stop start TOYOTA RAV4 2021 Owners Manual (in English)

3TABLE OF CONTENTS
1
2
3
4
5
6
7
8
9
10
Trailer towing ................181
Dinghy towing ............... 193
4-2. Driving procedures Engine (ignition) switch (vehi-cles without smart key sys-
tem) ............................. 195
Engine (ignition) switch (vehi- cles with smart key system).................................... 196
Automatic transmission . 201
Turn signal lever ........... 204
Parking brake ................ 205
Brake Hold .................... 208
4-3. Operating the lights and wipers
Headlight switch ............ 211
AHB (Automatic High Beam) .................................... 214
Fog light switch ............. 217
Windshield wipers and washer......................... 218
Rear window wiper and washer......................... 221
4-4. Refueling Opening the fuel tank cap.................................... 223
4-5. Using the driving support
systems
Toyota Safety Sense 2.0 226
PCS (Pre-Collision System) .................................... 232
LTA (Lane Tracing Assist) .................................... 240
RSA (Road Sign Assist) 250
Dynamic radar cruise control with full-speed range ... 253BSM (Blind Spot Monitor)
.................................... 264
Intuitive parking assist ... 273
PKSB (Parking Support Brake) .......................... 281
Parking Support Brake func- tion (static objects) ...... 286
Parking Support Brake func- tion (rear-crossing vehicles).................................... 292
Rear view monitor system .................................... 296
Toyota parking assist monitor .................................... 304
Panoramic view monitor 317
Stop & Start system....... 349
Driving mode s elect switch
.................................... 355
Multi-terrain Select (AWD vehicles) ...................... 357
Snow mode switch (AWD vehicles) ...................... 361
Downhill assist control sys- tem .............................. 362
Driving assist systems ... 364
4-6. Driving tips Winter driving tips .......... 371
Utility vehicle precautions ....

................................ 374
5-1. Basic function Buttons overview ........... 379
Menu screen.................. 381
Status icon..................... 382
“Setup” screen ............... 384
5Audio

6TABLE OF CONTENTS
8-1. Essential informationEmergency flashers ...... 628
If your vehicle has to be stopped in an emergency.................................... 628
If the vehicle is trapped in ris- ing water...................... 629
8-2. Steps to take in an emer- gency
If your vehicle needs to be towed........................... 631
If you think something is wrong .......................... 636
Fuel pump shut off system .................................... 637
If a warning light turns on or a warning buzzer sounds 638
If a warning message is dis- played.......................... 649
If you have a flat tire...... 653
If the engine will not start 662
If you lose your keys ..... 664
If the electronic key does not operate properly (vehicles
with smart key system) 664
If the vehicle battery is dis- charged ....................... 666
If your vehicle overheats 670
If the vehicle becomes stuck .................................... 6729-1. Specifications
Maintenance data (fuel, oil level, etc.) .................... 676
Fuel information............. 688
Tire information ............. 690
9-2. Customization Customizable features... 700
9-3. Initialization Items to initialize ............ 712
10-1.For owners Reporting safet y defects for
U.S. owners ................. 714
Seat belt instructions for Canadian owners (in
French) ........................ 715
SRS airbag instructions for Canadian owners (in
French) ........................ 716
What to do if... (Trouble- shooting) ..................... 726
Alphabetical Index ........ 729
8When trouble arises9Vehicle specifications
10For owners
Index

17Pictorial index
■Instrument panel
Engine switch .............................................................P.195, 196
Starting the engine/changing the modes .............P.195, 196, 199
Emergency stop of the engin e .............................................P.628
When the engine will not start ................................. .............P.662
Warning messages
*1............................................................P.6 49
Shift lever.................................................... ........................P.201
Changing the shift position.................................... ...............P.202
Precautions against towing ..................................................P.631
When the shift lever does not move............................. ........P.202
Meters ......................................................... ....................P.82, 85
Reading the meters/adjusting the instrument panel light ............................................................... ..............P.82, 84, 85, 88
Warning lights/indicator lights ................................ ................P.76
When the warning lights come on ................................ ........P.638
Multi-information display . ...................................................P.89
Display ........................................................ ...........................P.89
A
B
C
D

21Pictorial index
VSC OFF switch .................................................................P.365
Front seat heater switches
*...............................................P.530
Front seat heater/ventilator switches
*.............................P.531
Stop & Start cancel switch
*...............................................P.350
Parking brake switch ........................................... ..............P.205
Applying/releasing............................................. ...................P.205
Precautions against winter season .............................. ........P.372
Warning buzzer/message ... .........................................P.644, 649
Brake hold switch .............................................. ................P.208
Driving mode select switch ..................................... ..........P.355
Multi-terrain Select switch
*...............................................P.357
SNOW mode switch
*..........................................................P.361
“DAC” switch
*............................................................... .....P.362
*: If equipped
A
B
C
D
E
F
G
H
I
J

261-1. For safe use
1-1.For safe use
Use only floor mats designed
specifically for vehicles of the
same model and model year as
your vehicle. Fix them securely
in place onto the carpet.
1 Insert the retaining hooks
(clips) into the floor mat eye-
lets.
2 Turn the upper knob of each
retaining hook (clip) to secure
the floor mats in place.
Always align the marks . The shape of the retaining hooks
(clips) may differ from that shown in
the illustration.
Before driving
Observe the following
before starting off in the
vehicle to ensure safety of
driving.
Installing floor mats
A
WARNING
Observe the following precau-
tions.
Failure to do so may cause the
driver’s floor mat to slip, possibly
interfering with t
he pedals while
driving. An unexpectedly high
speed may result or it may
become difficult to stop the vehi-
cle. This could lead to an acci-
dent, resulting in death or serious
injury.
■When installing the driver’s
floor mat
●Do not use floor mats designed
for other models or different
model year vehicles, even if
they are Toyota Genuine floor
mats.
●Only use floor mats designed
for the driver’s seat.
●Always install the floor mat
securely using the retaining
hooks (clips) provided.
●Do not use two or more floor
mats on top of each other.
●Do not place the floor mat bot-
tom-side up or upside-down.

281-1. For safe use
Make sure that all occupants are
wearing their seat belts before
driving the vehicle. (P.30)
Use a child restraint system
appropriate for the child until the
child becomes large enough to properly wear the vehicle’s seat
belt. (
P.50)
Make sure that you can see
backward clearly by adjusting
the inside rear view mirror (if
equipped), Digital Rear-view
Mirror (if equipped) and outside
rear view mirrors properly.
( P.145, 147, 156)
WARNING
Observe the following precau-
tions.
Failure to do so m ay result in
death or serious injury.
●Do not adjust the position of the
driver’s seat while driving.
Doing so could cause the driver
to lose control of the vehicle.
●D o n ot pla ce a cu sh ion b etw ee n
the driver or passenger and the
seatback. A cushion may pre-
vent correct pos ture from being
achieved, and reduce the effec-
tiveness of the seat belt and
head restraint.
●Do not place anything under the
front seats.
Objects placed u nder the front
seats may become jammed in
the seat tracks and stop the
seat from locking in place. This
may lead to an accident and the
adjustment mechanism may
also be damaged.
●Always observe the legal speed
limit when driving on public
roads.
●When driving over long dis-
tances, take regular breaks
before you start to feel tired.
Also, if you feel tired or sleepy
while driving, do not force your-
self to continue driving and take
a break immediately.
Correct use of the seat
belts
Adjusting the mirrors

731-4. Theft deterrent system
1
For safety and security
*: If equipped
■Items to check before lock-
ing the vehicle
To prevent unexpected trigger-
ing of the alarm and vehicle
theft, make sure of the following:
 Nobody is in the vehicle.
 The side windows and moon
roof (if equipped) or pan- oramic moon roof (if
equipped) are closed before
the alarm is set.
 No valuables or other per-
sonal items are left in the
vehicle.
■Setting
Close the doors and hood, and
lock all the doors. The system
will be set automatically after 30
seconds.
The security indicator changes from
being on to flashing when the sys-
tem is set.
■Canceling or stopping
Do one of the following to deac-
tivate or stop the alarm:
 Unlock the doors.
 Turn the engine switch to
ACC or ON, or start the
engine. (The alarm will be
deactivated or stopped after a
few seconds.)
■System maintenance
The vehicle has a maintenance-free
type alarm system.
■Triggering of the alarm
The alarm may be triggered in the
following situations:
Alarm*
The alarm uses light and
sound to give an alert when
an intrusion is detected.
The alarm is triggered in the
following situations when
the alarm is set:
 Vehicles without smart key
system: A locked door is
unlocked or opened in any
way other than using the
wireless remote control or
key. (The doors will lock
again automatically.)
Vehicles with smart key
system: A locked door is
unlocked or opened in any
way other than using the
entry function, wireless
remote control or mechani-
cal key. (The doors will lock
again automatically.)
The hood is opened.
Setting/canceling/stop-
ping the alarm system

782-1. Instrument cluster
*1: These lights turn on when the
engine switch is turned to ON to
(Yellow)
Brake system warn-
ing light
*1 (  P.638)
Charging system
warning light
*1
(  P.638)
High coolant tempera-
ture warning light
*2
(  P.639)
Low engine oil pres-
sure warning light
*2
(  P.639)
(U.S.A.)
Malfunction indicator
lamp
*1 ( P.639)
(Canada)
Malfunction indicator
lamp
*1 ( P.639)
SRS warning light
*1
(  P.639)
(U.S.A.)
ABS warning light*1
(  P.640)
(Canada)
ABS warning light*1
(  P.640)
(Red/yellow)
Electric power steer-
ing system warning
light
*1 ( P.640)
(Flashes or
illuminates)
PCS warning light*1
(  P.640)
(Orange)
LTA indicator
( P.641)
(Flashes)
Stop & Start cancel
indicator
*1 (if
equipped) (P.641)
(Flashes)
Intuitive parking assist
OFF indicator
*3 (if
equipped) ( P.641)
(Flashes)
PKSB OFF indica-
tor
*1 (if equipped)
(  P.642)
(Flashes)
RCTA OFF indica-
tor
*1 (if equipped)
(  P.642)
Slip indicator light
*1
(  P.643)
Brake Override Sys-
tem/Drive-Start Con-
trol/PKSB (if
equipped) warning
light
*2 (  P.643)
(Flashes)
Brake hold operated
indicator
*1 ( P.643)
(U.S.A.)
(Flashes)
Parking brake indica-
tor ( P.644)
(Canada)
(Flashes)
Parking brake indica-
tor ( P.644)
Tire pressure warning
light
*1 (if equipped)
(  P.644)
Low fuel level warn-
ing light ( P.644)
Driver’s and front pas-
senger’s seat belt
reminder light
(  P.645)
Rear passengers’ seat
belt reminder lights (if
equipped) ( P.645)

802-1. Instrument cluster
*1: This light illuminates on the multi-information display with a
message.
*2: Depending on the operating con-ditions of the system, the color
and state (illuminat ed/blinking) of
the indicator change.
*3: The light comes on when the system is turned off.
*4: Intuitive parking assist OFF indi-cator turns on wh en the engine
switch is turned t o ON while the
Intuitive parking assist function is
on. It will turn off after a few sec-
onds.
*5: These lights tu rn on when the
engine switch is turned to ON to
indicate that a system check is
being performed. They will turn
off after the engine is started, or
after a few seconds. There may
be a malfunction in a system if
the lights do not turn on, or turn
off. Have the vehicle inspected
(Flashes)
Slip indicator light*5
(  P.365)
VSC OFF indicator
*3, 5
(  P.366)
PCS warning light
*3, 5
(  P.234)
BSM outside rear view
mirror indicators
*5, 6 ( i f
equipped) ( P.265)
BSM indicator (if
equipped) ( P.265)
RCTA OFF indica-
tor
*3, 5 (if equipped)
(  P.265)
Stop & Start indica-
tor
*5 (if equipped)
(  P.349)
Stop & Start cancel
indicator
*3, 5 (if
equipped) ( P.350)
Brake hold standby
indicator
*5 (  P.208)
Brake hold operated
indicator
*5 (  P.208)
Security indicator
(  P.70, 73)
Low outside tempera-
ture indicator
*7
(  P.83, 87)
Eco Driving Indicator
Light
*5 (  P.92)
(U.S.A.)
Parking brake indica-
tor ( P.205)
(Canada)
Parking brake indica-
tor ( P.205)
Eco drive mode indi-
cator (P.355)
Sport mode indicator
( P.355)
Mud & sand mode
indicator (if equipped)
(  P.358)
Rock & dirt mode indi-
cator (if equipped)
(  P.358)
Snow mode indicator
(if equipped)
(  P.361)
Downhill assist control
system indicator
*5 (if
equipped) ( P.362)
“AIR BAG ON/OFF”
indicator
*5, 8 (  P.43)

912-1. Instrument cluster
2
Vehicle status information and indicators
Select to display fuel consump-
tion data in various forms.
■Speedometer display/Dis-
tance to empty (4.2-inch
display)
Speedometer display
Displays the vehicle speed.
Distance to empty
Displays the driving range with remaining fuel. (
P.92)
■Fuel Economy
Following information is dis-
played.
Distance to empty
Displays the driving range with
remaining fuel. ( P.92)
Current fuel economy
Displays the instantaneous current
fuel Economy.
Average fuel economy
Displays the average fuel economy
since the function was reset or the
average fuel economy after starting
or refueling.
*1, 2,3
The average fuel economy selected
by “Fuel Economy” on the
screen is displayed. ( P.94)
*1: Use the displayed fuel consump-
tion as a reference only.
*2: Average fuel economy since the function was res et can be reset
by pressing and holding .
*3: Average fuel economy after starting is reset each time the
engine stops.
IconDisplay
Driving information dis-
play ( P.91)
Driving support system
information display
( P.93)
Audio system-linked dis-
play (if equipped)
( P.93)
Vehicle information dis-
play ( P.93)
Settings display ( P.94)
Warning message dis-
play ( P.98)
Driving information dis-
play
A
B
A
B
C
