TOYOTA RAV4 2016 XA40 / 4.G Owners Manual

480
RAV4_OM_OM42A41U_(U)
5-23. Other function
Some recognizable voice commands and their actions are shown
below as examples.
Basic
Phone
Command list
CommandAction
“Help”Prompts voice guidance to offer examples of com-
mands or operation methods
“Go Back”Returns to the previous screen
CommandAction
“Redial”Places a call to the phone number of the latest outgo-
ing call
“Call Back”Places a call to the phone number of latest incoming
call
“Show Recent
Calls”Displays the call history screen
“Dial ber>”Places a call to the said phone number
“Call
”Places a call to the said phone type of the contact
from the phone book

RAV4_OM_OM42A41U_(U)
4815-23. Other function
5
Audio system
The Mobile Assistant feature will activate Apple’s Siri® Eyes Free
mode via the steering wheel switc hes. To operate the Mobile Assis-
tant, a compatible cellular phone must be registered and connected to
this system via Bluetooth
®. ( → P. 435)
Press and hold the until
you hear the beeps.
The Mobile Assistant can be
used only when the following
screen is displayed.
To cancel the Mobile Assistant,
select “Cancel”, or press and hold
the on the steering wheel.
To restart the Mobile Assistant for
additional commands, press the on the steering wheel.
• Mobile Assistant can only be restarted after the system responds to a voice command.
• After some phone and music commands, the Mobile Assistant feature will automatically end to complete the requested action.
■
Adjusting the Mobile Assistant volume
The volume of the Mobile Assistant can be adjusted using the
“PWR/VOL” knob or steering wheel volume control switches. The
Mobile Assistant and phone call volumes are synchronized.
Mobile Assistant
1
2

482
RAV4_OM_OM42A41U_(U)
5-23. Other function
■Notes about Mobile Assistant
●The available features and functions may vary based on the iOS version
installed on the connected device.
● Some Siri features are limited in Eyes Free mode. If you attempt to use an
unavailable function, Siri will inform you that the function is not avai\
lable.
● If Siri is not enabled on the cellular phone connected via Bluetooth
®, an
error message will be displayed on the screen.
● While a phone call is active, the Mobile Assistant cannot be used.
● If using the navigation feature of the cellular phone, ensure the active audio
source is Bluetooth
® audio or iPod in order to hear turn by turn direction
prompts.

483
RAV4_OM_OM42A41U_(U)
6Interior features
6-1. Using the air conditioning system and defogger
Manual air conditioning system ............................ 484
Automatic air conditioning system ... 490
Heated steering wheel/ seat heaters .................... 499
6-2. Using the interior lights Interior lights list ................ 501• Interior lights ................. 502
• Personal lights .............. 502
6-3. Using the storage features List of storage features ..... 504• Glove box...................... 505
• Console box .................. 505
• Cup holders .................. 506
• Bottle holders ................ 507
• Auxiliary box ................. 507
Luggage compartment features ........................... 508
6-4. Using the other interior features
Other interior features ....... 519 • Sun visors .................... 519
• Vanity mirrors ............... 519
• Power outlets ................ 520
• Armrest ......................... 521
• Coat hooks.................... 521
• Assist grips .................. 522
Garage door opener.......... 523
Compass ........................... 530

484
RAV4_OM_OM42A41U_(U)
6-1. Using the air conditioning system and defogger
Manual air conditioning system∗
■Adjusting the temperature setting
Turn the temperature control dial clockwise (warm) or counterclock-
wise (cool).
If the “A/C” button is not pressed, the system will blow ambient tempera-
ture air or heated air.
■
Adjusting the fan speed setting
Turn the fan speed control dial clockwise (increase) or counter-
clockwise (decrease).
Turning the dial to “0” turns off the fan.
∗: If equipped
Control panel

RAV4_OM_OM42A41U_(U)
4856-1. Using the air conditioning system and defogger
6
Interior features
■Changing the air flow mode
Turn the air outlet selector dial
to change the airflow mode.
The positions between the air
outlet selections can also be
selected for more delicate
adjustment.
Air flows to the upper body.
Air flows to the upper body
and feet.
Air flows to the feet.
Air flows to the feet and the windshield defogger operates.
■Switching between outside air and recirculated air modes
Press .
The mode switches between outside air mode (indicator off) and recir-
culated air mode (indicator on) each time is pressed.
■
Defogging the windshield
Defoggers are used to defog the windshield and front side win-
dows.
Turn the air outlet selector dial to position.
Set the outside/recirculated air mode button to outside air mode if recir-
culated air mode is used.
Adjust the fan speed and temperature setting.( →P. 484)
If the dehumidification function is not operating, press the “A/C” but-
ton to operate the dehumi dification function.
To defog the windshield and the side windows early, turn the air flow and
temperature up.
1
2
Other functions
3
4

486
RAV4_OM_OM42A41U_(U)
6-1. Using the air conditioning system and defogger
■Defogging the rear window and out side rear view mirrors (if
equipped)
Defoggers are used to defog the rear window, and to remove rain-
drops, dew and frost from the outside rear view mirrors.
Press .
The defoggers will automatically turn off after a period of time.
■
Windshield wiper de-icer (if equipped)
This feature is used to prevent ice from building up on the wind-
shield and wiper blades.
Turns on/off
The windshield wiper de-icer will
automatically turn off after a
period of time.
■
Location of air outlets
The air outlets and air volume
changes according to the
selected air flow mode.
Air outlets

RAV4_OM_OM42A41U_(U)
4876-1. Using the air conditioning system and defogger
6
Interior features
■Adjusting the position of and opening and closing the air out-
lets
Front center outlets
Direct air flow to the left or
right, up or down.
Turn the knobs to open or
close the vents.
Turn the knob to open or
close the vent for rear seat
occupants.
Front side outlets
Direct air flow to the left or
right, up or down.
Open the vent.
Close the vent.
1
2
3
1
2

488
RAV4_OM_OM42A41U_(U)
6-1. Using the air conditioning system and defogger
■Operation of the air conditio ning system in Eco drive mode
In Eco drive mode, the air conditioning system is controlled to prioritize fuel
efficiency by regulating the engine speed and compressor operation to
restrict the heating/cooling capacity.
To improve air conditioning performance, perform the following operations:
● Adjust the fan speed
● Adjust the temperature setting
● Turn off Eco drive mode ( →P. 205)
■ Fogging up of the windows
●The windows will easily fog up when the humidity in the vehicle is high.
Turning on will dehumidify the air from the outlets and defog the wind-
shield effectively.
● If you turn off, the windows may fog up more easily.
● The windows may fog up if the recirculated air mode is used.
■ Outside/recirculated air mode
When driving on dusty roads such as tunnels or in heavy traffic, set the out-
side/recirculated air mode button to the recirculated air mode. This is effective
in preventing outside air from entering the vehicle interior. During cooling
operation, setting the recirculated air mode will also cool the vehicle interior
effectively.
■ When the outside temperature is low (vehicles with the “A/C” button)
The dehumidification function may not operate even when the “A/C” button is
pressed.
■ Ventilation and air conditioning odors
●To let fresh air in, set the air conditioning system to the outside air m\
ode.
● During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to
be emitted from the vents.
● To reduce potential odors from occurring:
It is recommended that the air conditioning system be set to outside air
mode prior to turning the vehicle off.
■ Air conditioning filter
→P. 583

RAV4_OM_OM42A41U_(U)
4896-1. Using the air conditioning system and defogger
6
Interior features
WARNING
■To prevent the windshield from fogging up
● Do not set the air outlet selection dial to during cool air operation in
extremely humid weather. The difference between the temperature of the
outside air and that of the windshield can cause the outer surface of the
windshield to fog up, blocking your vision.
■ To prevent burns
● Vehicles with outside rear view mirror defoggers: Do not touch the rear
view mirror surfaces when the outsi de rear view mirror defoggers are on.
● Vehicles with windshield wiper de-icer: Do not touch the glass at lower part
of the windshield or to the side of the front pillars when the windshield
wiper de-icer is on.
NOTICE
■To prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the
engine is off.
● Do not place anything on the instrument
panel which may cover the air outlets.
Otherwise, air flow may be obstructed,
preventing the windshield defoggers
from defogging.
