TOYOTA RAV4 EV 2014 1.G User Guide

11
C
Outside rear view mirror
switches
P. 143
Parking brake lever P. 216
AUX port*/USB port*
Cup holders P. 299
Shift lever P. 206
P position switch
P. 209
*: Refer to “Navigation System Owner’s Manual”.

12
Tilt and telescopic steering lock release lever P. 140
Headlight switch
Turn signal lever P. 234
P. 215
Windshield wiper and washer switch
Rear window wiper and washer switch P. 238
P. 241
Charging port door
opener
P. 59
Emergency flasher switch P. 412
Pictorial indexInstrument panel
Gauges and meters P. 218
Audio system*
Navigation system*
Hood release lever
P. 349
Horn P. 217

13
A
Instrument panel light control dial P. 219
*: Refer to “Navigation System Owner’s Manual”.
Manual headlight leveling dial P. 235

14
B
Instrument panelPictorial index
Cruise control switch P. 243
“DISP” switch P. 228Audio remote control switches *
Telephone switches *
Talk switch *

15
C
Power switch P. 200
Rear window and outside rear view
mirror defogger switch
P. 292
Security indicator P. 149
*: Refer to “Navigation System Owner’s Manual”.
Air conditioning system P. 276
Seat heater controls P. 310

16
D
SPORT mode switch P. 208
Power outlet P. 306
VSC OFF
switch
P. 252
Instrument panelPictorial index

17
Luggage compartmentPictorial index
Second seatback release lever P. 123
Grocery bag hooks
P. 317
Storage boxes P. 317
Cargo hooks P. 317
Power outlet P. 306
Luggage
compartment light
P. 295

18
For your information
Main Owner’s Manual
Please note that this manual covers all models and all equipment, including
options. Therefore, you may find some explanations for equipment not
installed on your vehicle.
All specifications provided in this manual are current at the time of printing.
However, because of the Toyota policy of continual product improvement, we
reserve the right to make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustrations may differ
from your vehicle in terms of equipment.
Accessories, spare parts and modification of your Toyota
A wide variety of non-genuine spare parts and accessories for Toyota
vehicles are currently available on the market. You should know that these
parts are not covered by Toyota warranty and that Toyota is not responsible
for their performance, repair, or replacement, or for any damage they may
cause to, or adverse effect they may have on, your Toyota vehicle.
This vehicle should not be modified with non-genuine Toyota products.
Modification with non-genuine Toyota products may affect performance,
safety or durability, and may even violate governmental regulations. In
addition, damage or performance problems resulting from the modification
may not be covered under warranty.
Installation of a mobile two-way radio system
The installation of a mobile two-way radio system in your vehicle could affect
electronic systems such as:
●Cruise control system
● Anti-lock brake system
● SRS airbag system
● Seat belt pretensioner system
Be sure to check with your Toyota dealer for precautionary measures or spe-
cial instructions regarding installation of a mobile two-way radio system.

19
Vehicle data recordings
Your Toyota is equipped with several sophisticated computers that will record
certain data, such as:
• Electric motor speed (traction motor speed)
• Accelerator status
• Brake status
• Vehicle speed
• Shift position
• Traction battery status
The recorded data varies according to the vehicle grade level and options
with which it is equipped. Furthermore, these computers do not record con-
versations, sounds or pictures.
●Data usage
Toyota may use the data recorded in these computers to diagnose malfunc-
tions, conduct research and development, and improve quality.
Toyota will not disclose the recorded data to a third party except:
• With the consent of the vehicle owner or with the consent of the lessee if the vehicle is leased
• In response to an official request by the police, a court of law or a govern- ment agency
• For use by Toyota in a law suit
• For research purposes where the data is not tied to a specific vehicle or vehicle owner
● Usage of data collected through Safety Connect
If your Toyota has Safety Connect and if you have subscribed to those ser-
vices, please refer to the Safety Connect Telematics Subscription Service
Agreement for information on data collected and its usage.

20
Event data recorder
This vehicle is equipped with an event data recorder (EDR). The main pur-
pose of an EDR is to record, in certain crash or near crash-like situations,
such as an air bag deployment or hitting a road obstacle, data that will assist
in understanding how a vehicle’s systems performed. The EDR is designed
to record data related to vehicle dynamics and safety systems for a short
period of time, typically 30 seconds or less.
The EDR in this vehicle is designed to record such data as:
• How various systems in your vehicle were operating;
• Whether or not the driver and passenger safety belts were buckled/fas-tened;
• How far (if at all) the driver was depressing the accelerator and/or brake pedal; and,
• How fast the vehicle was traveling.
These data can help provide a better understanding of the circumstances in
which crashes and injuries occur.
NOTE: EDR data are recorded by your vehicle only if a non-trivial crash situ-
ation occurs; no data are recorded by the EDR under normal driving condi-
tions and no personal data (e.g., name, gender, age, and crash location) are
recorded. However, other parties, such as law enforcement, could combine
the EDR data with the type of personally identifying data routinely acquired
during a crash investigation.
To read data recorded by an EDR, special equipment is required, and access
to the vehicle or the EDR is needed. In addition to the vehicle manufacturer,
other parties, such as law enforcement, that have the special equipment, can
read the information if they have access to the vehicle or the EDR.
