6217-3. Do-it-yourself maintenance
7
Maintenance and care
1Turn the power switch to
OFF.
2 Open the fuse box cover.
Engine compartment: Type A
fuse box (if equipped)
Push claw and to com-
pletely release the lock, and then lift
up the cover.
Engine compartment: Type B
fuse box
Push claw and to com-
pletely release the lock, and then lift
up the cover.
NOTICE
■For normal operation after
replacing the battery
Observe the following precautions
to prevent accidents:
●Always work with dry hands.
Moisture may cau se the battery
to rust.
●Do not touch or move any other
component inside the remote
control.
●Do not bend either of the battery
terminals.
Checking and replac-
ing fuses
If any of the electrical com-
ponents do not operate, a
fuse may have blown. If this
happens, check and replace
the fuses as necessary.
Checking and replacing
fuses
AB
AB

6548-2. Steps to take in an emergency
shown while the dr iving support sys-
tems such as PCS (Pre-Collision
system) or the dynamic radar cruise
control with full-speed range is oper-
ating. If a warning message is
shown, be sure to decelerate the
vehicle or follow an instruction
shown on the multi -information dis-
play.
A warning message is shown when
Brake Override Syst em, Drive-Start
Control or Parking Support Brake (if
equipped) ( P.190, 298) operates.
Follow the instruct ions on the multi-
information display.
●If a message about an operation
of the power switch is shown (if
equipped)
An instruction for operation of the
power switch is shown when the
incorrect procedure for starting the
hybrid system is performed or the
power switch is operated incorrectly.
Follow the instructions shown on the
multi-information display to operate
the power switch again.
●If a message abou t a shift lever
operation is shown
To prevent the shift lever from being
operated incorrectly or the vehicle
from moving unexpectedly, a mes-
sage that requires shifting the shift
lever may be sho wn on the multi-
information display. In that case, fol-
low the instruction of the message
and shift the shift lever.
●If a message or image about an
open/close state of a part or
replenishment of a consumable is
shown
Confirm the part indicated by the
multi-information display or a warn-
ing light, and then perform the cop-
ing method such as closing the open door or replenishing a con-
sumable.
■If a message that indicates the
need for visiting your Toyota
dealer is displayed
The system or part shown on the
multi-information di splay is malfunc-
tioning. Have the vehicle inspected
by your Toyota dea ler immediately.
■If a message that indicates the
need for referring to Owner’s
Manual is displayed
●If “Engine Coolant Temp High” is
shown, follow the instructions
( P.680).
●If the following messages are
shown, there may be a malfunc-
tion. Immediately stop the vehicle
in a safe place and contact your
Toyota dealer. Continuing to drive
the vehicle may be dangerous.
• “Hybrid System Malfunction”
• “Check Engine”
• “Hybrid Battery System Malfunc-
tion”
• “Accelerator System Malfunction”
• “Hybrid System Stopped”
• “Engine Stopped”
• “Smart Key System Malfunction”
●If the following messages are
shown, there may be a malfunc-
tion. Immediately have the vehi-
cle inspected by your Toyota
dealer.
• “Oil Pressure Low”
• “Braking Power Low”
●If “Maintenance Required for Trac-
tion Battery Cooling Parts See
Owner’s Manual” is shown, the fil-
ter may be clogged, the air intake
vent may be blocked, or there may
be a gap in the duct. Therefore,
perform the follo wing correction
procedure.
• If the air intake vent or filter of the hybrid battery (traction battery)
are dirty, perform the procedures
on P.611to clean them.
• If the warning message is shown
when the air intake vent and filter
of the hybrid battery (traction bat-

6558-2. Steps to take in an emergency
8
When trouble arises
tery) are not dirty, have the vehicle
inspected at your Toyota dealer.
■If “Hybrid System Overheated
Output Power Reduced” is
shown
The message may be shown when
driving under severe operating con-
ditions. (For example, when driving
up a long steep hill or driving up a
steep hill in reverse.)
Coping method: P.680
■If “Traction Battery Needs to be
Protected Refrain from the Use
of N Position” is shown
This message may be displayed
when the shift lever is in N.
As the hybrid batte ry (traction bat-
tery) cannot be charged when the
shift lever is in N, shift the shift lever
to P when the vehicle is stopped.
■If “Traction Battery Needs to be
Protected Shift into P to
Restart” is shown
This message is displayed when the
hybrid battery (traction battery)
charge has become extremely low
because the shift lever has been left
in N for a certain amount of time.
When operating the vehicle, shift to
P and restart the hybrid system.
■If “Shift to P when Parked” is
shown (if equipped)
Message is displayed when the
driver’s door is opened without turn-
ing the power switch to OFF with the
shift lever in any position other than
P.
Shift the shift lever to P.
■If “Shift is in N Release Acceler-
ator Before Shif ting” is shown
Message is displayed when the
accelerator pedal has been
depressed and the shift lever is in N.
Release the accelerator pedal and
shift the shift lever to D or R.
■If “Press Brake when Vehicle is
Stopped Hybrid System may
Overheat” is shown
Message is displayed when the
accelerator pedal is depressed to
maintain the vehicl e position when
stopped on a upward slope, etc.
If this continues, the hybrid system
may overheat.
Release the accelerator pedal and
depress the brake pedal.
■If “Auto Power OFF to Conserve
Battery” is shown (if equipped)
Power was turned off due to the
automatic power off function.
Next time when starting the hybrid
system, operate the hybrid system
for approximately 5 minutes to
recharge the 12- volt battery.
■If “Engine Oil Level Low Add or
Replace” is displayed
The engine oil level may be low.
Check the level o f the engine oil,
and add engine oil if necessary.
This message may be displayed if
the vehicle is stopped on a slope.
Move the vehicle to a level surface
and check if the message disap-
pears.
■If “Maintenance Required
Soon” is shown
Indicates that all maintenance
according to the driven distance on
the maintenance schedule
* should
be performed soon.
Comes on approximately 4500
miles (7200 km) after the message
has been reset.
If necessary, perform maintenance.
Please reset the m essage after the
maintenance is performed.
(  P.573)
*: Refer to the separate “Scheduled
Maintenance Guide” or “Owner’
Manual Supplement” for the main-
tenance interval applicable to your
vehicle.

6778-2. Steps to take in an emergency
8
When trouble arises
“LOW” line
5 Add coolant if necessary.
Water can be us ed in an emer-
gency if engine coolant is unavail-
able.
If water was added in an emer-
gency, have the vehicle inspected
at your Toyota dealer as soon as
possible.
6 Start the hybrid system and
turn the air conditioning sys-
tem on to check that the radi-
ator cooling fan operates and
to check for coolant leaks
from the radiator or hoses.
The fan operates when the air con-
ditioning system is turned on imme-
diately after a cold start. Confirm
that the fan is op erating by check-
ing the fan sound and air flow. If it is
difficult to check th ese, turn the air
conditioning system on and off
repeatedly. (The f an may not oper-
ate in freezing temperatures.)
7 If the fan is not operating:
Stop the hybrid system
immediately and contact your
Toyota dealer.
If the fan is operating:
Have the vehicle inspected at
the nearest Toyota dealer.
8 Check if “Engine Coolant
Temp High Stop in a Safe
Place See Owner’s Manual” is shown on the multi-infor-
mation display.
If the message does not disappear:
Stop the hybrid system and contact
your Toyota dealer.
If the message is not displayed:
Have the vehicle inspected at the
nearest Toyota dealer.
■If “Hybrid System Over-
heated Output Power
Reduced” is shown on the
multi-information display
1 Stop the vehicle in a safe
place.
2 Stop the hybrid system and
carefully lift the hood.
3 After the hybrid system has
cooled down, inspect the
hoses and radiator core (radi-
ator) for any leaks.
Radiator
Cooling fan
If a large amount of coolant leaks,
immediately contact your Toyota
dealer.
4The coolant level is satisfac-
tory if it is between the
C
A
B

6788-2. Steps to take in an emergency
“FULL” and “LOW” lines on
the reservoir.
Reservoir
“FULL” line
“LOW” line
5 Add coolant if necessary.
Water can be us ed in an emer-
gency if power control unit coolant
is unavailable.
If water was added in an emer-
gency, have the vehicle inspected
at your Toyota dealer as soon as
possible.
6 After stopping the hybrid sys-
tem and waiting for 5 minutes
or more, start the hybrid sys-
tem again and check for the
multi-information display.
If the message does not disappear:
Stop the hybrid system and contact
your Toyota dealer.
If the message is not displayed:
The hybrid system temperature has dropped and the vehicle may be
driven normally.
However, if the message appears
again frequently, contact your
Toyota dealer.
A
B
C
WARNING
■When inspecting under the
hood of your vehicle
Observe the following precau-
tions.
Failure to do so may result in seri-
ous injury such as burns.
●If steam is seen coming from
under the hood, do not open the
hood until the steam has sub-
sided. The engine compart-
ment may be very hot.
●After the hybrid system has
been turned off , check that the
“READY” indicator is off.
When the hybrid system is oper-
ating, the gasoline engine may
automatically start, or the cool-
ing fan may suddenly operate
even if the gasoline engine
stops. Do not touch or approach
rotating parts such as the fan,
which may lead to fingers or
clothing (especially a tie, a scarf
or a muffler) getting caught,
resulting in serious injury.
●Do not loosen the coolant reser-
voir cap while the hybrid system
and radiator are hot.
High temperature steam or
coolant could spray out.
NOTICE
■When adding engine/power
control unit coolant
Add coolant slowly after the
hybrid system has cooled down
sufficiently. Adding cool coolant to
a hot hybrid system too quickly
can cause damage to the hybrid
system.

6869-1. Specifications
Front
Rear
*: The model code is indicated on the Certification Regulation Label.
(  P.684)
■Oil capacity (Drain and refill  reference*)
*: The engine oil capacity is a reference quantity to be used whe n changing
the engine oil. Warm up and turn off the hybrid system, wait mo re than 5
minutes, and check the o il level on the dipstick.
■Engine oil selection
“Toyota Genuine Motor Oil” is used in your Toyota vehicle.
Use Toyota approved “Toyota
Electric motor (traction motor)
TypePermanent magnet synchronous motor
Maximum output88 kW
Maximum torque149 ft•lbf (202 N•m, 20.6 kgf•m)
TypePermanent magnet synchronous motor
Maximum output40 kW
Maximum torque89.2 ft•lbf (121 N•m, 12.3 kgf•m)
Hybrid battery (traction battery)
Model code*AXAH54LAXAL54L
TypeNickel-Metal hydride
batteryLithium-ion battery
Voltage7.2 V/module3.7 V/cell
Capacity6.5 Ah (3HR)4.3 Ah
Quantity34 modules70 cells
Nominal voltage244.8 V259.0 V
Lubrication system
With filter4.8 qt. (4.5 L
, 4.0 Imp. qt.)
Without filter4.4 qt. (4.2 L, 3.7 Imp. qt.)

Alphabetical Index739
Jam protection function ........ 183
Operation ............................. 182
Emergency, in case of If a warning buzzer sounds .. 642
If a warning light turns on ..... 642
If a warning message is dis-played................................. 654
If the 12-volt battery is dis- charged .............................. 672
If the electronic key does not operate properly ................. 670
If the fuel filler door cannot be opened ............................... 669
If the hybrid sy stem will not start
........................................... 667
If the vehicle is trapped in rising water .................................. 636
If you have a flat tire ............. 658
If you lose your keys ............ 668
If you think something is wrong ........................................... 641
If your vehicle becomes stuck ........................................... 680
If your vehicle has to be stopped in an emergency................. 635
If your vehicle needs to be towed ........................................... 637
If your vehicle overheats ...... 677
Emergency flashers ............... 634
Energy monitor ....................... 113
Engine Compartment ....................... 582
Hood..................................... 579
Identification number ............ 685
Engine coolant Capacity ............................... 688
Checking .............................. 584
Preparing and c hecking before
winter.................................. 378
Warning light ........................ 643
Engine coolant temperature gauge................................. 94, 98 Engine oil
Capacity ...............................686
Checking ..............................582
Preparing and checking before winter ..................................378
Warning light ........................643
Enhanced Vehicle Stability Con- trol (Enhanced VSC ) .............369
Enhanced VSC (Enhanced Vehi- cle Stability Control).............369
Entering letters and numbers/list screen operation...................397Entering letters and numbers397
List screen ............................398
EPS (Electric Po wer Steering)
Function................................370
Warning light ........................644
Establishing an Android Auto connection .......... ..................420
Establishing an Apple CarPlay connection .......... ..................419
EV drive mode.........................217
Event data recorder (EDR) .......10
EV indicator...............................73
F
Flat tire.....................................658 Tire pressure warning system...........................................593
Floor mats .................................28
Fluid Brake ............................586, 689
Hybrid transmission ..............689
Rear differential ....................689
Washer .................................587
FM ............................................437
Fog lights Replacing light bulbs ............624
Switch ...................................235
Wattage ................................692
Footwell lights ........................534
Front passenger’s seat belt

750Alphabetical Index
system ..................................... 74
Vehicle Stability Control (VSC) ............................................... 369
Ventilators (seat ventilators) . 531
Voice button (Setup screen).. 392
Voice command system ........ 470 Voice command system opera-tion ..................................... 471
VSC (Vehicle Stability Control) ............................................... 369
W
Warning buzzers Approach warning ................ 278
Brake hold ............................ 648
Brake Override System ........ 648
Brake system ....................... 642
Downshifting......................... 222
Drive-Start Control ............... 648
Electric power steering ......... 644
High coolant temperature ..... 643
Intuitive parking assist OFF indi-cator ................................... 646
Intuitive parking assist .......... 291
Low engine oil pressure ....... 643
LTA (Lane Tracing Assist).... 258
LTA indicator ........................ 645
Open door ............................ 131
Open hood ........................... 131
Open window ....................... 177
PKSB OFF indicato r ............. 646
Pre-collision warning ............ 250
RCTA (Rear Cross Traffic Alert) ........................................... 283
RCTA OFF indicator............. 647
Seat belt reminde r ........ 649, 650
Vehicle sway warning........... 262
Warning lights ABS ...................................... 644
Brake hold operated indicator........................................... 648
Brake Override System ........ 648 Brake system ........................642
Charging system ..................642
Drive-Start Control
................648
Electric power steering .........644
Engine ..................................643
High coolant temperature .....643
Intuitive parking assist OFF indi- cator ...................................646
Low engine oil pressure .......643
Low fuel level........................649
LTA indicator ........................645
Malfunction indica tor lamp ....643
Parking brake indicator.........648
PCS warning light .................645
PKSB (Parking Support Brake) ...........................................648
PKSB OFF indicator .............646
RCTA OFF indicator .............647
Seat belt reminder light 649, 650
Slip indicator .........................647
SRS ......................................644
Tire pressure ...... ..................649
Warning messages .................654
Washer Checking ..............................587
Low washer fluid warning mes-sage............................587, 654
Preparing and checking before winter ..................................378
Switch ...........................236, 239
Washing and waxing ..............566
Weight Cargo capacity .............196, 199
Load limits ............................199
Weight ..................................684
Wheels .....................................607 Replacing wheels .................607
Size ......................................690
Wi-Fi
®.......................................414
Connecting a device to the in- vehicle access point ...........414
Operating hints .....................417
