1023-4. Setup
3-4.Setup
1Press the “MENU” button.
2 Select “Setup”.
3 Select “Navigation”.
4 Select the desired item to be
set. Select to set home. (
P.102)
Select to set the favorites list.
( P.103)
Select to set areas to avoid.
( P.104)
Select to set detailed naviga-
tion settings. ( P.106)
●When “Useful Navi. Information
Settings” is displayed on the
screen: P.113
If home has been registered,
that information can be recalled
by selecting “Home” on the
destination screen. ( P.84)
1 Display the navigation set-
tings screen. ( P.102)
2 Select “Home”.
3 Select the desired item to
search for the location.
( P.84)
Navigation settings
Home, favorites list entries,
areas to avoid can be set as
memory points. The regis-
tered points can be used as
the destinations. ( P.84)
Registered areas to avoid,
will be avoided when the
navigation system searches
for a route.
Displaying navigation set-
tings screen
Navigation settings
screen
Setting up home
Registering home
A
B
C
D

1033-4. Setup
3
Navigation system
4Select “OK” when the editing
home screen appears.
1 Display the navigation set-
tings screen. ( P.102)
2 Select “Home”.
3 Select the desired item to be
edited.
Select to edit the home
name.
Select to edit location infor-
mation.
Select to change the icon to
be displayed on the map
screen. ( P.104)
Select to set display of the
home name on/off.
Select to delete registered
home location.
4 Select “OK”.
Points on the map can be regis-
tered.
1 Display the navigation set-
tings screen. ( P.102) 2
Select “Favorites”.
3 Select the desired item.
Select to edit the favorites list
entries. ( P.103)
“Add New”: Select to register favor-
ites list entries. ( P.103)
“Sort”: Select to sort (date, name,
icon) favorite list entries.
“Delete All”: Select to delete all
favorite list entries.
1 Select “Add New/Sort/Delete
All”.
2 Select “Add New”.
3 Select the desired item to
search for the location.
( P.84)
4 Select “OK” when the editing
favorites list screen appears.
( P.103)
●Up to 100 favorites list entries can
be registered.
The icon, name, location and/or
Editing home
Setting up favorites list
A
B
C
D
E
5HJLVWHULQJIDYRULWHVOLVW
HQWULHV
(GLWLQJIDYRULWHVOLVW
HQWULHV
A

1053-4. Setup
3
Navigation system
3Select the desired item.
Select to edit the list of areas
to avoid.
“Add New”: Select to register areas
to avoid. ( P.105)
“Delete All”: Select to delete all
areas to avoid.
1 Select “Add New/Delete All”.
2 Select “Add New”.
3 Select the desired item to
search for the location.
( P.84)
4 Select “+” or “-” to change the
size of the area to be avoided
and select “OK”.
5 Select “OK” when the area to
avoid screen appears.
●If a destination is entered in the
area to avoid or th e route calcula-
tion cannot be made without run- ning through the area to avoid, a
route passing through the area to
be avoided may be shown.
●Up to 10 locations can be regis-
tered as points/areas to avoid.
The name, location and/or area
size of a registered area can be
edited.
1
Select “Edit”.
2 Select the desired area.
3 Select the desired item to be
edited.
Select to edit the name of the
area to avoid.
Select to edit area location.
Select to edit area size.
Select to set the area to
avoid function on/off.
Select to set display of the
area to avoid name on/off.
Select to delete the area to
avoid.
4 Select “OK”.
Registering areas to avoid
A
(GLWLQJDUHDVWRDYRLG
A
B
C
D
E
F

1063-4. Setup
1Press the “MENU” button.
2 Select “Setup”.
3 Select “Navigation”.
4 Select “Detailed Navi. Set-
tings”.
5 Select the desired items to
be set. 
“Unverified Roads Guidance
Warning”
Select to set unverified roads guid-
ance warning on/off.
“Guidance on Unverified
Roads”
Select to set IPD road (roads that
are not completely digitized in our
database) guidance on/off.
 “Guidance with Street
Names”
Select to set the voice guidance for
the next street name on/off.
“Favorite POI Categories”
Select to set favorite POI catego-
ries that are used for POI selection
to display on the map screen.
( P.107)
 “Calibration”
Select to adjust the current position
mark manually or to adjust miscal-
culation of the distance caused by
tire replacement. ( P.107)
 “Adaptive Route”
Select to enable/disable adaptive
routes. When enabled, the naviga-
tion system will provide frequently
used routes.
“Reset Adaptive Route”
Select to erase adaptive route data.
“Automatic Destination List
Info”
Select to set automatic destination
list information on/off. When set to
on, the estimated time of arrival to
Detailed navigation
settings
Settings are available for
pop-up information, favor-
ite POI categories, low fuel
warning, etc.
Displaying the detailed
navigation settings
screen
Detailed navigation set-
tings screen

1073-4. Setup
3
Navigation system
the registered home and preset
destinations from the current posi-
tion will be displayed.
“Intersection Zoom Map”
Select to set display of a guidance
screen on/off.
“Automatic Zoom”
Select to set autom atic zoom func-
tion on/off. When it is enabled, as
the vehicle approaches a guidance
point, the map will change to a
detailed map automatically.
 “State Border Guidance”
Select to set cross-border guidance
on/off.
“Map Color Customization”
Select to set the map display color.
“Map Animation”
Select to set map animation on/off.
“Dynamic Route”*1
Select to enable/disable routes
sourced from the Cloud. ( P.94)
 “Predictive Efficient Drive”*1, 2
Select to set predictive efficient
drive on/off. ( P.108)
 “Restore the default settings”
Select to reset all setup items.
*1: This function is not made avail-
able in some countries or areas.
*2: Vehicles with hybrid system
Up to 6 POI icons, which are
used for selecting POIs on the
map screen, can be selected as favorites.
1
Display the detailed naviga-
tion settings screen.
( P.106)
2 Select “Favorite POI Catego-
ries”.
3 Select the desired category
to be changed.
“Default”: Select to set the default
categories.
4 Select the desired POI cate-
gory.
“List All Categorie s”: Select to dis-
play all POI categories.
5 Select the desired POI icon.
6 Select “OK”.
The current position mark can
be adjusted manually. Miscalcu-
lation of the distance caused by
tire replacement can also be
adjusted.
1 Display the detailed naviga-
tion settings screen.
( P.106)
2 Select “Calibration”.
3 Select the desired item.
Favorite POI categories
(Select POI icons)
Current position/Tire
change calibration

1093-4. Setup
3
Navigation system
releasing the accelerator pedal.
As a result, the battery charge
amount can be increased when
decelerating or stopping the
vehicle to enhance fuel econ-
omy.
The system reads the road and
traffic conditions ahead to effi-
ciently control the charging and
discharging of the hybrid battery
according to the actual driving
situation.
The capacity of the hybrid bat-
tery is limited. When it is fully
charged, regeneration cannot
occur, and when the battery is
depleted, it may be forcibly
charged by the engine. The sys-
tem predicts these situations to
adjust the battery charge level in
advance, effectively utilizing the
battery.
●The system operates when start-
ing route guidance and the posi-
tion of the vehicle is along the
guided route. (The system does
not operate in parking lots, etc.)
●When multiple destinations are
set, the system will continue to
operate to the last destination.
*: This function is not made avail-
able in some countries or areas.
1 Press the “MENU” button.
2 Select “Setup”.
3 Select “Traffic”.
4 Select the desired items to
be set.
Predictive SOC control
Traffic settings*
Traffic information such as
traffic congestion or traffic
incident warnings can be
made available.
Displaying the traffic set-
tings screen
Screen for traffic settings

1113-4. Setup
3
Navigation system
7Select the desired item to
search for the location.
( P.84)
8 Select “OK”.
9 Confirm the route overview
displayed.
Select the desired route from
3 possible routes. ( P.92)
Select to modify the route.
The routes can be adjusted
by setting preferred roads.
( P.111)
10 Select “OK”.
●Up to 5 routes can be registered.
1Select “Edit”.
2 Select the desired traffic
route. 3
Select the desired item to be
edited.
Select to edit the name of the
personal traffic route.
( P.110)
Select to edit start location.
( P.110)
Select to edit end location.
( P.110)
Select to see and modify the
entire route. ( P.111)
4 Select “OK”.
5 Follow the steps in “Register-
ing personal traffic routes”
from step 9. (  P.110)
1 Select “Delete”.
2 Select the desired traffic
route to be deleted and
select “Delete”.
3 Select “Yes” when the confir-
mation screen appears.
“My Traffic Routes” can be
adjusted by setting up to 2 pre-
Editing personal traffic
routes
A
B
'HOHWLQJSHUVRQDOWUDIILF
URXWHV
6HWWLQJSUHIHUUHGUR\
DGV
A
B
C
D

1133-4. Setup
3
Navigation system
3Select the desired item.
Select to automatically
change routes when conges-
tion information of the guid-
ance route has been
received.
Select to select manually
whether or not to change
routes when congestion
information of the guidance
route has been received. In
this mode, a screen will
appear to ask if you wish to
reroute.
Select to not reroute when
congestion information for
the guidance route has been
received.
When the navigation system
calculates a new route, a confir-
mation screen will be displayed. 1
Select the desired item.
Select to start route guidance
using the new route.
Select to confirm the new
route and current route on
the map.
Select to continue the current
route guidance.
Changing the route manually
A
B
C
A
B
C

1143-4. Setup
*: This function may not be avail-able immediately after purchase
of the vehicle.
1 Press the “MENU” button.
2 Select “Setup”.
3 Select “Navigation”.
4 Select “Useful Navi. Informa-
tion Settings”.
5 Select the desired items to
be set.
Use of information
accumulated by navi-
gation system
* (Vehi-
cles equipped with
DCM)
When enabled, information
collected by the navigation
system will be analyzed to
give advice for safe driving.
Displaying the useful nav-
igation information set-
tings screen

1153-5. Tips for operating the navigation system
3
Navigation system
3-5.Tips for operating the navigation system
The Global Positioning System
(GPS) developed and operated
by the U.S. Department of
Defense provides an accurate
current position, normally using
4 or more satellites, and in some
case 3 satellites. The GPS sys-
tem has a certain level of inac-
curacy. While the navigation
system compensates for this
most of the time, occasional
positioning errors of up to 300 ft.
(100 m) can and should be
expected. Generally, position
errors will be corrected within a
few seconds.
When the vehicle is not receiv-
ing signals from satellites, the
unreceived GPS mark appears
on the map screen. When the
vehicle is receiving the signals,
the unreceived GPS mark does not appear on the map screen.
The GPS signal may be physi-
cally obstructed, leading to inac-
curate vehicle position on the
map screen. Tunnels, tall build-
ings, trucks, or even the place-
ment of objects on the
instrument panel may obstruct
the GPS signals.
The GPS satellites may not
send signals due to repairs or
improvements being made to
them.
Even when the navigation sys-
tem is receiving clear GPS sig-
nals, the vehicle position may
not be shown accurately or inap-
propriate route guidance may
occur in some cases.

Accurate current position may
not be shown in the following
cases:
• When driving on a small angled
Y-shaped road.
• When driving on a winding road.
• When driving on a slippery road such as in sand, gravel, snow,
etc.
GPS (Global Position-
ing System)
This navigation system cal-
culates the current position
using satellite signals, vari-
ous vehicle signals, map
data, etc. However, an accu-
rate position may not be
shown depending on satel-
lite conditions, road config-
uration, vehicle condition or
other circumstances.
Limitations of the naviga-
tion system
NOTICE
●The installation of window tint-
ing may obstruct the GPS sig-
nals. Most window tinting
contains some metallic content
that will interf ere with GPS sig-
nal reception of the antenna in
the instrument panel. We advise
against the use of window tint-
ing on vehicles equipped with
navigation systems.
