822-1. Instrument cluster
The units used on the meter and display may differ depending on the target
region.
Tachometer
Displays the engine speed in revolutions per minute
Outside temperature ( P.83)
Clock ( P.84)
Multi-information display
Presents the driver with a variety of driving-related data ( P.89)
Displays warning messages if a malfunction occurs (P.633)
Speedometer
Displays the vehicle speed
Fuel gauge
Displays the quantity of fu el remaining in the tank
Odometer and trip meter
Odometer:
Displays the total distance th at the vehicle has been driven
Trip meter:
Displays the distance the vehicle has been driven since the meter was last
Gauges and meters (w ith 4.2-inch display)
The meters display various drive information.
Meter display
A
B
C
D
E
F
G

852-1. Instrument cluster
2
Vehicle status information and indicators
The display of the speedometer can be selected from two types,
analog or digital. (P.94)
Analog speedometer
The units used on the meter and display may differ depending on the target
region.
Tachometer
Displays the engine speed in revolutions per minute
Speedometer
Displays the vehicle speed
Clock ( P.88)
Fuel gauge
Displays the quantity of fu el remaining in the tank
Engine coolant temperature gauge
Displays the engine coolant temperature
Odometer and trip meter
Odometer:
Displays the total distance th at the vehicle has been driven
Trip meter:
Gauges and meters (with 7-inch display)
The meters display various drive information.
Meter display
A
B
C
D
E
F

862-1. Instrument cluster
Displays the distance the vehicle has been driven since the meter was last
reset. Trip meters “A” and “B” c an be used to record and display different
distances independently.
Outside temperature ( P.87)
Multi-information display
Presents the driver with a variety of driving-related data ( P.89)
Displays warning messages if a malfunction occurs (P.633)
Shift position and shift range indicator
Displays the selected shift posit ion or selected shift range (P.197)
Digital speedometer
The units used on the meter and display may differ depending on the target
region.
Tachometer
Displays the engine speed in revolutions per minute
Speedometer
Displays the vehicle speed
Clock ( P.88)
Fuel gauge
Displays the quantity of fu el remaining in the tank
Engine coolant temperature gauge
Displays the engine coolant temperature
Odometer and trip meter
Odometer:
Displays the total distance th at the vehicle has been driven
G
H
I
A
B
C
D
E
F

Alphabetical Index723
Jam protection function ........ 158
Operation ............................. 158
Warning message ................ 159
Mud & Sand mode .................. 349
Multi-information display Audio system-linked display ... 93
Changing the display.............. 90
Convenience Services (Sugges-tion function)......................... 98
Display contents ..................... 89
Driving informatio n display ..... 91
Driving support system informa- tion display ........................... 93
Dynamic radar cruise control with full-speed range .......... 248
Eco Driving Indicator .............. 92
Intuitive parking assist-sensor ........................................... 270
Language ....................... 96, 685
LTA (Lane-Tracing Assist) ... 241
Menu icons ............................. 90
Meter control switches ........... 90
Navigation system-linked display ............................................. 93
PCS (Pre-Collision System) . 227
Pop-up display ............... 96, 685
Settings .......................... 94, 685
Tire pressure ........................ 582
Units ............................... 96, 685
Vehicle information display .... 93
Warning message display ...... 98
Warning messages .............. 633
Multi-terrain Select ................. 349
N
Navigation system-linked display ................................................. 93
Noise from under vehicle .......... 8
Normal mode .................. 347, 350
O
Odometer.............................82, 85
Odometer and trip meter display “ODO TRIP” switch ...........84, 88
“ODO TRIP” switch ............84, 88
Oil Engine oil..............................662
Rear differential oil ...............666
Transfer oil ...........................665
Opener Back door .....................115, 117
Fuel filler door.......................220
Hood .....................................569
Outer foot lights Replacing light bulbs ............604
Wattage ................................670
Outside rear view mirrors ......153 Adjusting and folding ............153
BSM (Blind Spot M onitor) .....260
Outside rear view mirror defog- gers ............................509, 516
Outside temperature display .83, 87
Overheating.............................654
P
Panic mode .............................105
Panoramic moon roof Jam protection function ........162
Operation..............................161
Warning message . ...............163
Panoramic view monitor ........309 Camera switch......................311
Checking around the vehicle 314
Checking the front and around the vehicle ..........................315
Checking the rear and around the vehicle ..........................320
Checking the sides of the vehicle ...........................................317
Customizing the panoramic view
