TOYOTA RAV4 2018 Owners Manual (in English)

321
RAV4_OM_OM0R012U_(U)
4-6. Driving tips
4
Driving
Utility vehicle precautions
●Specific design char acteristics give it a higher center of gravity than
ordinary passenger cars. This vehi cle design feature causes this
type of vehicle to be more likely to rollover. And, utility vehicles
have a significantly higher rollover rate than other types of vehicles.
● An advantage of the higher ground clearance is a better view of the
road allowing you to anticipate problems.
● It is not designed for cornering at the same speeds as ordinary pas-
senger cars any more than low- slung sports cars are designed to
perform satisfactorily under off -road conditions. Therefore, sharp
turns at excessive speeds may c ause the vehicle to rollover.
This vehicle belongs to the util ity vehicle class, which has
higher ground clearance and narrowe r tread in relation to the
height of its center of gravity to make it capable of performing in
a wide variety of off-road applications.
Utility vehicle feature
WARNING
■ Utility vehicle precautions
Always observe the following precautions to minimize the risk of death, seri-
ous injury or damage to your vehicle:
● In a rollover crash, an unbelted person is significantly more likely to die
than a person wearing a seat belt. Therefore, the driver and all passengers
should always fasten their seat belts.
● Avoid sharp turns or abrupt maneuvers, if at all possible.
Failure to operate this vehicle correctly may result in loss of control or
vehicle rollover causing death or serious injury.
● Loading cargo on the roof luggage carrier (if equipped) will make the cen-
ter of the vehicle gravity higher. Avoid high speeds, sudden starts, sharp
turns, sudden braking or abrupt maneuvers, otherwise it may result in loss
of control or vehicle rollover due to failure to operate this vehicle correctly.
● Always slow down in gusty crosswinds. Because of its profile and higher
center of gravity, your vehicle is more sensitive to side winds than an ordi-
nary passenger car. Slowing down will allow you to have better control.
● Do not drive horizontally across steep slopes. Driving straight up or
straight down is preferred. Your vehicle (or any similar off-road vehicle)
can tip over sideways much more easily than forward or backward.

322
RAV4_OM_OM0R012U_(U)
4-6. Driving tips
When driving your vehicle off-road, please observe the following pre-
cautions to ensure your driving enjoyment and to help prevent the clo-
sure of areas to off-road vehicles:
● Drive your vehicle only in areas where off-road vehicles are permit-
ted to travel.
● Respect private property. Get owner’s permission before entering
private property.
● Do not enter areas that are clos ed. Honor gates, barriers and signs
that restrict travel.
● Stay on established roads. When c onditions are wet, driving tech-
niques should be changed or trav el delayed to prevent damage to
roads.
■ Additional information for off-road driving
For owners in U.S. mainland, Hawaii and Puerto Rico:
To obtain additional information pertain ing to driving your vehicle off-road,
consult the following organizations:
● State and Local Parks and Recreation Departments
● State Motor Vehicle Bureau
● Recreational Vehicle Clubs
● U.S. Forest Service and Bureau of Land Management
Off-road driving

RAV4_OM_OM0R012U_(U)
3234-6. Driving tips
4
Driving
WARNING
■Off-road driving precautions
Always observe the following precautions to minimize the risk of death, seri-
ous injury or damage to your vehicle:
● Drive carefully when off the road. Do not take unnecessary risks by driving
in dangerous places.
● Do not grip the steering wheel spokes when driving off-road. A bad bump
could jerk the wheel and injure your hands. Keep both hands and espe-
cially your thumbs on the outside of the rim.
● Always check your brakes for effectiveness immediately after driving in
sand, mud, water or snow.
● After driving through tall grass, mud, rock, sand, rivers, etc., check that
there is no grass, bush, paper, rags, stone, sand, etc. adhering or trapped
on the underbody. Clear off any such matter from the underbody. If the
vehicle is used with these materials trapped or adhering to the underbody,
a breakdown or fire could occur.
● When driving off-road or in rugged te rrain, do not drive at excessive
speeds, jump, make sharp turns, strike objects, etc. This may cause loss
of control or vehicle rollover causing death or serious injury. You are also
risking expensive damage to your vehicle’s suspension and chassis.

324
RAV4_OM_OM0R012U_(U)
4-6. Driving tips
NOTICE
■To prevent the water damage
Take all necessary safety measures to ensure that water damage to the
engine or other components does not occur.
● Water entering the engine air intake will cause severe engine damage.
● Water entering the automatic transmission will cause deterioration in shift
quality, locking up of your transmission accompanied by vibration, and ulti-
mately damage.
● Water can wash the grease from wheel bearings, causing rusting and pre-
mature failure, and may also enter the differentials, transmission and
transfer case (AWD models), reducing the gear oil’s lubricating qualities.
■ When you drive through water
If driving through water, such as when crossing shallow streams, first check
the depth of the water and the bottom of the riverbed for firmness. Drive
slowly and avoid deep water.
■ Inspection after off-road driving
● Sand and mud that has accumulated around brake drums and around
brake discs may affect braking efficiency and may damage brake system
components.
● Always perform a maintenance inspection after each day of off-road driv-
ing that has taken you through rough terrain, sand, mud, or water. For
scheduled maintenance information, refer to the “Scheduled Maintenance
Guide” or “Owner’s Manual Supplement”.

RAV4_OM_OM0R012U_(U)
3254-6. Driving tips
4
Driving

326
RAV4_OM_OM0R012U_(U)
5-1. Basic OperationsAudio system types ........... 328
Using the steering wheel audio switches ................ 331
AUX port/USB port ............ 334
5-2. Using the audio system Optimal use of the audio system ................... 336
5-3. Using the radio Radio operation ................. 338
5-4. Playing an audio CD and MP3/WMA discs
CD player operation .......... 340
5-5. Using an external device Listening to an iPod .......... 350
Listening to USB memory device................ 356
Using the AUX port ........... 362
5-6. Using Bluetooth
® devices
Bluetooth® audio/
phone .............................. 363
Using the steering wheel switches ................ 368
Register a Bluetooth
®
device.............................. 369
5-7. “SETUP” menu Using the “SETUP” menu (“Bluetooth
*” menu) ........ 370
Using the “SETUP” menu (“PHONE” menu) ............ 375 5-8. Bluetooth
® Audio
Operating a Bluetooth®
enabled portable
player .............................. 380
5-9. Bluetooth
® Phone
Making a phone call .......... 383
When receiving a phone call ....................... 385
Speaking on the phone ..... 386
5-10. Bluetooth
®
Bluetooth®......................... 388
5-11. Using the audio system (Entune Audio)
Audio system (Entune Audio) ................ 392
5-12. Basic Operations Audio system operations (Entune Audio) ................ 394
Steering wheel audio switches .......................... 396
AUX port/USB port ............ 397
Basic audio operations...... 398
5-13. Setup Setup menu....................... 400
General settings ................ 401
Audio settings ................... 403
Display settings ................. 404
Voice settings.................... 406
5-14. Using the audio system Selecting the audio source ............................. 407
List screen operation......... 408
Optimal use of the audio system ............................ 410
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.
5Audio system

327
RAV4_OM_OM0R012U_(U)
5Audio system
5-15. Using the radioRadio operation ................. 411
5-16. Playing an audio CD and MP3/WMA/AAC discs
CD player operation .......... 413
CD player and disc information ...................... 414
5-17. Using an external device iPod player operation ........ 420
USB memory device player operation .............. 425
Using the AUX port ........... 430
5-18. Connecting Bluetooth
®
Preparations to use wireless
communication ................ 431
Registering a Bluetooth
®
audio player for the
first time .......................... 434
Registering a Bluetooth
®
phone for the
first time .......................... 435
Registering a Bluetooth
®
device.............................. 436
Connecting a Bluetooth
®
device.............................. 438
Displaying a Bluetooth
®
device details .................. 440
Detailed Bluetooth
®
settings............................ 441 5-19. Bluetooth
® Audio
Listening to Bluetooth®
Audio............................... 443
5-20. Bluetooth
® Phone
Using a Bluetooth®
Phone ............................. 445
Making a call ..................... 447
Receiving a call ................. 450
Speaking on the phone ..... 451
Bluetooth
® phone
message function ............ 454
Using the steering wheel switches ................ 459
Bluetooth
® phone
settings ........................... 460
5-21. Phonebook Contact/Call History Settings ........................... 462
5-22. Bluetooth
®
What to do if... (Troubleshooting) ............ 472
Bluetooth
®......................... 476
5-23. Other function Voice command system ............................ 482

328
RAV4_OM_OM0R012U_(U)
5-1. Basic Operations
Audio system types
Vehicles with Entune Premium Audio with Navigation
Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S
MANUAL”.
Vehicles with Entune Audio Plus
Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S
MANUAL”.
Vehicles with Entune Audio
→ P. 3 9 2

RAV4_OM_OM0R012U_(U)
3295-1. Basic Operations
5
Audio system
Vehicles without Entune Premium Audio with Navigation or Entune
Audio Plus or Entune Audio
CD player with AM/FM radio
Press the “SETUP” button.
Turn the “TUNE•SCROLL” knob to select “Language”.
Press the knob.
Turn the knob as corresponds to the desired language.
“English”, “Español”, or “Français” can be selected.
Press the knob or (SAVE) to return to the setup menu.
■Using cellular phones
Interference may be heard through the audio system’s speakers if a cellular
phone is being used inside or close to the vehicle while the audio system is
operating.
Changing language setting
1
2
3
4

330
RAV4_OM_OM0R012U_(U)
5-1. Basic Operations
WARNING
■Certification for the disc player
● Part 15 of the FCC Rules
FCC Warning:
Changes or modifications not expressly approved by the party responsi-
ble for compliance could void the user’s authority to operate the equip-
ment.
● Laser products
• Do not take this unit apart or attempt to make any changes yourself.
This is an intricate unit that uses a laser pickup to retrieve information
from the surface of compact discs. The laser is carefully shielded so
that its rays remain inside the cabinet. Therefore, never try to disassem-
ble the player or alter any of its parts since you may be exposed to laser
rays and dangerous voltages.
• This product utilizes a laser. Use of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous radiation exposure.
NOTICE
■To prevent battery discharge
Do not leave the audio system on longer than necessary with the engine is
stopped.
■ To avoid damaging the audio system
Take care not to spill drinks or other fluids over the audio system.
