remove seats TOYOTA RAV4 2018 Owners Manual (in English)

551-1. For safe use
RAV4_OM_OM0R012U_(U)
1
For safety and security
WARNING
■Front passenger occupant classi fication system precautions
● Do not recline the front passenger seatback so far that it touches a rear
seat. This may cause the “AIR BAG OFF” indicator light to be illuminated,
which indicates that the SRS airbags for the front passenger will not acti-
vate in the event of a severe accident. If the seatback touches the rear
seat, return the seatback to a position where it does not touch the rear
seat. Keep the front passenger seatback as upright as possible when the
vehicle is moving. Reclining the seatback excessively may lessen the
effectiveness of the seat belt system.
● If an adult sits in the front passenger seat, the “AIR BAG ON” indicator
light is illuminated. If the “AIR BAG OFF” indicator is illuminated, ask the
passenger to sit up straight, well back in the seat, feet on the floor, and
with the seat belt worn correctly. If the “AIR BAG OFF” indicator still
remains illuminated, either ask the passenger to move to the rear seat, or
if that is not possible, move the front passenger seat fully rearward.
● When it is unavoidable to install a forward-facing child restraint system on
the front passenger seat, install the child restraint system on the front pas-
senger seat in the proper order. ( →P. 61)
● Do not modify or remove the front seats.
● Do not kick the front passenger seat or subject it to severe impact. Other-
wise, the SRS warning light may come on to indicate a malfunction of the
front passenger occupant classification system. In this case, contact your
Toyota dealer immediately.
● Child restraint systems installed on the rear seat should not contact the
front seatbacks.
● Do not use a seat accessory, such as a cushion and seat cover, that cov-
ers the seat cushion surface.
● Do not modify or replace the upholstery of the front seat.

148
RAV4_OM_OM0R012U_(U)
3-3. Adjusting the seats
■Adjusting the height of the head restraints
■ Adjusting the rear cente r seat head restraint
Always raise the head restraint one level from the stowed position when
using. Make sure that the head restraints are
adjusted so that the center of the head
restraint is closest to the top of your ears.
WARNING
■ Head restraint precautions
Observe the following precautions regarding the head restraints. Failure to
do so may result in death or serious injury.
● Use the head restraints designed for each respective seat.
● Adjust the head restraints to the correct position at all times.
● After adjusting the head restraints, push down on them and make sure
they are locked in position.
● Do not drive with the head restraints removed.

RAV4_OM_OM0R012U_(U)
5457-1. Maintenance and care
7
Maintenance and care
NOTICE
■Cleaning detergents
● Do not use the following types of detergent, as they may discolor the vehi-
cle interior or cause streaks or damage to painted surfaces:
• Non-seat portions: Organic substances such as benzene or gasoline,
alkaline or acidic solutions, dye, and bleach
• Seats: Alkaline or acidic solutions, such as thinner, benzene, and alcohol
● Do not use polish wax or polish cleaner. The instrument panel’s or other
interior part’s painted surface may be damaged.
■ Preventing damage to leather surfaces
Observe the following precautions to avoid damage to and deterioration of
leather surfaces:
● Remove any dust or dirt from leather surfaces immediately.
● Do not expose the vehicle to direct sunlight for extended periods of time.
Park the vehicle in the shade, especially during summer.
● Do not place items made of vinyl, plastic, or containing wax on the uphol-
stery, as they may stick to the leather surface if the vehicle interior heats
up significantly.
■ Water on the floor
Do not wash the vehicle floor with water.
Vehicle systems such as the audio system may be damaged if water comes
into contact with electrical components such as the audio system above or
under the floor of the vehicle. Water may also cause the body to rust.
■ When cleaning the inside of th e windshield (vehicles with Toyota
Safety Sense P)
Do not allow glass cleaner to contact the lens. Also, do not touch the lens.
( →P. 237)
■ Cleaning the inside of the rear window
● Do not use glass cleaner to clean the rear window, as this may cause
damage to the rear window defogger heater wires. Use a cloth dampened
with lukewarm water to gently wipe the window clean. Wipe the window in
strokes running parallel to the heater wires.
● Be careful not to scratch or damage the heater wires.

730Alphabetical index
RAV4_OM_OM0R012U_(U)
Cargo capacity ......................... 672
Cargo hooks............................. 512
Catch protection function ....... 157
CD player .......................... 340, 413
Chains....................................... 317
Child restraint system ............... 57Booster seats, definition ......... 57
Booster seats, installation ....... 67
Convertible seats, definition ............................... 57
Convertible seats,
installation ............................ 64
Front passenger occupant classification syst em............. 49
Infant seats, definition ............. 57
Infant seats, installation .......... 64
Installing CRS with LATCH system ..................... 62
Installing CRS with seat belts ...................................... 64
Installing CRS with top tether strap ........................... 69
Child safety ................................ 56
Airbag precautions .................. 39
Back door precautions .......... 123
Battery precautions ....... 567, 665
Child restraint system ............. 57
How your child should wear the seat belt ................. 32
Installing child restraints ......... 61
Moon roof precautions .......... 163
Power window lock switch .... 156
Power window
precautions ......................... 159
Rear door child-protectors .... 110
Removed key battery precautions ......................... 591
Seat belt extender precautions ........................... 35
Seat belt precautions .............. 33
Seat heater precautions........ 503 Child-protectors ...................... 110
Cleaning ........................... 540, 543
Aluminum wheels ................. 541
Exterior ................................. 540
Interior .................................. 543
Radar sensor ................ 237, 303
Seat belts.............................. 544
Clock......................................... 402
Coat hooks ............................... 526
Compass .................................. 535
Condenser................................ 564
Console box ............................. 509
Coolant ..................................... 562 Capacity................................ 676
Checking............................... 562
Preparing and checking before winter ...................... 317
Cooling system Engine overheating............... 666
Cruise control
Cruise control ....................... 276
Dynamic radar cruise control ................................ 264
Warning message................. 634
Cup holders ............................. 510
Curtain shield airbags............... 36
Customizable features ............ 697
Daytime running light system.................................... 217
Defogger Outside rear view
mirrors ........................ 490, 497
Rear window ................. 490, 497
Windshield ............................ 489
Differential................................ 677
Dimension ................................ 672
Dinghy towing.......................... 197
D
