
4
5
Page 289 of 624

RAV4_OM_OM42809U_(U)
2895-1. Using the air conditioning system and defogger
5
Interior features
To adjust the fan speed, turn the fan speed control dial clockwise
(increase) or counterclockwise (decrease).
Turning the dial to “0” turns off the fan.
To adjust the temperature setting, turn the temperature control dial
clockwise (warm) or counterclockwise (cool).
If is not pressed, the system will blow ambient temperature air or
heated air.
To select the air outlets, set the air outlet selector dial to the desired
position.
The positions between the air outlet selections shown below can also be
selected for more delicate adjustment.
Adjusting the settings
1
2
3
Page 290 of 624

290
RAV4_OM_OM42809U_(U)
5-1. Using the air conditioning system and defogger
Set the air outlet selector dial to
position.
If the recirculated air mode is used,
it will automatically switch to the
outside air mode.
Perform the following operations accordingly:
●To adjust the fan speed, turn the fan speed control dial.
● To adjust the temperature setting, turn the temperature control
dial.
● If the dehumidification functi on is not operating, press to
operate the dehumidif ication function.
To defog the windshield and the side windows early, turn the air
flow and temperature up.
Upper body
Defogging the windshield
1
Air outlets and air flow
2
