bluetooth TOYOTA RAV4 2022 Owners Manual

4TABLE OF CONTENTS
5-2. Basic information before operation
Initial screen .................. 377
Touch screen ................ 378
Home screen................. 380
Entering letters and num- bers/list screen operation
.................................... 381
Screen adjustment ........ 384
Linking multi-information dis- play and the system .... 385
5-3. Connectivity settings Registering/Connecting a Bluetooth
® device ....... 386
Setting Bluetooth
® details
.................................... 390
Wi-Fi
® Hotspot .............. 398
5-4. Apple CarPlay/Android Auto
Apple CarPlay
®/Android
Auto™ ......................... 403
5-5. Other settings General settings ............ 410
Voice settings................ 414
Vehicle settings ............. 415
5-6. Using the audio/visual sys- tem
Quick reference............. 416
Some basics ................. 417
5-7. Radio operation AM/FM/SiriusXM (SXM) radio.................................... 421
5-8. Media operation USB memory................. 428
iPod/iPhone (Apple CarPlay) .................................... 430Android Auto..................
433
Bluetooth
® audio ........... 434
5-9. Audio/visual remote con- trols
Steering switches .......... 438
5-10.Audio settings Setup ............................. 440
5-11.Tips for operating the
audio/visual system
Operating information .... 442
5-12.Voice command system operation
Voice command system 454
Command list ................ 457
5-13.Mobile Assistant operation Mobile Assistant ............ 461
5-14.Phone operation (Hands- free system for cellular
phones)
Quick reference ............. 463
Some basics .................. 464
Placing a call using the Bluetooth
® hands-free sys-
tem .............................. 468
Receiving a call using the Bluetooth
®hands-free sys-
tem .............................. 471
Talking on the Bluetooth
®
hands-free system ....... 472
Bluetooth
® phone message
function ........................ 474
5-15.Phone settings Setup ............................. 479
5-16.What to do if... (Bluetooth
®)
Troubleshooting............. 489

681-3. Emergency assistance
(“SOS”)
Connects drivers to response-cen-
ter support. (
P.69)
Enhanced Roadside Assis-
tance
Provides drivers various on-road
assistance. ( 
P.70)
After you have signed the
Telematics Subscription Ser-
vice Agreement and are
enrolled, you can begin receiv-
ing services.
A variety of subscription terms
are available for purchase. Con-
tact your Toyota dealer, call the
following appropriate Customer
Experience Center or push the
“SOS” button in your vehicle for
further subscription details.
The United States
1-800-331-4331
Canada
1-888-869-6828
Puerto Rico
1-877-855-8377
■Safety Connect Services Infor-
mation
●Phone calls using the vehicle’s
Bluetooth® technology will not be
possible when Safety Connect is
active and in use.
●Safety Connect is available begin-
ning Fall 2009 on select Toyota
models (in the contiguous United
States only). Contact with the
Safety Connect response center is dependent upon
the telematics
device being in operative condi-
tion, cellular connection availabil-
ity, and GPS satellite signal
reception, which can limit the abil-
ity to reach the response center or
receive emergency service sup-
port. Enrollment and Telematics
Subscription Service Agreement
are required. A variety of subscrip-
tion terms are available; charges
vary by subscription term selected
and location.
●Automatic Collision Notification,
Emergency Assistance and Stolen
Vehicle Location are available in
the United States, including
Hawaii and Alaska , Puerto Rico
and Canada, and Enhanced
Roadside Assistance are avail-
able in the United States, Puerto
Rico and Canada.
●Automatic Collision Notification,
Emergency Assistance, Stolen
Vehicle and Enhanced Road
Assistance are not available in the
U.S. Virgin Islands.
For vehicles first sold in the U.S.
Virgin Islands, no Safety Connect
services will function in or outside
the U.S. Virgin Islands.
●Safety Connect services are not
subject to section 255 of the Tele-
communications Act and the
device is not TTY compatible.
■Languages
The Safety Connect response cen-
ter will offer suppor t in multiple lan-
guages. The Safety Connect system
will offer voice prompts in English,
Spanish, and French. Please indi-
cate your language of choice when
enrolling.
■When contacting the response
center
You may be unable to contact the
response center if the network is
busy.
Subscription

369
5
5
Audio
Audio
5-1. Basic functionButtons overview......... 371
Menu screen ............... 373
Status icon .................. 374
“Setup” screen ............ 376
5-2. Basic information before operation
Initial screen ................ 377
Touch screen .............. 378
Home screen............... 380
Entering letters and num- bers/list screen operation.................................. 381
Screen adjustment ...... 384
Linking multi-information display and the system.................................. 385
5-3. Connectivity settings Registering/Connecting a Bluetooth
® device ..... 386
Setting Bluetooth
® details
.................................. 390
Wi-Fi
® Hotspot ............ 398
5-4. Apple CarPlay/Android Auto
Apple CarPlay
®/Android
Auto™ ....................... 403
5-5. Other settings General settings .......... 410
Voice settings.............. 414
Vehicle settings ........... 4155-6. Using the audio/visual
system
Quick reference ........... 416
Some basics................ 417
5-7. Radio operation AM/FM/SiriusXM (SXM) radio .......................... 421
5-8. Media operation USB memory ............... 428
iPod/iPhone (Apple Car- Play) .......................... 430
Android Auto ............... 433
Bluetooth
® audio ......... 434
5-9. Audio/visual remote con- trols
Steering switches ........ 438
5-10.Audio settings Setup ........................... 440
5-11.Tips for operating the audio/visual system
Operating information.. 442
5-12.Voice command system operation
Voice comm and system
.................................. 454
Command list .............. 457
5-13.Mobile Assistant opera- tion
Mobile Assistant .......... 461

370
5-14.Phone operation (Hands-free system for cellular
phones)
Quick reference........... 463
Some basics ............... 464
Placing a call using the Bluetooth
® hands-free sys-
tem ............................ 468
Receiving a ca ll using the
Bluetooth
®hands-free sys-
tem ............................ 471
Talking on the Bluetooth
®
hands-free system..... 472
Bluetooth
® phone message
function...................... 474
5-15.Phone settings Setup........................... 479
5-16.What to do if... (Bluetooth
®)
Troubleshooting .......... 489
5-17.Connected Services over- view
Connected Services .... 493
Type A: Function achieved by using a smartphone or
DCM .......................... 494
Type B: Function achieved by using DCM and the sys-
tem ............................ 496
Type C: Function achieved by using DCM............ 497Type D: Function achieved
by using DCM and a
smartphone ............... 500
5-18.Connected Services oper- ation
Toyota Apps ................ 502
5-19.Setup Toyota Apps settings... 506

3715-1. Basic function
5
Audio
5-1.Basic function
*: Vehicles with Audio onlyFor details about Audio Plus or Premium Audio, refer to “Navigation and
Multimedia System Owner’s Manual”.
By touching the screen with y our finger, you can control the
selected functions. ( P.378, 379)
Press to seek up or down for a radio station or to access a
desired track/file. ( P.421, 428, 430, 434)
Press to access the Bluetooth
® hands-free system. ( P.463)
• When an Apple CarPlay connecti on is established, press to display the
Phone application screen.
*1
Press to display the Toyota Apps screen.*1, 2 (  P.502)
Turn to change the radio station or skip to the next or previou s
track/file. ( P.421, 428, 430, 434)
Press to turn the audio/visual system on and off, and turn it t o
adjust the volume. Press and hold to restart the system. ( P.377,
417)
Buttons overview*
Operations of each part
A
B
C
D
E
F

3745-1. Basic function
Indicate during data commu-
nication performed via Data
Communication Module
(DCM)
*1
The reception level of Data
Communication Module
(DCM) display
*1 ( P.374)
The reception level of the
connected phone display
( P.374)
Remaining battery charge
display ( P.375)
Bluetooth
® phone connection
condition display ( P.375)
Wi-Fi
® connection condition
display
*1, 2 (  P.398)
*1: Vehicles equipped with DCM
*2: This function is not made avail-
able in some countries or areas.
●The number of status icons that
can be displayed differs depend-
ing on the displayed screen.
The level of reception does not
always correspond with the level
displayed on the cellular phone.
The level of reception may not
be displayed depending on the
phone you have.
When the cellular phone is out
of the service area or in a place
inaccessible by radio waves,
/ is displayed.
“Rm” is displayed when receiv-
ing in a roaming area. While
roaming, display “Rm” top-left
on the icon.
The receiving area may not be
displayed depending on the type
of Bluetooth
® phone you have.
While connected with cellular
phone
Status icon
Status icons are displayed
at the top of the screen.
Status icon explanation
A
B
C
D
E
F
5HFHSWLRQOHYHOGLVSOD\
Reception LevelIndicators
Poor
Excellent

3755-1. Basic function
5
Audio
While using Data Communi-
cation Module (DCM)
While using Wi-Fi®Hotspot
●When Wi-Fi® Hotspot is off, no
item is displayed.
The amount displayed does not
always correspond with the
amount displayed on the
Bluetooth
® device.
The amount of battery charge
left may not be displayed
depending on the type of the
Bluetooth
® device connected.
This system does not have a
charging function. An antenna for the Bluetooth
®
connection is built into the
instrument panel.
The condition of the Bluetooth
®
connection may deteriorate and
the system may not function
when a Bluetooth
® phone is
used in the following conditions
and/or places:
The cellular phone is obstructed
by certain objects (such as
when it is behind the seat or in
the glove box or console box).
The cellular phone is touching or
is covered with metal materials.
Leave the Bluetooth
® phone in a
place where the condition of the
Bluetooth
® connection is good.
Reception LevelIndicators
Poor
Excellent
Reception LevelIndicators
No connection
Connected
Remaining battery charge
display
Remaining chargeIndicators
Empty
Full
Bluetooth® connection
condition display
IndicatorsConditions
(Blue)
Indicates that the con-
dition of the
Bluetooth
® connection
is good.
(Gray)
While in this condition,
sound quality during
phone calls may dete-
riorate.
Indicates that the cel-
lular phone is not con-
nected via Bluetooth
®.

3765-1. Basic function
Press the “MENU” button, then
select “Setup” to display the
“Setup” screen. The items
shown on the “Setup” screen
can be set.Select to change the selected
language, operation sound
settings, etc. ( P.410)
Select to set Bluetooth
®
device and Bluetooth
® sys-
tem settings. ( P.390)
Select to set audio settings.
( P.440)
Select to set the phone
sound, contacts, message
settings, etc. ( P.479)
Select to set the voice set-
tings. ( P.414) Select to set vehicle informa-
tion. (
P.415)
Select to set Wi-Fi
® connec-
tion settings.
*1, 2 (  P.399)
Select to set Toyota Apps
settings.
*2 (  P.506)
*1: Vehicles equipped with DCM
*2: This function is not made avail-
able in some countries or areas.
“Setup” screen
“Setup” screen
A
B
C
D
E
F
G
H

3865-3. Connectivity settings
5-3.Connectivity settings
■Registering from the sys-
tem
1 Turn the Bluetooth
® connec-
tion setting of your cellular
phone on.
 This function is not available
when Bluetooth
® connection
setting of your cellular phone
is set to off.
2 Press the “MENU” button.
3 Select “Phone”.
 Operations up to this point
can also be performed by
pressing the “PHONE” button
on the instrument panel.
4 Select “Yes” to register a
phone.
Registering/Connect-
ing a Bluetooth®
device
To use the hands-free sys-
tem, it is necessary to regis-
ter a Bluetooth
® phone with
the system.
Once the phone has been
registered, it is possible to
use the hands-free system.
This operation cannot be
performed while driving.
When an Apple CarPlay
connection is established,
Bluetooth
® functions of the
system will become unavail-
able and any connected
Bluetooth
® devices will be
disconnected.
When connecting to
Android Auto, a Bluetooth
®
connection will be made
automatically.
When an Android Auto con-
nection is established,
some Bluetooth
® functions
other than hands-free sys-
tem cannot be used.
Registering a Bluetooth®
phone for the first time

3875-3. Connectivity settings
5
Audio
5Select the desired Bluetooth®
device.
 If the desired Bluetooth
®
phone is not on the list, select
“If you cannot find...” and fol-
low the guidance on the
screen. ( P.388)
6 Register the Bluetooth
®
device using your Bluetooth
®
device.
 For details about operating
the Bluetooth
® device, see
the manual that comes with it.
 A PIN code is not required for
SSP (Secure Simple Pairing)
compatible Bluetooth
®
devices. Depending on the
type of Bluetooth
® device
being connected, a message
confirming registration may
be displayed on the
Bluetooth
® device’s screen. Respond and operate the
Bluetooth
® device according
to the confirmation message.
7 Check that the following
screen is displayed, indicat-
ing pairing was successful (a
Bluetooth
® link has been
established but registration is
not yet complete).
 The system is connecting to
the registered device.
 At this stage, the Bluetooth
®
functions are not yet avail-
able.
8 Check that “Connected” is
displayed and registration is
complete.
 If an error message is dis-
played, follow the guidance
on the screen to try again.
●If a cellular phone does not oper-
ate properly after being con-
