3TABLE OF CONTENTS
1
2
3
4
5
6
7
8
9
10
Trailer towing ................177
Dinghy towing ............... 189
4-2. Driving procedures Engine (ignition) switch (vehi-cles without smart key sys-
tem) ............................. 191
Engine (ignition) switch (vehi- cles with smart key system)
.................................... 192
Automatic transmission . 197
Turn signal lever ........... 200
Parking brake ................ 201
Brake Hold .................... 204
4-3. Operating the lights and wipers
Headlight switch ............ 207
AHB (Automatic High Beam) .................................... 210
Fog light switch ............. 214
Windshield wipers and washer......................... 214
Rear window wiper and washer......................... 217
4-4. Refueling Opening the fuel tank cap.................................... 219
4-5. Using the driving support
systems
Toyota Safety Sense 2.0 222
PCS (Pre-Collision System) .................................... 227
LTA (Lane Tracing Assist) .................................... 235
RSA (Road Sign Assist) 245
Dynamic radar cruise control with full-speed range ... 248BSM (Blind Spot Monitor)
.................................... 259
Intuitive parking assist ... 270
PKSB (Parking Support Brake) .......................... 278
Parking Support Brake func- tion (static objects) ...... 283
Parking Support Brake func- tion (rear-crossing vehicles)
.................................... 286
Rear view monitor system .................................... 288
Toyota parking assist monitor .................................... 296
Panoramic view monitor 309
Stop & Start system....... 341
Driving mode s elect switch
.................................... 347
Multi-terrain Select (AWD vehicles) ...................... 349
Snow mode switch (AWD vehicles) ...................... 352
Downhill assist control sys- tem .............................. 353
Driving assist systems ... 355
4-6. Driving tips Winter driving tips .......... 362
Utility vehicle precautions .... ...

............................. 365
5-1. Basic function Buttons overview ........... 371
Menu screen.................. 373
Status icon..................... 374
“Setup” screen ............... 376
5Audio

1984-2. Driving procedures
While the engine switch
is in ON and the brake pedal
depressed
*, shift the shift lever
while pushing the shift release
button on the shift knob.
Shift the shift lever while
pushing the shift release button
on the shift knob.
Shift the shift lever nor-
mally.
When shifting the shift lever
between P and D, make sure that
the vehicle is completely stopped.
*: For the vehicle to be able to be
shifted from P, the brake pedal
must be depresse d before the
shift release button is pushed. If
the shift release button is pushed first, the shift lock will not be
released.
■Shift lock system
The shift lock syste m is a system to
prevent accidental operation of the
shift lever in starting.
The shift lever can be shifted from P
only when the engi ne switch is in
ON, the brake pedal is depressed
and the shift release button is
pushed.
■If the shift lever cannot be
shifted from P
First, check whether the brake pedal
is being depressed.
If the shift lever cannot be shifted
even though the brake pedal is
depressed and the shift release but-
ton is pushed, the re may be a prob-
lem with the shift lock system. Have
the vehicle inspected by your
Toyota dealer immediately.
The following steps may be used as
an emergency measure to ensure
that the shift lev er can be shifted.
Releasing the shift lock:
1 Pull the parking brake switch to
check that the parking brake is
set. ( P.201)
2 Turn the engine switch to OFF.
3 Depress the brake pedal.
4 Pry the cover up with a flathead
screwdriver or equivalent tool.
To prevent damage to the cover,
cover the tip of the screwdriver
with a rag.
5 Press and hold the shift lock
override button and then push
the button on the shift knob.
Shifting the shift lever

5516-4. Using the other interior features
6
Interior features
1Within 5 seconds after pro-
gramming the garage door
opener has been completed,
if the garage door opener
motor is trained to
HomeLink
®, both garage
door operation indicators will
flash rapidly (green) and the
light on the garage door
opener motor will blink twice,
indicating that 2-way commu-
nication is enabled.
If the indicators do not flash, per-
form 2 and 3 within the first 10
presses of the HomeLink
® button
after programming has been com-
pleted.
2 Press a programmed
HomeLink
® button to oper-
ate a garage door.
3 Within 1 minute of pressing
the HomeLink
® button, after
the garage door operation
has stopped, press the
“Learn” or “Smart” button on
the garage door opener
motor. Within 5 seconds of
the establishment of 2-way
communication with the
garage door opener, both
garage door operation indica-
tors in the vehicle will flash
rapidly (green) and the light
on the garage door opener
motor will blink twice, indicat-
ing that 2-way communica-
tion is enabled.
■Reprogramming a single
HomeLink
® button
When the following procedure is
performed, buttons which
already have devices registered
to them can be overwritten:
1 Press and hold the desired
HomeLink
® button.
2 When the HomeLink
® indica-
tor starts flashing orange,
release the HomeLink
® but-
ton and perform “Program-
ming HomeLink
®” 1 (it takes
20 seconds for the
HomeLink
® indicator to start
flashing).
■Before programming
●Install a new battery in the trans-
mitter.
●The battery side of the transmitter
must be pointed away from the
HomeLink
® buttons.
Press the appropriate
HomeLink
® button. The
HomeLink
® indicator light
should turn on.
The status of the opening and
closing of a garage door is
shown by the garage door oper-
ation indicators.
Operating HomeLink®

Alphabetical Index721
Seat heaters ......................... 521
High mounted stoplight Replacing light bulbs ............ 604
Hill-start assist control .......... 356
HOME button .......................... 380
Home screen ........................... 380
Hood ........................................ 569
Hooks Cargo hooks ......................... 531
Coat hooks ........................... 545
Retaining hooks (floor mat) .... 28
Horn ......................................... 141
I
I/M test ..................................... 566
Identification Engine .................................. 662
Vehicle ................................. 661
Ignition switch (Engine switch) ....................................... 191, 192Auto power off function ........ 195
Changing the engine switch modes ................................ 195
Changing the engine switch positions ............................. 191
If your vehicle has to be stopped in an emergency................. 612
Starting the engine ....... 191, 192
Immobilizer system .................. 71
Indicators .................................. 76
Info button (Menu screen) ..... 373
Initialization Items to initialize................... 696
Maintenance......................... 563
Moon roof ............................. 159
Panoramic moon roof ........... 162
Parking Support Brake ......... 282
Power back door .................. 122
Power windows .................... 155
Tire pressure warning system........................................... 584
Initial screen ........................... 377 Caution screen .....................377
Restarting the system ...........377
Inside rear view m irror ...142, 144
Instrument panel light control84, 88
Interior lights...........................524 Switch ...................................524
Intuitive parking assist Function................................270
Warning message . ...............272
iPod/iPhone (Apple CarPlay) .430
J
Jack Positioning a floor jack .........570
Vehicle-equipped jack ..........638
Jack handle .............................638
Jam protection function Electronic sunshade .............162
Moon roof .............................158
Panoramic moon r oof ...........162
Power back door ..................120
Power windows ....................155
K
Keyless entry Smart key system .................127
Wireless remote control........104
Keys .........................................102 Battery-saving function .........128
Electronic key .......................102
Engine switch ...............191, 192
If the electronic key does not operate properly .................648
If you lose your keys.............648
Key number plate .................102
Keyless entry ................104, 127
Mechanical key.....................106
Replacing the battery ...........597
Warning buzzer .. ..................127
Wireless remote control key .104

Alphabetical Index727
Turn signal lever................... 200
Side windows ...... ................... 155
Smart key system ................... 127 Antenna location .................. 127
Entry functions ............. 107, 114
Starting the engine ............... 192
Warning message ................ 633
Snow mode switch ................. 352
Snow tires ............................... 362
Spare tire Storage location ................... 638
Spark plug ............................... 664
Specifications ......................... 660
Speedometer ...................... 82, 85
Sport mode ............................. 347
Status icon .............................. 374 Status icon explanation ........ 374
Steering lock Column lock release............. 191
Steering switch ............... 438, 454 Audio switch ......................... 438
Steering wheel Adjustment ........................... 141
Heated steering wheel ......... 521
Meter control switches ........... 90
Stop lights Replacing light bulbs ............ 604
Stop & Start system Function ............................... 341
Replacing the battery ........... 652
Storage feature ....................... 527
Storage precautions .............. 527
Stuck If the vehicle becomes stuck 656
Sunglass holder ..................... 529
Sunshade ........................ 158, 161
Sun visors ............................... 536
Switches “ODO TRIP” switch .......... 84, 88
“SOS” button .......................... 66
Automatic High Beam switch 210
Brake hold switch ................. 204 BSM (Blind Spot M
onitor) .....260
Digital Rear-view Mirror control switches..............................144
Door lock switch ...................111
Driving mode select switch ...347
Driving position memory switches..............................135
Dynamic radar cruise control with full-speed range ..........249
Electronic sunshade switch ..161
Emergency flashers switch...612
Engine switch ...............191, 192
Fog light switch .....................214
Garage door opener switches ...........................................546
Heated steering wheel..........522
Ignition switch (Engine switch) ...................................191, 192
Intuitive parking assist ..........271
Light switch...........................207
LTA switch ............................240
Meter control switches............90
Moon roof switches ..............158
Outside rear v iew mirror
switches..............................153
Panoramic moon roof switches ...........................................161
Parking brake switch ............201
PKSB (Parking Support Brake) ...........................................279
Power back door switch117, 118
Power door lock switch.........111
Power window switch ...........155
RCTA ....................................260
Rear window and outside rear view mirror defoggers switch...................................509, 516
Rear window wiper and washer switch .................................217
Seat heater switches ....522, 523
Seat ventilator switches........523
Snow mode switch ...............352

730Alphabetical Index
LTA indicator ........................ 625
Open door ............................ 111
Open hood ........................... 111
Open window ....................... 156
PKSB OFF indicator ............. 626
Pre-collision warning ............ 227
RCTA (Rear Cross Traffic Alert) ........................................... 260
RCTA OFF indicator............. 626
Seat belt reminder ................ 629
Vehicle sway warning........... 239
Warning lights ABS ...................................... 624
Brake hold operated indicator........................................... 627
Brake Override System ........ 627
Brake system ....................... 622
Charging system .................. 622
Drive-Start Control ............... 627
Electric power steering ......... 624
Engine .................................. 623
High coolant temperature ..... 623
Inappropriate pedal operation ........................................... 627
Intuitive parking assist OFF indi- cator ................................... 625
Low engine oil pressure ....... 623
Low fuel level ....................... 628
LTA indicator ........................ 625
Malfunction indicator lamp ... 623
Parking brake indicator ........ 628
PCS warning light................. 624
PKSB (Parking Support Brake) ........................................... 626
PKSB OFF indicato r ............. 626
RCTA OFF indicator............. 626
Seat belt reminder light ........ 629
Slip indicator......................... 627
SRS ...................................... 623
Stop & Start cancel indicator 625
Tire pressure ........................ 628
Warning messages ................ 633 Washer
Checking ..............................578
Low washer fluid warning mes-sage............................578, 633
Preparing and checking before winter ..................................362
Switch ...........................214, 217
Washing and waxing ..............556
Weight Cargo capacity .............173, 176
Load limits ............................176
Weight ..................................660
Wheels .....................................590 Replacing wheels .................590
Size ......................................667
Wi-Fi
®.......................................398
Connecting a device to the in- vehicle access point ...........398
Operating hints .....................401
Wi-Fi
® button (Setup screen) 376
Wi-Fi
® Hotspot ........................398
Window glasses Power windows ....................155
Window lock switch ...............157
Windows Power windows ....................155
Rear window defogger .509, 516
Washer .........................214, 217
Windshield defog ger ......509, 516
Windshield wipers Intermittent windshield wipers...........................................214
Position.........................214, 217
Rain-sensing windshield wipers ...........................................214
Replacing the wiper insert ....594
Winter driving tips ..................362
Wiper insert .............................594
Wireless charger.....................539
Wireless remote control.........104 Battery-saving function .........128
Locking/Unlocking ................104
