TOYOTA RAV4 2018 Owners Manual (in English)

RAV4_OM_OM0R012U_(U)
721
10
For owners
AVERTISSEMENT
■Précautions relatives aux coussins gonflables SRS
● N’accrochez pas de cintres ni d’objets rigides sur les crochets porte-vête-
ments. Tous ces objets pourraient se transformer en projectiles et vous
occasionner des blessures graves, voire mortelles, en cas de déploiement
des coussins gonflables SRS en rideau.
● Si un recouvrement de vinyle est placé sur la zone de déploiement du
coussin gonflable SRS de protection des genoux, veillez à le retirer.
● N’tilisez pas d’ccessoires recouvrant les parties du siège où les coussins
gonflables SRS latéraux et le coussin gonflable SRS du coussin de siège
se déploient, car ces accessoires pourraient entraver le déploiement des
coussins SRS. De tels accessoires peuvent empêcher les coussins gon-
flables latéraux et le coussin gonflable du coussin de siège de se déployer
correctement, rendre le système inopérant ou provoquer accidentellement
le déploiement des coussins gonflables latéraux et du coussin gonflable
du coussin de siège, occasionnant des blessures graves, voire mortelles.
● Ne frappez pas et n’ppliquez pas une pression importante à l’mplacement
des composants des coussins gonflables SRS.
Vous risquez de provoquer un mauvais fonctionnement des coussins gon-
flables SRS.
● Ne touchez à aucun composant des coussins gonflables SRS immédiate-
ment après leur déploiement (gonflage), car ils pourraient être chauds.
● Si vous avez de la difficulté à respirer après le déploiement des coussins
gonflables SRS, ouvrez une portière ou une glace pour laisser entrer l’air,
ou quittez le véhicule si vous pouvez le faire en toute sécurité. Dès que
possible, nettoyez tous les résidus afin d’éviter les irritatio\
ns cutanées.
● Si les emplacements de stockage des coussins gonflables SRS, tels que
le tampon de volant et les garnitures des montants avant et arrière, sont
endommagés ou fissurés, faites-les remplacer par votre concessionnaire
Toyota.
● Ne placez aucun objet, par exemple un coussin, sur le siège du passager
avant. Cela disperserait le poids du passager, ce qui empêcherait le cap-
teur de le détecter correctement. Cela pourrait empêcher le déploiement
des coussins gonflables SRS du passager avant en cas de collision.

722
RAV4_OM_OM0R012U_(U)
AVERTISSEMENT
■Modification et mise au rebut des composants du système de coussins
gonflables SRS
Ne mettez pas votre véhicule au rebut et n’effectuez aucune des modifica-
tions suivantes sans d’abord consulter votre concessionnaire Toyota. Les
coussins gonflables SRS pourraient fonctionner de manière incorrecte ou
se déployer (gonfler) accidentellement, ce qui serait susceptible d’occasion-
ner des blessures graves, voire mortelles.
● Installation, retrait, démontage et réparation des coussins gonflables SRS
● Réparations, modifications, retrait ou remplacement du volant, du tableau
de bord, de la planche de bord, des sièges ou du capitonnage des sièges,
des montants avant, latéraux et arrière ou des brancards de pavill\
on
● Réparations ou modifications de l’aile avant, du pare-chocs avant ou du
côté de l’habitacle
● Installation d’une protection de calandre (barre safari, barre kangourou,
etc.), de lames de déneigement, de treuils ou d’un porte-bagages de toit
● Modifications du système de suspension du véhicule
● Installation d’appareils électroniques tels qu’un émetteur-récepteur radio
ou un lecteur de CD
● Modifications à votre véhicule pour une personne aux capacités physiques
réduites

723
RAV4_OM_OM0R012U_(U)
Index
What to do if... (Troubleshooting) .................... 724
Alphabetical index ..................... 728
For vehicles with Entune Premium Audio with Naviga-
tion or Entune Audio Plus, refer to the “NAVIGATION
AND MULTIMEDIA SYSTEM OWNER’S MANUAL” for
information regarding the equipment listed below.
• Navigation system
• Audio system
• Rear view monitor system
• Toyota parking assist monitor
• Panoramic view monitor

724What to do if... (Troubleshooting)
RAV4_OM_OM0R012U_(U)
What to do if... (Troubleshooting)
●If you lose your keys or mechanical keys, new genuine keys or mechanical
keys can be made by your Toyota dealer. ( →P. 100)
●Vehicles with smart key system
If you lose your electronic keys, the risk of vehicle theft increases signifi-
cantly. Contact your Toyota dealer immediately. ( →P. 106)
●Is the key battery weak or depleted? (→P. 589)
●Vehicles with smart key system
Is the engine switch in IGNITION ON mode?
When locking the doors, turn the engine switch off. ( →P. 201)
●Vehicles with smart key system
Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on
your person.
●The function may not operate properly due to the condition of the radio
wave. ( →P. 101, 132)
●Is the child-protector lock set?
The rear door cannot be opened from inside the vehicle when the lock is
set. Open the rear door from outside and then unlock the child-protector
lock. (→P. 1 1 0 )
If you have a problem, check the following before contacting
your Toyota dealer.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
The doors cannot be locked or unlocked
The rear door cannot be opened

725What to do if... (Troubleshooting)
RAV4_OM_OM0R012U_(U)
●Is the shift lever in P? (→P. 198)
●Is the battery discharged? ( →P. 662)
●Did you press the engine switch while firmly depressing the brake pedal?
(→P. 200)
●Is the shift lever in P? ( →P. 200)
●Is the electronic key anywhere detectable inside the vehicle? ( →P. 130)
●Is the steering wheel unlocked? (→P. 203)
●Is the electronic key battery weak or depleted?
In this case, the engine can be started in a temporary way. (→P. 661)
●Is the battery discharged? (→P. 662)
●Vehicles without smart key system
Is the engine switch in the “ON” position?
If you cannot release the shift lever by depressing the brake pedal with the
engine switch in the “ON” position: →P. 2 1 1
●Vehicles with smart key system
Is the engine switch in IGNITION ON mode?
If you cannot release the shift lever by depressing the brake pedal with the
engine switch in IGNITION ON mode: →P. 2 1 1
●Vehicles without smart key system
It is locked to prevent theft of the vehicle if the key is removed from the
engine switch. (→P. 199)
●Vehicles with smart key system
It is locked automatically to prevent theft of the vehicle. ( →P. 203)
If you think something is wrong
The engine does not start
(vehicles without smart key system)
The engine does not start
(vehicles with smart key system)
The shift lever cannot be shifted from P even if you depress
the brake pedal
The steering wheel cannot be turned after the engine is
stopped

726What to do if... (Troubleshooting)
RAV4_OM_OM0R012U_(U)
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. (→P. 156)
●The auto power off function will be operated if the vehicle is left in ACCES-
SORY or IGNITION ON mode (the engine is not running) for a period of
time. ( →P. 202)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? ( →P. 620)
●The brake system warning light is on
Is the parking brake released? (→P. 214)
Depending on the situation, other types of warning buzzer may also sound.
( →P. 619, 629)
●Is the message displayed on the multi-information display?
Check the message on the multi-information display. ( →P. 640)
●When a warning light turns on or a warning message is displayed, refer to
P. 619, 629.
The windows do not open or close by operating the power
window switches
The engine switch is turned off automatically
(vehicles with smart key system)
A warning buzzer sounds during driving
A warning buzzer sounds when leaving the vehicle
(vehicles with smart key system)
A warning light turns on or a warning message is displayed

727What to do if... (Troubleshooting)
RAV4_OM_OM0R012U_(U)
●Stop the vehicle in a safe place and replace the flat tire with the spare tire.
(→P. 645)
●Try the procedure for when the vehicle becomes stuck in mud, dirt, or
snow. ( →P. 669)
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck

728Alphabetical index
RAV4_OM_OM0R012U_(U)
Alphabetical index
A/C .................................... 488, 494Air conditioning filter ............. 587
Automatic air conditioning
system ......... ....................... 494
Manual air conditioning
system ......... ....................... 488
Micro dust and pollen filter .... 496
ABS (Anti-lock Brake
System) .................................. 310 Function ................................ 310
Warning light ......................... 619
Air conditioning filter .............. 587
Air conditioning system ............................ 488, 494
Air conditioning filter ............. 587
Automatic air conditioning system ......... ....................... 494
Manual air conditioning system ......... ....................... 488
Micro dust and pollen filter .... 496
Airbags ....................................... 36 Airbag operating conditions .... 44
Airbag precautions for your child .............................. 39
Airbag warning light .............. 619
Correct driving posture ........... 26
Curtain shield airbag operating conditions ............. 44
Curtain shield airbag precautions ........................... 41
Front passenger occupant classification syst em............. 49
General airbag precautions .... 39
Locations of airbags................ 36
Modification and disposal of airbags.............................. 43
Side airbag operating conditions ............................. 44
Side airbag precautions .......... 41
Side and curtain shield
airbags operating
conditions ............................. 44 Side and curtain shield
airbags precautions .............. 41
SRS airbag instructions for Canadian owners ............... 713
SRS airbags ........................... 36
All-wheel drive lock switch..... 299
Anchor brackets ........................ 62
Antenna Radio ............................ 339, 412
Smart key system ................. 130
Anti-lock brake system
(ABS) ...................................... 310 Function ................................ 310
Warning light......................... 619
Approach warning Dynamic radar cruise control ................................ 271
Armrest..................................... 526
Assist grips .............................. 527
Audio input ...................... 334, 397
Audio system ........................... 328 Audio input............................ 334
AUX port/USB port............. 334, 350, 356
Bluetooth
® audio .................. 363
CD player.............................. 340
iPod ...................................... 350
MP3/WMA disc ..................... 340
Optimal use .......................... 336
Portable music player ........... 334
Radio .................................... 338
Steering wheel audio switch ................................. 331
USB memory ........................ 356
AUTO LSD ................................ 310
Automatic air conditioning system Air conditioning filter ............. 587
Automatic air conditioning system .......... ...................... 494
A

729Alphabetical index
RAV4_OM_OM0R012U_(U)
Automatic High Beam ............. 220
Automatic light control system .................................... 218
Automatic transmission.......... 205 If the shift lever cannot be
shifted from P ..................... 211
Paddle shift switches ........... 208
AUX port ........................... 334, 397
Auxiliary box ............................ 511
Back door
Back door.............................. 113
Jam protection function......... 121
Power back door ................... 116
Touchless power back door .................................... 115
Wireless remote control .......... 99
Back-up lights Replacing light bulbs............. 603
Wattage ................................ 680
Battery ...................................... 565 Battery checking ................... 565
If the vehicle battery
is discharged ...................... 662
Preparing and checking before winter....................... 317
Warning light/ message ............................. 633
Bluetooth
®........................ 388, 476
Audio system ................ 380, 443
Hands-free system (for cellular phone) ..... 383, 445
Registering a Bluetooth
® device....... 369, 436
Selecting a Bluetooth®
device ......................... 371, 438
Wireless communication ........... 363, 431
Bluetooth
® audio ............. 380, 443 Bluetooth
® phone
(audio system)....................... 363
Deleting the call history ........ 377
Making a call......................... 383
Managing speed dials........... 376
Managing the contacts ......... 378
Phone settings ...................... 370
Receiving a call .................... 385
Speaking on the phone......... 383
Bluetooth
® phone (Entune Audio)
Deleting the call history ........ 462
Making a call......................... 447
Managing the contacts ......... 466
Message function ................. 454
Phone settings ...................... 460
Receiving a call .................... 450
Speaking on the phone......... 451
Bottle holders .......................... 511
Brake Fluid ...................................... 564
Parking brake ....................... 214
Warning light/message..................... 619, 630
Brake assist ............................. 310
Break-in tips............................. 167
Brightness control Instrument panel light
control .................................. 86
BSM (Blind Spot Monitor) ....... 300 Blind Spot Monitor
function............................... 304
Rear Cross Traffic Alert function............................... 307
Care .................................. 540, 543 Aluminum wheels ................. 541
Exterior ................................. 540
Interior .................................. 543
Radar sensor ................ 237, 303
Seat belts.............................. 544
B
C

730Alphabetical index
RAV4_OM_OM0R012U_(U)
Cargo capacity ......................... 672
Cargo hooks............................. 512
Catch protection function ....... 157
CD player .......................... 340, 413
Chains....................................... 317
Child restraint system ............... 57Booster seats, definition ......... 57
Booster seats, installation ....... 67
Convertible seats, definition ............................... 57
Convertible seats,
installation ............................ 64
Front passenger occupant classification syst em............. 49
Infant seats, definition ............. 57
Infant seats, installation .......... 64
Installing CRS with LATCH system ..................... 62
Installing CRS with seat belts ...................................... 64
Installing CRS with top tether strap ........................... 69
Child safety ................................ 56
Airbag precautions .................. 39
Back door precautions .......... 123
Battery precautions ....... 567, 665
Child restraint system ............. 57
How your child should wear the seat belt ................. 32
Installing child restraints ......... 61
Moon roof precautions .......... 163
Power window lock switch .... 156
Power window
precautions ......................... 159
Rear door child-protectors .... 110
Removed key battery precautions ......................... 591
Seat belt extender precautions ........................... 35
Seat belt precautions .............. 33
Seat heater precautions........ 503 Child-protectors ...................... 110
Cleaning ........................... 540, 543
Aluminum wheels ................. 541
Exterior ................................. 540
Interior .................................. 543
Radar sensor ................ 237, 303
Seat belts.............................. 544
Clock......................................... 402
Coat hooks ............................... 526
Compass .................................. 535
Condenser................................ 564
Console box ............................. 509
Coolant ..................................... 562 Capacity................................ 676
Checking............................... 562
Preparing and checking before winter ...................... 317
Cooling system Engine overheating............... 666
Cruise control
Cruise control ....................... 276
Dynamic radar cruise control ................................ 264
Warning message................. 634
Cup holders ............................. 510
Curtain shield airbags............... 36
Customizable features ............ 697
Daytime running light system.................................... 217
Defogger Outside rear view
mirrors ........................ 490, 497
Rear window ................. 490, 497
Windshield ............................ 489
Differential................................ 677
Dimension ................................ 672
Dinghy towing.......................... 197
D
